Rear seat shoulder safety belt Ð stowage (with seat
removed)
% [FV36101( E )02/92]
Quick Release Rear Passenger Seat
Assembly
% [FV36201( E )02/95]
Three Passenger and Four Passenger Bench
and Bed Seats
[FV36300( E )01/89]
To remove the seat assembly:
*
[FV36400( E )06/92]
1. Disengage the lap/shoulder safety belt from
the seat by inserting a key or screwdriver
into the slot in the detachable anchor and
lifting upward. Stow the tongue end of the
detachable anchor as shown in the
illustration.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

130 [FV36500( E )05/91]
three fourths page art:0020783-BLocation of the detachable anchor warning label on safety
belt
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

131 [FV36600( E )05/95]
two third page art:0020856-C
Rear seat shoulder safety belt Ð stowage (with seat
removed)
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

132 [FV36700( E )05/95]
three fourths page art:0020784-CLocation of the stowage hook caution label on safety belt
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

133 [FV36801( E )05/95]
two third page art:0020857-B
Rear seat shoulder safety belt Ð stowage (with seat
removed)
[FV36900( E )03/91]
2. Lift and rotate the LH/RH seat latch handles
rearward.
[FV37000( E )06/92]
3. Lift the LH/RH latch rod hook ends out of
the locking holes in the front strikers.
[FV37101( E )06/92]
4. Move (slide) the seat rearward and lift the
seat's rear stanchion hooks away from the
rear latch strikers in the floor prior to lifting
the front stanchion hooks out from the front
latch strikers in the floor. Refer to the
illustration.
[FV37201( E )03/91]
5. Remove the seat assembly from vehicle.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

134
*
[FV37301( E )05/89]
To install the seat assembly:
[FV37401( E )06/92]
1. Place the seat assembly in the vehicle.
[FV37501( E )06/92]
2. Align the front stanchion hooks to the front
latch strikers in the floor prior to lowering
the seat's rear stanchion hooks and aligning
them with the rear latch strikers in the floor.
[FV37601( E )06/92]
3. Engage the LH/RH latch rod hook ends in
the front striker locking holes.
[FV37701( E )06/92]
4. Rotate the LH/RH latch handles forward,
and at the same time, slide the seat assembly
forward to engage the floor strikers.
Continue forward movement until it reaches
the end of its travel.
[FV37801( E )06/92]
5. Before you engage the lap/shoulder safety
belt to the seat, make sure the belt is not
twisted. A twisted belt may cause the
retractor to not work properly. Remove any
twist, then insert the tongue end of the
detachable anchor into the detachable anchor
until you hear a ªsnapº and feel the latch
engage. Refer to the previous illustration.
File:08ltfve.ex
Update:Wed Apr 17 08:47:13 1996

135 [FV37901( E )02/92]
two third page art:0020231-C
Quick seat release Ð bench seat
