2006 NISSAN X-TRAIL Owners Manual

Hold the bottom of the antenna and remove by
turning counterclockwise.
CAUTION

Be sure that antenna is removed be-
fore the vehicle enters an automatic
car wash.

Be sure to fold down the antenna
before the vehicle enters a garage
with a low ceiling.4-18
Heater, air conditioner and audio systems


06.4.14/T30-J/V5.0


FM-AM RADIO WITH CASSETTE
PLAYER AND COMPACT DISC (CD)
CHANGER1. CD LOAD button
2. SEEK/APS REW, APS FF/TRACK
ADJUSTING button
3. AUTOP (Automatic preset) button
4. SCAN tuning button
5. CD PLAY button
6. TAPE PLAY button
7. FM/AM band select button
8. DOLBY button
9. RPT (Repeat) play button
10. RADIO TUNE/FF⋅REW/AUDIO (Bass,
treble, fader, balance) ADJUSTING button
11. CD EJECT button
12. PWR (Power)/VOL (Volume) control knob
13. Audio/Clock display
14. Station and preset (radio)/CD insert or CD
play select button
15. TAPE EJECT button
16. MENU (Bass, treble, fader, balance, clock)
button
SAA0830
Heater, air conditioner and audio systems
4-19


06.4.14/T30-J/V5.0


Audio main operationHead unit:
The tape deck employs a permalloy head which
allows for improved reproduction of high fre-
quency ranges. Noise is also greatly reduced by
the use of the Dolby NR (Noise Reduction)
system. The auto loudness circuit enhances the
low frequency range automatically in both radio
reception and tape and CD playback.
PWR/Volume control:
Turn the ignition key to ACC or ON, and then
push the PWR/VOL (Volume) control knobwhile
the system is off to call up the mode (radio, tape
or CD) which was playing immediately before
the system was turned off. When no CD or tape
is loaded, the radio will come on. While the
system is on, pushing the PWR/VOL control
knobturns the system off.
To turn the radio off, press the PWR/VOL
control knob.
Turn the PWR/VOL control knobto adjust the
volume.
MENU button:
Press the MENU button to change the selecting
mode as follows.BASS→TREBLE→FADER→BALANCE→
CLOCK ON/OFF→(clock adjustment)→
RADIO→BASS
See “CLOCK” in the “2. Instruments and con-
trols” section for the clock adjustment.
To adjust Bass, Treble, Fader and Balance,
press the MENU button until the desired mode
(BASS, TREBLE, FADER or BALANCE) ap-
pears in the display. Press the TUNE (
,
) or SEEK (
,
) button to adjust
Bass and Treble to the desired level. Use the
TUNE or SEEK button also to adjust Fader or
Balance modes. Fader adjusts the sound level
between the front and rear speakers and Bal-
ance adjusts the sound between the right and
left speakers.
AUDIO
MODEAUDIO CONTROL
ADJUSTING BUTTON
or
Center
position
or
BASS
(bass ad-
justment)BAS −5 BAS 0 BAS +5
TREBLE
(treble
adjust-
ment)TRE −5 TRE 0 TRE +5
FADER
(front/rear
balance
adjust-
ment)FADR5
(FADER
Rear)FAD 0FADF5
(FADER
Front)
BALANCE
(left/right
balance
adjust-
ment)BALL5
(BALANCE
Left)BAL 0BALR5
(BALANCE
Right)Once you have adjusted the sound quality to the
desired level, press the MENU button repeatedly
until the radio, cassette tape or CD display
reappears. Otherwise, the radio, cassette tape
or CD display will automatically reappear after
about 10 seconds.Radio operation
Radio band select:
Pushing the FM/AM button will change the band
as follows:
AM→FM1→FM2→AM
4-20
Heater, air conditioner and audio systems


06.4.14/T30-J/V5.0


When FM/AM button is pushed while the igni-
tion switch is in the ACC or ON position, the
radio will come on at the station last played.
The last station played will also come on when
the PWR/VOL control knobis pushed to ON.
If a compact disc or tape is playing when the
FM/AM button is turned to ON, the compact
disc or tape will automatically be turned off and
the last radio station played will come on.
TUNE (Tuning):WARNING
The radio should not be tuned while
driving so full attention may be given to
vehicle operation.
Use the TUNE button
or
for manual
tuning. To move quickly through the channels,
hold either side of the TUNE button down for
more than 0.5 seconds.
SEEK tuning:
Pushing the SEEK button
or
tunes
from high to low or low to high frequencies and
stops at the next broadcasting station.
SCANtuning:
Pushing the SCAN tuning button tunes from low
to high frequencies and stops at each broad-
casting station for 5 seconds. Pushing the but-
ton again during this 5 second period will stop
SCAN tuning and the radio will remain tuned to
that station.
If the SCAN tuning button is not pushed within 5
seconds, SCAN tuning moves to the next sta-
tion.
Station memory operations:
Twelve stations can be set for the FM band (six
for FM1, six for FM2) and six stations can be set
for both the AM bands.
1. Tune to the desired station using the SEEK,
SCAN or TUNE button.
2. Select the desired station and keep pushing
any of the desired station/preset buttons (1
to 6) until a beep sound is heard. (The radio
mutes when the station/preset button is
pushed.)
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same manner.
If the battery cable is disconnected, or ifthe fuse blows, the radio memory will be
erased. In that case, reset the desired sta-
tions.
AUTOP
(Automatic preset) button:
To select the preset FM or AM, push the AUTOP
button for less than 1.5 seconds.
To preset the FM or AM, push the AUTOP
button for more than 1.5 seconds.
Cassette tape player operationTurn the ignition key to the ACC or ON position,
and then lightly insert the cassette tape into the
tape door. The cassette tape will be automati-
cally pulled into the player.
The radio or CD will turn off (if it is on) and the
cassette tape will begin to play.
CAUTION
Do not force the cassette tape into the
tape door. This could cause player
damage.
If the system is turned off by pushing the
PWR/VOL control knobwith the cassette tape
still in the player, the tape will resume playing
when the system is turned back on.
Heater, air conditioner and audio systems
4-21


06.4.14/T30-J/V5.0


PLAY:

When the TAPE button is pushed with the
system turned off and a tape loaded, the
system will come on and the tape will play.

When the TAPE button is pushed with either
the radio or compact disc turned on and the
tape loaded, the compact disc or the radio
will automatically be turned off and the tape
will play.

When the TAPE button is pushed with the
TAPE playing, the tape will play the program
recorded on the reverse side.
FF (Fast Forward), REW
(Rewind):
Push the(fast forward) button to fast
forward the tape. To rewind the tape, push the
(rewind) button. Either the FF or REW
symbol illuminates on the right side of the display
window. To stop the FF or REW function, press
the
(fast forward) or
(rewind) again,
or the TAPE button.
APS (Automatic
Program Search) FF,
APS REW:
When the(APS FF) button is pushed
while the tape is being played, the next program
will start to play from the beginning. Push the
(APS FF) button several times to skip
through programs. The tape will advance the
number of times the button is pushed (up to nine
programs).
When the
(APS REW) button is pushed
once, the program being played starts over from
the beginning. Push the
(APS REW) but-
ton several times to skip back several selections.
The tape will go back the number of times the
button is pushed. Either the FF or REW symbol
flashes on the display window while searching
for the selection.
This system searches for the blank intervals
between selections. If there is a blank interval
within one program or there is no interval be-
tween programs, the system may not stop in the
desired or expected location.
SCANtuning:
Push the SCAN tuning button while playing a
tape, and it stops at the next tape program for 5
seconds. Pushing the button again during this 5
second period will stop SCAN tuning and the
tape program is continued. If the SCAN tuning
button is not pushed within 5 seconds, SCAN
tuning moves to the next tape program.Dolby NR (Noise Reduction):
Push the Dolby NR
button for Dolby NR
encoded tapes to reduce high frequency tapenoise. The indicator will come on.
Dolby noise reduction is manufactured under
license from Dolby Laboratories Licensing Cor-
poration. Dolby NR and the double-D symbol
are trademarks of Dolby Laboratories Li-
censing Corporation.
Metal or chrome tape usage:
The cassette player will be automatically set to
high performance play when playing a metal or
chrome cassette tape.
TAPE EJECT:
When this button is pushed with the tape
loaded, the tape will be ejected.
When the tape is ejected while it is being played,
the system will be turned off.
Compact disc (CD) changer
operationTurn the ignition key to the ACC or ON position,
push the LOAD button and insert the compact
disc into the slot with the label side facing up.
The compact disc will be guided automatically
into the slot and will start playing.
After loading the disc, the number of tracks on
the disc will appear on the display.
If the radio or tape is already operating, it will
automatically turn off and the compact disc will
play.
4-22
Heater, air conditioner and audio systems


06.4.14/T30-J/V5.0


CAUTION

Do not force the compact disc into
the slot. This could damage the
player.

Do not use 8 cm (3.1 in) discs.
If the system has been turned off while the
compact disc was playing, pushing the
PWR/VOL control knobwill start the compact
disc.
CD LOAD:
To insert a CD in the CD changer, push the
LOAD button for less than 1.5 seconds. Select
the loading slot by pushing the CD insert select
button (1 to 6), then insert the CD.
To insert 6 CDs to the CD changer in succes-
sion, push the LOAD button for more than 1.5
seconds.
The inserted slot numbers will illuminate on the
display.CD PLAY:
When the CD6 (CD play) button is pushed with
the system off and the compact disc loaded, thesystem will turn on and the compact disc will
start to play.
When the CD6 button is pushed with the com-
pact disc loaded with the tape or the radio
playing, the tape or radio will automatically be
turned off and the compact disc will start to play.
FF (Fast Forward), REW
(Rewind):
When the
(fast forward) or
(rewind)
button is pushed while the compact disc is
being played, the compact disc will play while
fast forwarding or rewinding. When the button is
released, the compact disc will return to normal
play speed.
APS (Automatic Program
Search) FF, APS REW:
When the(APS FF) button is pushed
while the compact disc is being played, the next
program from the present one will start to play
from its beginning. Push several times to skip
through programs. The compact disc will ad-
vance the number of times the button is pushed.
(When the last program on the compact disc is
skipped through, the first program will be
played.) When the
(APS REW) button is
pushed, the program being played returns to its
beginning. Push several times to skip back
through programs. The compact disc will go
back the number of times the button is pushed.CD PLAY select button:
To change CD, push the CD play select button
(1 to 6).
SCANtuning:
When the SCAN tuning button is pushed for
less than 1.5 seconds while the CD is being
played, the beginning of all the CD programs in
each track will be played for 10 seconds in
sequence.
When the SCAN tuning button is pushed for
more than 1.5 seconds while the CD is being
played, the first program in all the CDs will be
played for 10 seconds.
Pushing the button again during this 10 second
period will stop SCAN tuning.
If the SCAN tuning button is not pushed within
10 seconds, SCAN tuning moves to the next
disc program.REPEAT (RPT):
When the RPT play button is pushed while the
compact disc is being played, the play pattern
can be changed as follows:
The display shows the following symbols.
Heater, air conditioner and audio systems
4-23


06.4.14/T30-J/V5.0


(no mark): ALL RPT (Repeat)
1DISC: 1 CD RPT
1: 1 TR (Track) RPT
MIX: ALL MIX
1DISC MIX: 1 CD MIX
CD EJECT:
When the CD EJECT button is pushed with the
compact disc loaded, the compact disc will be
ejected.
To eject the disc selected by the CD select
button, push the EJECT button for less than 1.5
seconds.
To eject all the discs in succession, push the
EJECT button for more than 1.5 seconds.
When this button is pushed while the compact
disc is being played, the compact disc will come
out and the system will turn off.
If the compact disc comes out and is not
removed, it will be pulled back into the slot
to protect it.
CD INindicator:
CD IN indicator (inserted slot number) appears
on the display when the CD is loaded with the
system on.
4-24
Heater, air conditioner and audio systems


06.4.14/T30-J/V5.0


FM-AM RADIO WITH COMPACT
DISC (CD) PLAYER1. PRESET ABC button
2. Display3. CD button
4. CD eject button
5. CD insert slot
6. MENU button7. AUDIO button
8. Station select buttons
9. SEEK/TRACK, FF/REV button
10. PWR/VOL control knob
11. BAND select button
Audio main operationPWR/VOL control knob:
Turn the ignition key to the ACC or ON position,
then push the PWR/VOL control knob. If you
listen to the radio with the engine not running,
turn the key to the ACC position. The mode
(radio or CD) that was playing immediately be-
fore the system was turned off resumes playing.
When no CD is loaded, the radio comes on.
Pushing the PWR/VOL control knobagain turns
the system off.
Turn the PWR/VOL control knobto the right to
increase volume or to the left to decrease vol-
ume.
SAA0840
Heater, air conditioner and audio systems
4-25


06.4.14/T30-J/V5.0
