2006 NISSAN X-TRAIL Owners Manual

CAUTION

The outlet and plug may be hot dur-
ing or immediately after use.

This power outlet is not designed for
use with a cigarette lighter unit.

Do not use with accessories that ex-
ceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.
Use only one power outlet at a time.

Use power outlets with the engine
running to avoid discharging the ve-
hicle battery. (If the engine is
stopped, this could result in a dis-
charged battery.)

Avoid using when the air conditioner,
headlights or rear window defroster
is on.

Before inserting or disconnecting a
plug, be sure to turn off the power
switch of electrical accessory being
used or the ACC power of the vehicle.

Push the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tem-
perature fuse may blow.

When not in use, be sure to replace
the cover. Do not allow water to con-
tact the socket.
DRIVER’S BOXTo open the driver’s box, push the button and
pull up the lid.
To close, push the lid down.
WARNING
Keep the lid of the box closed while
driving to help prevent injury in an acci-
dent or a sudden stop.
SIC1710A
Luggage room
SIC2400
STORAGE
2-26
Instruments and controls


06.4.14/T30-J/V5.0


MULTI BOX
Drink boxYou can store unopened beverages in the box.
To keep the beverage warm or cool, open thesliding panels, allow the air to come in by pulling
the air flow control knob
1, and put the drink in
the box. Then close the sliding panels.
To put in a 500 m
can or plastic beverage
bottle, push the holder switch2
and place it at
an angle.
WARNING
Do not put in or take out objects from
the drink box/pocket while driving so
that full attention may be given to ve-
hicle operation.
CAUTION

Do not drive with the sliding panels
open. Objects inside may come out,
and this may result in unexpected
injuries.

Do not leave carbonated beverages
inside because the temperatures in a
closed vehicle could easily become
high if the engine is stopped on hot
days.
Avoid abrupt starting or braking
when the multi box is being used.

Do not spill the drink. It may cause
damage to the vehicle.

The temperature of the inside of the
box is the same as that of the airflow.
It cannot change the temperature of
the drink extremely.
SIC2357B
Instruments and controls
2-27


06.4.14/T30-J/V5.0


PocketYou can use the box as a pocket.
Open the sliding panels, and shut the air flow by
pushing the air flow control knob
1. Put an
object in the box, then close the sliding panels.

Do not put any objects that can melt in
the pocket. An object may damage the
vehicle if it melts.

Do not leave any plastic objects. They
may be deformed.

Do not put in jewelry such as rings,
earrings and so on, because they maybe deformed by heat.
CUP HOLDERS
WARNING
The cup holder should not be used while
driving so full attention may be given to
vehicle operation.
CAUTION

Avoid abrupt starting and braking
SIC2995
SIC2955
Front
2-28
Instruments and controls


06.4.14/T30-J/V5.0


when the cup holder is being used to
prevent spilling the drink. If the liquid
is hot, it can scald you or your pas-
senger.

Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.
FrontWhile the air conditioner is cooling the air, drinks
can be kept cold.

Open the cover and put a drink in it.

Pull up the knob
A
to keep the drink cold.

Push down the knobB
when the cooling
function is not used.

When a high temperature is set or the air
conditioner is warming the air, the cooling
function will not work even if the knobis
pulled up.

The temperature of the inside of the holder is
the same as that of the air blowing from the
air conditioner. The drink cannot be cooler
than the temperature set by air conditioner.
The cap of a plastic beverage bottle can be
put beside the holder.
Rear
Pull out the cover to use the cup holders.

Push them in when they are not being used.
CAUTION

Store them when they are not used.
Be careful not to stumble or not to
hook anything while they are being
used. An unexpected accident may
occur.
SIC2281A
Rear
Instruments and controls
2-29


06.4.14/T30-J/V5.0


The rear cup holders should be
stored when the rear seat is folded
down.
GLOVE BOXTo open the glove box, pull the handle
1.
To close, push the lid in until the lock latches.
To lock
2
or unlock
3
the glove box, use the
master key.
WARNING
Keep glove box lid closed while driving
to help prevent injury in an accident or a
sudden stop.
UPPER GLOVE BOXPull up the lid to open the upper glove box.
Push down the lid to close the upper glove box.
WARNING
Keep upper glove box lid closed while
driving to prevent injury in an accident
or a sudden stop.
SIC2282A
SIC2283
2-30
Instruments and controls


06.4.14/T30-J/V5.0


CAUTION
Please do not forcibly open the upper
glove box lid upward. The lid might be
damaged.
CONSOLE BOX
WARNING

The center console box should not be
used while driving so full attention
may be given to vehicle operation.

Keep the center console box lid
closed while driving to prevent injury
in an accident or a sudden stop.
To open the console box, pull up the lid
1.To close, push the lid down.
The console box lid can be used as an armrest.
Slide the box forward or backward
2
to the
desired position.
CAUTION
Do not place valuable items in the cen-
ter console box.
SIC1719A
Instruments and controls
2-31


06.4.14/T30-J/V5.0


CAUTION

Make sure the luggage floor board
closes securely.
Do not drive with the luggage floor
board removed.

Do not load heavy luggage when the
spare tire is removed. It may cause
damage to the luggage floor board.
To open the luggage floor board, push in the
front edge, then pull up the lever.
To open the luggage side box, pull up the knob.
SPA1725A
SPA1334A
LUGGAGE FLOOR BOARD LUGGAGE SIDE BOX2-32
Instruments and controls


06.4.14/T30-J/V5.0


WARNING

Always make sure that the luggage is
properly secured. Use the suitableropes and hooks.

Unsecured luggage can become dan-
gerous in an accident or sudden stop.
CARGO NETThe cargo net helps keep packages in the cargo
area from moving around while your vehicle is
driven.
To install the cargo net, attach the hooks to the
retainers.
To remove the cargo net, detach the hooks from
the cargo net retainers.
SIC2401
SIC2284
LUGGAGE HOOKS
Instruments and controls
2-33


06.4.14/T30-J/V5.0
