1996 FORD E SERIES Owners Manual

249 [RE05975( E )02/95]
three fourths page art:0020839-C
The spare tire location and assembly
*
[RE06050( E )03/91]
To stow spare tire:
*
[RE06150( E )10/94]
1. Insert the jack handle or lug nut wrench into
the actuator hole and turn counterclockwise
until the cable/retainer is extended for
insertion into the wheel.
*
[RE06200( E )10/94]
2. Install the retainer through wheel center
with valve stem facing up.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

250
*
[RE06250( E )12/91]
NOTE: Stow aluminum wheel and tire with
valve stem down.
*
[RE06350( E )10/94]
3. Rotate the handle clockwise to secure tire.
Continue until the lift mechanism ªslipsº.
*
[RE06400( E )03/91]
4. Check for proper seating against underbody
supports and retighten if necessary.
*
[RE15100(BEF )05/95]
RWARNING
Make sure the spare tire and jacking
equipment are stowed and secured in the
proper storage location.
*
[RE15200( ALL)03/95]
Preparing to Change the Tire
*
[RE15250( ALL)12/91]
NOTE: To lift your vehicle by other than the
front or rear jacking points, be sure to
use only hoist adapters with a wide
contact surface.
*
[RE15325( E M)03/95]
1. Make sure that your vehicle will not move
or roll. Put the gearshift in P (Park). Set the
parking brake and block the wheel that is
diagonally opposite the tire that you are
changing.
*
[RE15377( E )06/95]
When one of the back wheels is off the ground,
the transmission alone will not prevent the
vehicle from moving or slipping off the jack,
even if the vehicle is in P (Park). To prevent the
vehicle from moving when you change a tire, be
sure the parking brake is set, then block the
wheel (both directions) that is diagonally
opposite (other side and end of the vehicle) to
the tire being changed.
[RE15430(E )10/95]
RWARNING
If the vehicle slips off the jack, you or
someone else coule be seriously injured.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

251 [RE15445(E )05/95]
RWARNING
On E-Super Duty vehicles, the parking
brake is on the transmission. Therefore,
the vehicle will not be prevented from
moving when a rear wheel is lifted, even
if the vehicle is in Park and the parking
brake is applied. Be sure to block both
directions of the wheel that is diagonally
opposite to the wheel that is being lifted.
If the vehicle slips off the jack, someone
could be seriously injured.
*
[RE15550(BEF )05/95]
2. Get out the spare tire and jack.
[RE16300( E )01/89]
The jack, jack handle and lug nut wrench are
stowed as shown below.
[RE16400( E )05/91]
one third page art:0020289-D
Jack handle and wrench stowage
*
[RE16800(BEF )12/91]
3. Use the tapered end of the lug nut wrench
to unscrew wheel ornaments attached by
retaining screws. Remove any wheel trim.
Insert the tapered end of the lug nut wrench
behind wheel covers or hubcaps and twist
off.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

252
*
[RE16900(BEF )10/89]
4. Loosen the wheel nuts by pulling up on the
handle of the lug nut wrench about one-half
turn (counterclockwise). Do not remove the
wheel lug nuts until you raise the tire off the
ground.
*
[RE16950(BEF )05/95]
Removing and Replacing the Tire
[RE17000( E )02/95]
1. Unfold the jack handle and lock into the
jack. Use the jack handle to slide the jack
under the vehicle.
*
[RE17175(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE17200(BEF )05/95]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[RE17300(BEF )06/95]
2. Positioning the jack
[RE18501( E )01/89]
a. To raise a front or rear wheel, place the
jack as shown in the following
illustrations.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

253 [RE18551(E )11/89]
one third page art:0020296-A
Jacking point (All models except E-Super Duty)
[RE18600(BE )11/89]
one third page art:0021527-A
Jacking point (E-Super Duty)
[RE18900( E )12/91]
one third page art:0020298-B
Instructions for jacking a wheel Ð All models
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

254
*
[RE19100( E )08/91]
b. Turn the jack handle clockwise until the
wheel is completely off the ground.
*
[RE21151(BEF )10/92]
one third page art:0020939-B
[RE21400(BEF )06/95]
3. Remove the lug nuts with the lug nut
wrench.
[RE21500(BEF )06/95]
4. Replace the flat tire with the spare tire.
*
[RE21600( EF )06/95]
If your vehicle has dual rear wheels, there are
locating pins on the hubs and wheels with
corresponding holes. When you put the wheel
back on, make sure the pins are lined up with
the proper holes.
[RE21800( EF )06/95]
If your vehicle has single rear wheels, thread the
lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench
to screw the lug nut snugly against the wheel
but do not tighten.
*
[RE21900( EF )01/89]
If your vehicle has dual rear wheels, thread the
two-element swiveling lug nut on the wheel
studs with the flange face toward the wheel. Use
the lug nut wrench to screw the lug nut snugly
against the wheel but do not tighten.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

255
*
[RE22000( EF )05/90]
quarter page art:0020310-A
Single rear wheel nut
*
[RE22100( EFM)05/90]
quarter page art:0020311-A
Dual rear wheel nut
*
[RE22200(BEF )01/95]
5. Lower the vehicle by turning the jack handle
counterclockwise.
[RE22300(BEF )06/95]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration.
%*
[RE22425( EF )05/90]
quarter page art:0020317-A
Lug nut tightening sequence
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

256
*
[RE23400(BEF )05/95]
RWARNING
Use of wheels or lug nuts other than
original equipment could cause damage to
the wheel or mounting system and allow
the wheels to come off while the vehicle
is in motion.
[RE23500(BEF )06/95]
7. Replace any wheel covers, ornaments, or hub
caps that your vehicle has. Make sure that
they are screwed or snapped into place.
[RE23615(BEF )06/95]
8. Put the tire, jack, and wrench away. (Make
sure jack is securely fastened so it doesn't
rattle when you drive.) The carrier is
designed to hold the temporary spare which
comes with your vehicle. The stowage of a
full size tire in the spare tire carrier may
damage the tire or the vehicle. The flat full
size tire should be stowed securely in the
vehicle until it can be repaired.
[RE23700(BEF )06/95]
9. Unblock the wheels.
*
[RE24100( EF )06/95]
On vehicles equipped with dual rear wheels
retighten the wheel lug nuts to the specified
torque at 100 miles (160 km), and again at 500
miles (800 km) of new vehicle operation and at
the intervals specified in theMaintenance Schedule
and Recordbooklet.
*
[RE24200( ALL)10/89]
Also retighten to the specified torque at 500
miles (800 km) of operation after any wheel
change or any time the lug nuts are loosened.
*
[RE24301( ALL)05/95]
RWARNING
Failure to retighten wheel lug nuts at
mileages specified could allow wheels to
come off while the vehicle is in motion.
