When stopped in traffic for long periods of time
in hot weather, place the gearshift selector lever
in P (Park) to increase the engine idle speed.
This aids in engine cooling and air conditioner
efficiency. If the engine overheats, move the
Function Selector Lever to VENT to stop the
compressor and increase the engine speed for a
short time.
*
[DR39900( ALL)05/90]
Vehicles with trailers should not be parked on a
grade. However, if you must park on a grade,
place wheel chocks under the trailer's wheels as
follows:
*
[DR40000( ALL)05/95]
q
Apply the brake pedal and hold.
*
[DR40100( ALL)11/89]
q
Have another person place the wheel chocks
under the trailer wheels.
*
[DR40200( ALL)11/89]
q
With the chocks in place, release the foot
service brakes, making sure the chocks are
holding.
*
[DR40350( E M)03/91]
q
Apply the parking brake by pressing the
service brake pedal down firmly with your
right foot while applying the parking brake
pedal with your left foot.
*
[DR40575( E M)06/95]
q
Shift the gearshift lever into P (Park).
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

242
*
[DR40600( ALL)01/93]
To start, after being parked on a grade:
*
[DR40700( ALL)11/89]
q
Apply the foot service brakes and hold
*
[DR40800( ALL)11/89]
q
Start the engine
*
[DR40900( ALL)11/89]
q
Shift transmission into gear and release the
parking brake
*
[DR41000( ALL)11/89]
q
Release the foot service brakes and move the
vehicle uphill to free the wheel chocks
*
[DR41100( ALL)05/95]
q
Apply the brake pedal and hold while
another person retrieves the chocks.
*
[DR41550( EF )03/94]
NOTE: Diesel equipped vehicles not
recommended for snow plowing.
File:10ltdre.ex
Update:Wed Apr 17 08:44:07 1996

243
Roadside Emergencies
*
[RE00400( ALL)03/95]
Jump-Starting Your Vehicle
*
[RE00450( EF )04/94]
NOTE: Read the7.3L Diesel Engine Owner's
Guide Supplementfor information on
jump-starting your diesel-powered light
truck.
*
[RE00500( ALL)01/95]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start from a booster battery
to start your vehicle.
*
[RE00600( ALL)02/95]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[RE00700( ALL)02/95]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[RE00800( ALL)06/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

244 %
*
[RE00900( ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[RE00925( ALL)06/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE00950(BEF )06/95]
RWARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[RE01000( ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
*
[RE01100( ALL)03/95]
Preparing Your Vehicle
*
[RE01200( ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300( ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

245
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
%*
[RE01700( ALL)05/95]
Connecting the jumper cables
*
[RE01800( ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
[RE01850( E )05/91]
NOTE: DO NOT jump-start your auxilliary
battery.
*
[RE01900( ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02000( ALL)05/95]
3. Connect one end of the second cable to the
negative (-) terminal of the booster battery
Ð NOT to the discharged battery.
*
[RE02100( ALL)04/95]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

246
*
[RE02200( ALL)05/95]
RWARNING
Do not connect the end of the second
cable to the negative (-) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
*
[RE02300( ALL)06/93]
one third page art:0020262-C
Attaching jumper cables
*
[RE02500( ALL)03/95]
Jump-Starting
*
[RE02600( ALL)03/95]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[RE02700( ALL)03/95]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[RE02800( ALL)03/95]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

247
*
[RE02900( ALL)03/95]
Removing jumper cables
*
[RE03000( ALL)03/95]
1.Always remove the jumper cables in the
reverse order.Remove the negative (S) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[RE03100( ALL)06/95]
2. Remove the negative (S) cable from the
booster battery.
*
[RE03200( ALL)06/95]
3. Remove the positive (+) cable from the
booster battery.
*
[RE03400( ALL)05/95]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[RE03500( ALL)04/95]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
You may need to use a battery charger to fully
recharge the battery.
*
[RE03550( ALL)03/95]
If you need to replace your battery, seeBattery
in theServicing Your Vehiclechapter.
*
[RE03600( ALL)03/95]
Changing a Tire
*
[RE03700( ALL)01/95]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[RE03800( ALL)03/95]
The Conventional Spare Tire
*
[RE03900(BEF )01/95]
If you have the conventional spare tire, you can
use it as a spare or as a regular tire. This spare
tire is identical to the other tires that come with
your vehicle, although the wheel may not match.
File:11ltree.ex
Update:Wed Apr 17 08:42:44 1996

248
*
[RE04275(BEF )05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
*
[RE04280(BEF )10/94]
Extended use of other than matching size spare
tires on a Traction-Lok axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
*
[RE05100(BEF )03/95]
Spare Tire Location
*
[RE05250( E )06/94]
The spare tire for your vehicle is stowed at the
rear under the frame (except cutaway and
stripped chassis models).
*
[RE05550( E )03/91]
To remove the spare tire:
[RE05625( E )03/93]
1. Open both of the rear doors. Remove the
access cover from the rubber strip found
behind the left door. Insert tapered end of
lug wrench or tip of jack handle through the
access hole. Turn counterclockwise until the
cable extends enough to allow the spare tire
to be pulled rearward from under the
vehicle.
*
[RE05700( E )10/94]
2. Slide the spare tire to the rear and remove
the retainer from the wheel.
*
[RE05850( E )10/94]
3. To stow the cable/retainer with spare
removed, turn jack handle wrench clockwise
until slack is removed.
