5
When trouble arises
4015-2. Steps to take in an emergency*1
: Driver’s seat belt buzzer:
Vehicles without a smart key system
The driver’s seat belt buzzer sounds to alert the driver that h is or her seat
belt is not fastened. Once the engine switch is turned to the “ ON” position,
the buzzer sounds for 6 seconds. If the vehicle reaches a speed of 12 mph
(20 km/h), the buzzer sounds once. If the seat belt is still un fastened after 24
seconds, the buzzer will sound intermittently for 10 seconds. Then, if the
seat belt is still unfastened, the buzzer will sound in a diffe rent tone for 20
more seconds.
Vehicles with a smart key system
The driver’s seat belt buzzer sounds to alert the driver that h is or her seat
belt is not fastened. Once the “ENGINE START STOP” switch is tu rned to
IGNITION ON mode, the buzzer sounds for 6 seconds. If the vehic le
reaches a speed of 12 mph (20 km/h), the buzzer sounds once. If the seat
belt is still unfastened after 24 seconds, the buzzer will soun d intermittently
for 10 seconds. Then, if the seat belt is still unfastened, the buzzer will
sound in a different tone for 20 more seconds.*2
: Front passenger’s seat belt buzzer:
The front passenger’s seat belt buzzer sounds to alert the front passenger
that his or her seat belt is not fastened. The buzzer sounds on ce if the vehi-
cle reaches a speed of 12 mph (20 km/h). If the seat belt is st ill unfastened
after 24 seconds, the buzzer will sound intermittently for 10 s econds. Then,
if the seat belt is still unfastened, the buzzer will sound in a different tone for
20 more seconds.

4025-2. Steps to take in an emergency
■ Front passenger detection sensor and passenger seat belt remind er
and warning buzzer
● If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash and warni ng
buzzer to sound, even if a passenger is not sitting in the seat .
● If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.■
The tire pressure warning light may turn on due to natural caus es
The tire pressure warning light may turn on due to natural caus es such
as natural air leaks or tire inflation pressure changes caused by tem-
perature. In this case, adjusting the tire inflation pressure w ill turn off the
warning light (after a few minutes).■
When a tire is replace d with a spare tire
The compact spare tire is not equipped with a tire pressure war ning
valve and transmitter. If a tire goes flat, the tire pressure w arning light will
not turn off even though the flat tire has been replaced with t he spare
tire. Replace the spare tire with the repaired tire and adjust the tire infla-
tion pressure. The tire pressure warning light will go off afte r a few min-
utes.

5
When trouble arises
4035-2. Steps to take in an emergency
■
If the tire pressure warn ing system is inoperative
The tire pressure warning system will be disabled in the follow ing condi-
tions:
(When the condit ion becomes no rmal, the system will work proper ly.)●
If tires not equipped with tire pressure warning valves and tra nsmit-
ters are used.●
If the ID code on the tire pressure warning valves and transmit ters is
not registered in the tire pressure warning computer.●
If the tire inflation p ressure is 55 psi ( 380 kPa, 3.87 kgf/cm 2
or bar) or
higher.
The tire pressure warning system may be disabled in the followi ng condi-
tions:
(When the condit ion becomes no rmal, the system will work proper ly.)●
If electronic devices or facilities using similar radio wave fr equencies
are nearby.●
If a radio set at similar frequen cies is in use i n the vehicle.●
If a window tint that affects the radio wave signals is install ed.●
If there is a lot of snow or ice on the vehicle, in particular around the
wheels or wheel housings.
●
If non-genuine Toyota wheels are used. (Even if you use Toyota
wheels, the tire pressure warning system may not work properly with
some types of tires.)
●
If tire chains are used.
●
If a large metallic object which can interfere with signal rece ption is
put in the trunk.
■
If the tire pressure warning light frequently comes on after bl inking
for approximately one minute
If the tire pressure warning light frequently comes on after bl inking for
approximately one minute when the “ENGINE START STOP” switch is
turned to IGNITION ON mode (vehicles with a smart key system) o r the
engine switch is turned to the “ON” position (vehicles without a smart key
system), have it check ed your Toyota dealer.

4045-2. Steps to take in an emergency
WARNING■
If the tire pressure wa rning light comes on
Be sure to observe the following precautions. Failure to do so could
cause loss of vehicle control and result in death or serious in jury.●
Stop your vehicle in a safe plac e as soon as possible. Adjust t he tire
inflation pressure immediately.●
If the tire pressure warning light comes on even after tire inf lation pres-
sure adjustment, it is probable that you have a flat tire. Chec k the tires.
If the tire is flat, change to the spare tire and have the flat tire repaired
by the nearest Toyota dealer.●
Avoid abrupt maneuvering and braking. If the vehicle tires dete riorate,
you could lose control of the s teering wheel or the brakes.■
If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

5
When trouble arises
4055-2. Steps to take in an emergency
WARNING■
Maintenance of the tires
Each tire, including the spare (if provided), should be checked monthly
when cold and inflated to the inflation pressure recommended by the
vehicle manufacturer on the vehicle placard or tire inflation p ressure
label (tire and load information label). (If your vehicle has t ires of a differ-
ent size than the size indicated on the vehicle placard or tire inflation
pressure label [tire and load information label], you should de termine the
proper tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire
pressure monitoring system (TPMS -tire pressure warning system) that
illuminates a low tire pressure telltale (tire pressure warning light) when
one or more of your tires is significantly under-inflated. Acco rdingly,
when the low tire pressure telltale (tire pressure warning ligh t) illumi-
nates, you should stop and check your tires as soon as possible , and
inflate them to the proper press ure. Driving on a significantly under-
inflated tire causes the tire to overheat and can lead to tire failure.
Under-inflation also reduces fuel efficiency and tire tread lif e, and may
affect the vehicle's han dling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a sub-
stitute for proper tire maintenance, and it is the driver's res ponsibility to
maintain correct tire pressure, even if under-inflation has not reached the
level to trigger illumination of the TPMS low tire pressure tel ltale (tire
pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warning
system) malfunction indicator to indicate when the system is no t operat-
ing properly. The TPMS (tire pressure warning system) malfuncti on indi-
cator is combined with the low tire pressure telltale (tire pre ssure
warning light). When the system detects a malfunction, the tell tale will
flash for approximately one minut e and then remain continuously illumi-
nated. This sequence will continue upon subsequent vehicle star t-ups as
long as the malfunction exists. When the malfunction indicator is illumi-
nated, the system may not be able to detect or signal low tire pressure
as intended.

4065-2. Steps to take in an emergency
WARNINGTPMS (tire pressure warning system) malfunctions may occur for a vari-
ety of reasons, including the installation of replacement or al ternate tires
or wheels on the vehicle that prevent the TPMS (tire pressure w arning
system) from functioning properl y. Always check the TPMS (tire pres-
sure warning system) malfunctio n telltale after replacing one o r more
tires or wheels on your vehicle to ensure that the replacement or alter-
nate tires and wheels allow the TPMS (tire pressure warning sys tem) to
continue to function properly.
NOTICE■
To ensure the tire pressure warning system operates properly
Do not install tires with different specifications or makers, as the tire
pressure warning system may not operate properly.

5
When trouble arises
4075-2. Steps to take in an emergency
If a warning message is displayed (vehicles with a color multi-information display)
Stop the vehicle immediately. Continuing to drive the vehicle
may be dangerous.
The following warning indicates a possible problem in the brake sys-
tem. Immediately stop the vehicle in a safe place and contact y our
Toyota dealer. Warning message Details
(U.S.A.)
(Canada) Indicates that:
• The brake fluid level is low; or
• The brake system is malfunctioning
A buzzer also sounds.If a warning is shown on the mult i-information display, stay ca lm and
perform the following actions:
Master warning light The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.
Multi-information display
If any of the warning light comes on again after the following
actions have been performed, contact yo ur Toyota dealer.

4085-2. Steps to take in an emergency
Stop the vehicle immediately.
The following warning indicates the possibility of damage to th e vehi-
cle that may lead to an acciden t. Immediately stop the vehicle in a
safe place and contact your Toyota dealer. Warning message Details
(Comes on in red) Indicates that the engine is almost overheating.
(  P. 449)
A buzzer also sounds.
