2019 TOYOTA 86 Owners Manual

1291-7. Safety information
1
Before driving
Condition and operation in t he front passenger occupant
classification system *1
■ Adult *2
■ Child restraint system with infant *6, *7, *8Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
ON”
SRS warning light Off
Front passenger’s seat belt reminder light
Flashing *3
Devices Front passenger airbag
OnFront side airbag *4
Front curtain shield airbag *4
Front passenger’s seat belt pretensioner *4
Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
OFF” *9
SRS warning light
Off
Front passenger’s seat belt reminder light
Devices Front passenger airbag Off
Front side airbag *4
On
Front curtain shield airbag *4
Front passenger’s seat belt pretensioner *4The front passenger’s frontal airbag ON and OFF indicators show
you the status of the front pass enger’s SRS frontal airbag. Whe n
the engine switch is turned to “ ON” position (vehicles without a
smart key system), or the “ENGINE START STOP” switch to IGNI-
TION ON mode (vehicles with a smart key system), both the ON
and OFF indicators illuminate whil e the system is checked, afte r
which both indicators turn off.
After that, one of the indicators illuminates depending on the status
of the front passenger’s SRS frontal airbag determined by the
Toyota advanced frontal airbag monitoring system.

1301-7. Safety information
■ Child *5, *7
■ Unoccupied
■ There is a malfuncti on in the systemIndicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
OFF” or “AIR
BAG ON” *5
SRS warning light Off
Front passenger’s seat belt reminder light Off or
flashing *3, *5
Devices Front passenger airbag Off or on *5
Front side airbag *4
On
Front curtain shield airbag *4
Front passenger’s seat belt pretensioner *4
Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
OFF”
SRS warning light
Off
Front passenger’s seat belt reminder light
Devices Front passenger airbag Off
Front side airbag *4
On
Front curtain shield airbag *4
Front passenger’s seat belt pretensioner *4
Indicator/
warning light “AIR BAG ON” and “AIR BAG OFF”
indicator lights “AIR BAG
OFF”
SRS warning light On
Front passenger’s seat belt reminder light Off
Devices Front passenger airbag Off
Front side airbag *4
On
Front curtain shield airbag *4
Front passenger’s seat belt pretensioner *4

1311-7. Safety information
1
Before driving *1
: The occupant classification system does not operate during sel f-
checking.*2
: The system judges a person of adult size as an adult. When a
smaller adult sits in the front passenger seat, the system may not
recognize him/her as an adult depending on his/her physique and
posture.*3
: In the event the front pass enger does not wear a seat belt.*4
: The front passenger’s SRS side airbag, SRS curtain shield airb ag
and seat belt pretensioner are not controlled by the occupant
classification system.*5
: For some children, child in seat, child in booster seat or chi ld in
convertible seat, the system may not recognize him/her as a
child. Factors which may affect this can be the physique or pos -
ture.
Children who have outgrown a child restraint system should
always wear the seat belt when sitting in the seat irrespective of
whether the airbag is deactivated or activated.*6
: When a child restraint system is installed on the front passen ger
seat, do not place any article on the seat other than the child
occupant and a child restraint system.
Failure to do so may prevent the front passenger occupant class i-
fication system from functioning correctly or cause the system to
fail.*7
: Do not place more than one child on the front p assenger seat.
Failure to do so may prevent the front passenger occupant class i-
fication system from functioning correctly.*8
: Never install a rear-facing child restraint system on the fron t pas-
senger seat. See the caution that follows regarding installatio n of
a child restraint system. (  P. 1 4 1 )*9
: In case the indicator is not illuminated, consult this manual on
how to installing the child res traint system properly. (  P. 141)

1321-7. Safety information
If the passenger’s frontal airbag OFF indicator illuminates and the ON indicator
turns off even when the front passenger’s seat is occupied by a n adult
This can be caused by an adult incorrectly sitting in the front passen-
ger’s seat. Perform the following.
Vehicles without a smart key system:
The engine switch is turned to the “LOCK” position.
Vehicles with a smart key system:
Turn the “ENGINE START STOP” switch off.
Ask the front passenger to set the seatback to the upright
position, sit up straight in the center of the seat cushion, co r-
rectly wear the seat belt, position his/her legs out forward, a nd
adjust the seat to the rearmost position.
Vehicles without a smart key system:
The engine switch is tur ned to the “ON” position.
Vehicles with a smart key system:
Turn the “ENGINE START STOP” switch to IGNITION ON
mode.
If the OFF indicator remains illuminated while the ON indicator
remains off, perform the following.
• Vehicles without a smart key system:
The engine switch is turned to the “LOCK” position.
Vehicles with a smart key system:
Turn the “ENGINE START STOP” switch off.
• Make sure that the front passenger is not using a blanket,
seat cushion, seat cove r or seat heater, etc.
• If wearing excessive layers o f clothing, the front passenger
should remove any unnecessary items before sitting in the
front passenger seat, or s hould sit in a rear seat.STEP 1
STEP 2
STEP 3
STEP 4

1331-7. Safety information
1
Before driving The engine switch is turned to the “ON” position (vehicles
without a smart key system), or the “ENGINE START STOP”
switch to IGNITION ON mode (vehicles with a smart key sys-
tem). After the self-check is performed, the ON indicator
should illuminate while the OFF indicator remains off. If the
OFF indicator still remains illumi nated while the ON indicator
remains off, ask the occupant to move to the rear seat and
immediately contact your Toyo ta dealer for an inspection.STEP 5

1341-7. Safety information
If the front passenger’s frontal airbag ON indicator illuminate s and the OFF indicator turns off
even when an infant or a small child is in a child restraint system (including booster seat)
This can be caused by the child restraint system being installe d incor-
rectly. Perform the following.
Vehicles without a smart key system:
The engine switch is turned to the “LOCK” position.
Vehicles with a smart key system:
Turn the “ENGINE START STOP” switch off.
Remove the child restraint system from the seat. By referring
to the child restraint manufacturer’s recommendations as well
as the child restraint system in stallation procedure in “child
restraint system”, correctly rein stall the child restraint syst em.
Vehicles without a smart key system:
The engine switch is turned to the “ON” position and make
sure that the front passenger’s frontal airbag ON indicator
turns off and the OFF indicator illuminates.
Vehicles with a smart key system:
Turn the “ENGINE START STOP” switch to IGNITION ON
mode and make sure that the front passenger’s frontal airbag
ON indicator turns off and t he OFF indicator illuminates.
If the ON indicator still remains illuminated while the OFF ind i-
cator turns off, perform the following.
• Ensure that no article is pla ced on the seat other than the
child restraint system and the child occupant.
• Ensure that the backward-fo rward position and seatback of
front passenger seat are locked into place securely by mov-
ing the seat back and forth.
If the ON indicator still remains illuminated while the OFF ind i-
cator turns off after taking the relevant corrective actions
described above, relocate the child restraint system to the
rear seat and immediately contact your Toyota dealer for an
inspection.STEP 1
STEP 2
STEP 3
STEP 4
STEP 5

1351-7. Safety information
1
Before driving WARNING■ Front passenger occupant cl assification system precautions
Observe the following precautions regarding front passenger occ upant clas-
sification system.
Failure to do so may cause the occupant classification system t o not function
correctly, resulting in death or serious injury.
● Wear the seat belt properly.
● Do not apply excessive force to the seat.
● Do not put sharp object(s) on the seat or pierce the seat uphol stery.
● Do not put objects under the front passenger seat.
● Do not use a seat accessory, such as a cushion or seat cover, t hat covers
the seat cushion surface.
● Do not spill liquid on the front passenger seat. If liquid is s pilled, wipe it off
immediately and dry the seat. If the airbag warning light illum inates, dry
the seat until the warning light turns off. If the airbag warni ng light stays on
even when the seat has dried, do not allow anyone to sit on the front pas-
senger seat and have the system checked by your Toyota dealer. If the air-
bag warning light does not illuminate, check that the airbag ON /OFF
indicator light works properly. If the indicator light does not work properly,
do not allow anyone to sit in the front passenger’s seat and ha ve the sys-
tem inspected by your Toyota dealer.
● Do not remove or disassemble the front passenger seat. Also, do not
replace or modify the seat upholstery or foam inside the seat.
● Do not install any accessory (such as an audio amplifier) other than a gen-
uine Toyota accessory under the front passenger’s seat.
● Do not place a magnetized items near the seat belt buckle.

1361-7. Safety information
WARNING■ Front passenger occupant classification system precautions
● Never install a rearward facing child seat in the front passeng er’s seat
even if the front passenger’s SRS frontal airbag is deactivated . Be sure to
install it in the rear seat in a correct manner. Also, it is st rongly recom-
mended that any forward facing child seat or booster seat be in stalled in
the rear seat, and that even children who have outgrown a child restraint
system be also seated in the rear seat. This is because childre n sitting in
the front passenger’s seat may be killed or severely injured should the
front passenger’s SRS frontal airbag deploy. Toyota believes th at the rear
seats are the safest place for children
● If luggage or electronic devices are placed on the front passen ger seat,
the OFF indicator may turn off and the ON indicator may illumin ate. If this
occurs, the front passenger’s airbag may deploy during a collision. If this is
not desirable, remove the luggage or electronic devices from th e front pas-
senger seat.
● Modifications for persons with disabilities that may affect the front passen-
ger occupant classification system. (U.S. only) Removing, repla cing or
modifying any parts of the front seats, seat belts, front bumpe r, front side
frame, instrument panel, combination meter, steering wheel, ste ering col-
umn, tires, suspension or floor panel can affect the operation of the Toyota
front passenger occupant classification system.
