2017 TOYOTA C-HR Owners Manual

1372. Instrument cluster
2
Instrument cluster
C-HR_OM_Europe_OM10528E
NOTICE
■During setting up the display
To prevent battery discharge, ensure that the engine is running while setting
up the display features.

1382. Instrument cluster
C-HR_OM_Europe_OM10528E
Fuel consumption information
Navigation/multimedia system
: If equipped
Fuel consumption information can be displayed on the naviga-
tion/multimedia system.

1392. Instrument cluster
2
Instrument cluster
C-HR_OM_Europe_OM10528E
Press on the navigation/
multimedia system.
Select “Trip information”.
■Trip information screen
Average vehicle speed since
the engine was started.
Cruising range ( P. 141)
Fuel consumption in the past
15 minutes
Elapsed time since the
engine was started.
Resetting the consumption
data
Vehicles without a smart entry & start system:
Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the engine
switch was last turned to the “ON” position. Use the displayed aver-
age fuel consumption as a reference.
Vehicles with a smart entry & start system:
Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the engine
switch was last turned to IGNITION ON mode. Use the displayed
average fuel consumption as a reference.
These images are examples only, and may vary slightly from actual con-
ditions.
Trip information
1
2
1
2
3
4
5

1402. Instrument cluster
C-HR_OM_Europe_OM10528E
Press on the navigation/
multimedia system.
Select “Past record”.
■Past record screen
Best recorded fuel consump-
tion
Previous fuel consumption
record
Average fuel consumption
Updating the average fuel
consumption data
Resetting the past record
data
The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last updated.
Use the displayed average fuel consumption as a reference.
These images are examples only, and may vary slightly from actual con-
ditions.
Past record
1
2
1
2
3
4
5

1412. Instrument cluster
2
Instrument cluster
C-HR_OM_Europe_OM10528E
■Updating the past record data
Update the average fuel consumption by selecting “Update” to measure the
current fuel consumption again.
■ Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.

1422. Instrument cluster
C-HR_OM_Europe_OM10528E

143
3
Operation of
each component
C-HR_OM_Europe_OM10528E
3-1. Key information
Keys ................................... 144
3-2. Opening, closing and
locking the doors
Side doors.......................... 155
Back door........................... 165
Smart entry & start
system ............................. 171
3-3. Adjusting the seats
Front seats ......................... 186
Rear seats ......................... 188
Head restraints .................. 190
3-4. Adjusting the steering
wheel and mirrors
Steering wheel ................... 194
Inside rear view mirror ....... 196
Outside rear view
mirrors ............................. 198
3-5. Opening and closing
the windows
Power windows .................. 201

1443-1. Key information
C-HR_OM_Europe_OM10528E
Keys
The following keys are provided with the vehicle.
Vehicles without a smart entry & start system (type A)
Key (with a wireless remote
control function)
Operating the wireless remote con-
trol function ( P. 145)
Key (without a wireless remote
control function)
Key number plate
Vehicles without a smart entry & start system (type B)
Keys
Operating the wireless remote con-
trol function ( P. 145)
Key number plate
Vehicles with a smart entry & start system
Electronic keys
• Operating the smart entry &
start system ( P. 171)
• Operating the wireless remote
control function ( P. 145)
Mechanical keys
Key number plate
The keys
1
2
3
1
2
1
2
3
