2006 NISSAN X-TRAIL Owners Manual

1. Inside mirror (P.3-11)
2. Room light (P.2-39)/Map light (P.2-41)
3. Power windows (P.2-36)
4. Front seat (P.1-2)
5. Room light (P.2-39)
6. Luggage room light (P.2-41)
7. Fuel-filler door opener lever (P.3-9)
8. Parking brake (P.5-15)
9. Console box (P.2-31)
10. Rear cup holders (P.2-29)
11. Rear seat (P.1-6)
12. LATCH system (P.1-26)
SSI0143
PASSENGER COMPARTMENT0-4
Illustrated table of contents


06.4.14/T30-J/V5.0


1. Side ventilator (P.4-7)
2. Cup holder (P.2-28)
3. Headlight/Turn signal switch/Fog light
switch* (P.2-18)
4. Driver air bag (P.1-37)/Horn (P.2-22)
5. Driver’s box/Power outlet (P.2-25)
6. Driver’s side ventilator (P.4-7)
7. Wiper and washer switch (P.2-15)
8. Center ventilator (P.4-7)
9. Meters and gauges (P.2-3)
10. Audio system*(P.4-14)/Navigation system**
(P.4-2)
11. Hazard warning flasher switch (P.2-21)
12. Passenger air bag (P.1-37)
13. Driving light switch* (P.2-20)
14. Hood release switch (P.3-7)
15. Outside mirror remote control (P.3-12)
16. Instrument brightness control (P.2-19)
17. VDC (Vehicle dynamic control) off switch*
(P.2-23)
18. Fuse box cover (P.8-22)
19. Tilting steering wheel lock lever (P.3-10)
20. Cruise control switch (P.5-16)
21. Ignition switch (P.5-6)
SSI0144
INSTRUMENT PANEL
Illustrated table of contents
0-5


06.4.14/T30-J/V5.0


22. 4WD mode switch* (P.5-19)/SNOW
mode switch* (P.2-23)
23. Rear window/outside mirror defroster
switch (P.2-17)
24. Multi box (P.2-27)
25. Heater/air conditioner control (P.4-8)
26. Glove box (P.2-30)
27. Upper glove box (P.2-30)
* If so equipped
** Refer to the separate Navigation System
Owner’s Manual0-6
Illustrated table of contents


06.4.14/T30-J/V5.0


1. Tachometer (P.2-5)
2. Turn signal indicator (P.2-20)/Hazard indica-
tor (P.2-21)
3. Speedometer (P.2-4)
4. Fuel gauge (P.2-6)
5. Engine coolant temperature gauge (P.2-5)
6. Warning/Indicator lights (P.2-7)
7. Odometer (Total/Twin trip) (P.2-4)/Clock
(P.2-24)
8. Reset button for trip odometer (P.2-4)/Clock
adjustment (P.2-24)
9. Automatic Transmission (AT) shift position
indicator* (P.5-10)
* If so equipped
SIC2394
METERS AND GAUGES
Illustrated table of contents
0-7


06.4.14/T30-J/V5.0


1. Power steering fluid reservoir (P.8-14)
2. Engine oil filler cap (P.8-11)
3. Automatic transmission fluid dipstick
(*1) (P.8-13)
4. Brake and clutch (*2) fluid reservoir
(P.8-14)
5. Air cleaner (P.8-18)
6. Window washer fluid reservoir (P.8-15)
7. Engine coolant reservoir (P.8-8)
8. Engine oil dipstick (P.8-10)
9. Radiator cap (P.8-9)
10. Fuse/Fusible link holder (P.8-22)
11. Battery (P.8-16)
*1: For Automatic Transmission (AT) model
*2: For Manual Transmission (MT) model
SDI1947
ENGINE COMPARTMENT CHECK
LOCATIONS0-8
Illustrated table of contents


06.4.14/T30-J/V5.0


1 Safety — Seats, seat belts and supple-
mental restraint systemSeats ........................................................................................ 1-2
Front manual seat adjustment ..................................... 1-2
Lumbar support (for driver’s seat) .............................. 1-4
Front power seat adjustment (if so equipped for
driver’s seat) ..................................................................... 1-4
Rear seat adjustment ..................................................... 1-6
Head restraint adjustment (for front seats) ............... 1-9
Active head restraint (for front seats) ..................... 1-10
Armrest ........................................................................... 1-10
Seat belts ............................................................................. 1-11
Precautions on seat belt usage ................................ 1-11
Child safety .................................................................... 1-14
Pregnant women .......................................................... 1-15
Injured persons ............................................................. 1-15
Three-point type seat belt with retractor ............... 1-15
Rear center seat belt .................................................. 1-19
Seat belt extenders ...................................................... 1-19
Seat belt maintenance ................................................ 1-19
Child restraints ................................................................... 1-20Precautions on child restraints ................................. 1-20
Child restraint installation on rear seat center or
outboard positions ....................................................... 1-21
LATCH (Lower Anchors and Tethers for
CHildren) system .......................................................... 1-26
Top tether strap child restraint ................................. 1-28
Child restraint installation on front passenger
seat .................................................................................. 1-29
Booster seats ....................................................................... 1-32
Precautions on booster seats .................................... 1-32
Booster seat installation on rear seat outboard
or center positions ........................................................ 1-35
Booster seat installation on front passenger
seat.................................................................................... 1-36
Supplemental restraint system ....................................... 1-37
Precautions on supplemental restraint system ..... 1-37
Supplemental air bag warning labels ...................... 1-47
Supplemental air bag warning light ......................... 1-47


06.4.14/T30-J/V5.0


WARNING

Do not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident
you could be thrown into it and re-
ceive neck or other serious injuries.
You could also slide under the lap
belt and receive serious internal
injuries.
For the most effective protection
when the vehicle is in motion, the
seat should be upright. Always sit
well back in the seat and adjust the
seat belt properly. See “Precautions
on seat belt usage” later in this sec-
tion.
FRONT MANUAL SEAT
ADJUSTMENT
WARNING

Do not adjust the driver’s seat while
driving so full attention may be given
to vehicle operation. The seat may
move suddenly and could cause loss
of control of the vehicle.

After adjustment, gently rock in the
seat to make sure it is securely
locked.
SSS0133B
SEATS1-2
Safety — Seats, seat belts and supplemental restraint system


06.4.14/T30-J/V5.0


Forward and backwardPull the lever up
1
while you slide the seat
forward or backward to the desired position.
Release the lever to lock the seat in position.
RecliningTo recline the seatback, pull the lever up
2and
lean back. To bring the seatback forward again,
pull the lever and move your body forward. The
seatback moves forward.
The reclining feature allows adjustment of the
seatback for occupants of different sizes to help
obtain proper seat belt fit. See “Precautions on
seat belt usage” later in this section. The seat-
back may also be reclined to allow occupants to
rest when the vehicle is parked.
Seat lifter (for driver’s seat)Turn the dial and adjust the angle and height of
the seat cushion to the desired position.
SPA1727A
SSS0344
Safety — Seats, seat belts and supplemental restraint system
1-3


06.4.14/T30-J/V5.0
