1131-7. Safety information
1
Before driving ■ Example of the type of accident in which the SRS side airbag an d SRS
curtain shield airbag will most likely deploy
■ Examples of the types of accidents in which the SRS curtain shi eld air-
bag will most likely deploy A severe side impact near the front seat
activates the SRS side airbag and SRS
curtain shield airbag.
The vehicle rolls onto its side or the roof.
The side of the vehicle raises above a
certain threshold or the vehicle skids and
its tires hit a curbstone laterally.

1141-7. Safety information
■ Examples of the types of accidents in which the SRS side airbag and
SRS curtain shield airbag are unlikely to deploy
There are many types of collisions which might not necessarily require SRS
side airbag and SRS curtain shield airbag deployment. In the event of acci-
dents like those illustrated, the SRS side airbag and SRS curta in shield
air-
bag may not deploy depending on the level of accident forces in volved.
The vehicle is involved in an oblique side-
on impact.
The vehicle is involved in a side-on
impact in an area outside the vicinity of
the passenger compartment.

1151-7. Safety information
1
Before driving
■ Examples of the types of accidents in which the SRS side airbag is
unlikely to deploy
There are many types of collisions which might not necessarily require SRS
side airbag deployment. In the event of an accident like those illustrated, the
SRS side airbag may not deploy depending on the level of accide nt force
involved. The vehicle strikes a telephone pole or
similar object.
The vehicle is involved in a side-on
impact from a motorcycle.
The vehicle rolls onto its side or roof.

1161-7. Safety information
■ Examples of the types of accidents in which the SRS side airbag and
SRS curtain shield airbag will basically not deploy
The SRS side airbag and SRS curtain shield airbag are not desig ned to
deploy in most cases if the vehicle is involved in a frontal co llision, is struck
from behind or pitches end over end. Examples of such accidents are illus-
trated. The vehicle is involved in frontal collision
with another vehicle (moving or station-
ary).
The vehicle is struck from behind.
The vehicle pitches end over end.

1171-7. Safety information
1
Before driving In an accident where the vehicle is struck from the side more t han once, the
SRS side airbag and SRS curtain shield airbag deploy only once on the first
impact.
Example: In the case of a double side impact collision, first w ith one vehicle
and immediately followed by another from the same direction, on ce the SRS
side airbag and SRS curtain shield airbag are activated on the first impact,
they will not be activated on the second. SRS curtain shield airbag
SRS side airbagSecond impact First impact

1181-7. Safety information
WARNING■ If the SRS airbags deploy
Do not touch the SRS side airbag system components around the f ront seat
seatback with bare hands right after deployment. Doing so can c ause burns
because the components can be very hot as a result of deployment.
After deployment, do not touch any part of the SRS curtain shie ld airbag sys-
tem (from the front pillar to the part of the roof side over th e rear seat). Doing
so can cause burns because the components can be very hot as a result of
deployment.
■ SRS side airbag and SRS curtain shield airbag precautions
The SRS side airbag and SRS curtain shield airbag are designed only to be
a supplement to the primary protection provided by the seat bel t. They do
not do away with the need to fasten seat belts. It is also impo rtant to wear
your seat belt to help avoid injuries that can result when an occupant is not
seated in a proper upright position.

1191-7. Safety information
1
Before driving ■ When to contact your Toyota dealer
In the following cases, the vehicle will require inspection and /or repair. Con-
tact your Toyota dealer as soon as possible.
● Any of the SRS airbags have been inflated.
● The front of the vehicle is damaged or
deformed, or was involved in an acci-
dent that was not severe enough to
cause the SRS airbags to inflate.
● A portion of a door is damaged or
deformed, or the vehicle was involved
in an accident that was not severe
enough to cause the SRS side airbags
and curtain shield airbags to inflate.
● The pad section of the steering wheel
or dashboard is scratched, cracked, or
otherwise damaged.
● The surface of the seats with the side
airbag is scratched, cracked, or other-
wise damaged.

1201-7. Safety information
WARNING■ SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
● The driver and all passengers in the vehicle must wear their se at belts
properly.
The SRS airbags are supplemental devices to be used with the seat belts. ● The portion of the front pillars, rear pil-
lars or roof side rail garnishes (padding)
containing the curtain shield airbags
inside is scratched, cracked or other-
wise damaged.
