1996 FORD E SERIES Owners Manual

111 %
*
[SC11500( ALL)06/95]
Resuming a Set Speed
*
[SC11600( ALL)06/95]
If you press the brake pedal, the speed control is
cancelled. You can return to the speed you set
by using the RSM switch, as long as you did not
press the OFF switch.
*
[SC11700( ALL)06/95]
To resume the speed you had before, you must
be driving at least 30 mph (50 km/h).
*
[SC11800( ALL)06/95]
Press and release the RESUME switch. Your
vehicle gradually returns to the previously set
speed and then maintains it.
*
[SC11850( ALL)03/95]
RWARNING
If your vehicle has speed control, do not
use it on slippery roads. You could lose
control of your vehicle and could injure
someone.
File:07ltsce.ex
Update:Wed Apr 17 08:47:45 1996

113
Features
*
[FV00401(BEF )02/95]
Your vehicle has a variety of features designed
for your comfort, convenience and safety. Read
this chapter to find out about standard and
optional features.
*
[FV00501( EF )05/90]
NOTE: For Stripped Chassis vehicles, see your
Body Builders manual for location and
operation of all items defined in this
section.
*
[FV00601(BEF )01/95]
Doors
%*
[FV01801(BEF )03/95]
Anti-theft front door lock knobs
*
[FV01901(BEF )10/89]
Anti-theft lock knobs are designed to preclude
unlocking the door by pulling up on the bullet
type lock knob. To unlock and open the front
door from the inside of the vehicle, pull on the
inside door handle.
[FV03401( E )04/95]
Side Double Doors (If equipped)
[FV03500( E )05/91]
To open the forward door of the side double
door from the inside, first unlock the door with
the lock plunger or the power lock switch. Now
reach into the depression in the door and pull
the release handle inward. Open the forward
side door from the outside by pulling the door
handle towards you.
[FV03600( E )03/91]
The rear side door cannot be opened until the
forward side door is open. With the forward
side door open, pull the release handle (from the
middle of the rear door pillar) to open the rear
side door.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

114 [FV03701( E )03/91]
one third page art:0020189-BSide double door handles
*
[FV03801( E )04/95]
Sliding Door
[FV04001( E )03/94]
Unlock the door first. Then unlatch the sliding
door by pulling the inside handle to the rear, or
by pulling the outside handle outward. Now
slide the door back until the catch at the bottom
of the door engages. To close, pull the inside
handle forward or pull the outside handle
forward, and slide the door forward until it is
closed and latched. If the door is not completely
closed repeat the process.
[FV04201( E )03/91]
one third page art:0020180-B
Sliding door handles
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

115 % [FV08701( E )05/90]
Dual Rear Cargo Door
[FV08901( E )05/91]
To open the right rear door from the inside, first
unlock the door with the lock plunger. Now
reach into the depression in the door and pull
the release handle inward. Open the right rear
door from the outside by pulling on the door
handle.
[FV09000( E )05/93]
The left rear door cannot be opened until the
right rear door is open. With the right rear door
open, pull the release handle (from the middle
of the left door) to open the left door.
[FV09100( E )03/91]
quarter page art:0020198-B
Dual rear cargo door handles - outside
[FV09200( E )03/91]
one third page art:0020199-B
Dual rear cargo door handles - inside
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

116
*
[FV09801( E )05/95]
RWARNING
Do not operate your vehicle with the rear
double doors open.
*
[FV14100(BEF )04/95]
Power Door Locks (If equipped)
*
[FV14500(BEF )05/95]
The power door lock switches are located in the
front doors. To lock all doors push the switch
marked L. To unlock all doors push the switch
marked U.
*
[FV14701(BEF )03/91]
The manual door locks will override the power
door lock controls.
*
[FV15001(BEF )05/95]
quarter page art:0020203-C
Power door lock controls
*
[FV15301(BEF )05/95]
Remote Entry System
(If equipped)
*
[FV15401(BEF )06/95]
If your vehicle has the remote entry system, you
can lock or unlock the vehicle doors without
using a key. The remote also has a personal
alarm feature. The buttons for the system are
located on the two hand held transmitters that
came with your vehicle.
*
[FV15600(BEF )06/95]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

117
*
[FV15700(BEF )02/95]
The remote entry features only operate with the
ignition in the OFF position.
*
[FV15800(BEF )04/94]
quarter page art:0020788-A
The remote entry transmitter
%*
[FV15901(BEF )02/95]
Unlocking the doors with the remote entry
system
*
[FV16001(BEF )02/95]
To unlock the driver's door, press the UNLOCK
button.
*
[FV16101(BEF )02/95]
To unlock the other doors, press the UNLOCK
button a second time within five (5) seconds of
unlocking the driver's door.
*
[FV16300(BEF )02/95]
Locking the doors with the remote entry
system
*
[FV16401( E )04/95]
To lock all the doors, press the LOCK button.
This will also arm the optional factory installed
Anti-Theft system.
%*
[FV16800(BEF )02/95]
Remote entry personal alarm
*
[FV16900(BEF )04/95]
If you wish to activate the remote entry system
personal alarm, press the PANIC button. This
will honk the horn and flash the lights for
approximately 2 minutes 45 seconds. You can
turn it OFF by pressing the PANIC button again
from the same transmitter or by turning the
ignition to the ON or ACCESSORY position.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

118
*
[FV17000(BEF )02/95]
When you use the remote entry UNLOCK or
PANIC buttons, the illuminated entry system
turns on the vehicle's interior lights for 25
seconds. You can turn these lights off with the
remote entry LOCK button or by turning the
ignition to the ON or ACCESSORY position.
*
[FV17100(BEF )04/94]
quarter page art:0060566-B
%*
[FV17200( E )04/95]
Arming and Disarming the Alarm System
with Remote Entry
*
[FV17300( E )04/95]
Your Remote Entry System will automatically
arm the factory installed Anti-Theft System when
the doors are locked, and automatically disarm it
when the doors are unlocked. The remote will
also reset the anti-theft alarm (when the driver's
door is unlocked) if it was triggered.
*
[FV17400( E )04/95]
The remote entry system may not arm and
disarm non-factory installed anti-theft systems.
%*
[FV17501(BEF )02/95]
Replacing the batteries
*
[FV17601(BEF )02/95]
The remote entry transmitter is powered by two
coin type three-volt lithium 2016
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

119
*
[FV17701(BEF )02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV17801(BEF )03/93]
quarter page art:0020789-A
Opening the remote transmitter
*
[FV17901(BEF )02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
*
[FV18001(BEF )02/95]
quarter page art:0020790-A
Replacing the batteries
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996
