be followed.For additional information, see the
separate Service and Maintenance Guide.BRAKE BOOSTERCheck the brake booster function as follows:
1. With the engine off, press and release the
brake pedal several times. When brake pedal
movement (distance of travel) remains the
same from one pedal application to the next,
continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without de-
pressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradually
with each depression as the vacuum is re-
leased from the booster.
If the brakes do not operate properly, see a
NISSAN dealer.Some vehicles are equipped with engine com-
partment and passenger compartment fuse
boxes that use only type
A
fuses. Other ve-
hicles are equipped with typeA
fuses in the
engine compartment fuse box and type
Bfuses
in the passenger compartment fuse box.
Type
Afuses are provided as spare fuses. They
are stored in the passenger compartment fuse
box.
Type
A
fuses can be installed in the engine
compartment and passenger compartment fuse
boxes.If a type
A
fuse is used to replace a type
B
fuse, the type
A
fuse will not be level with the
fuse pocket as shown in the illustration. This will
not affect the performance of the fuse. Make
sure the fuse is installed in the fuse box securely.
Type
B
fuses cannot be installed in the under-
hood fuse boxes. Only use type
A
fuses in the
underhood fuse boxes.
SDI1751
SDI1752
FUSES
8-22
Maintenance and do-it-yourself


06.4.14/T30-J/V5.0


ENGINE COMPARTMENT
CAUTION
Never use a fuse of higher or lower
amperage rating than that specified on
the fuse box cover. This could damage
the electrical system or cause a fire.If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition switch and headlight
switch are OFF.
2. Open the engine hood.
3. Remove the fusible link cover.
4. Remove the fuse with the fuse puller.
5. If the fuse is open
A, replace it with a new
fuse
B.
6. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.
Fusible linksIf any electrical equipment does not operate and
fuses are in good condition, check the fusible
links. If any of these fusible links are melted,
replace only with genuine NISSAN parts.
SDI1928
SDI1753
Type A
SDI1754
Type B
Maintenance and do-it-yourself
8-23


06.4.14/T30-J/V5.0


PASSENGER COMPARTMENTIf any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and the headlight
switch are OFF.
2. Pull to open the fuse box lid.
3. Pinch the fuse straight with the fuse puller
A
and pull it out.
4. If the fuse is open, replace it with a new fuse.
5. If a new fuse also opens, have the electrical
system checked and repaired by a NISSAN
dealer.Replace the battery as follows:
1. Open the lid using a suitable tool
A.
2. Replace the battery with a new one.
Recommended battery: CR2025 or equiva-
lent
SDI1934
SPA1374E
KEYFOB BATTERY
REPLACEMENT
8-24
Maintenance and do-it-yourself


06.4.14/T30-J/V5.0


Make sure that the
⊕
side faces the
bottom case
B.
3. Close the lid securely.
4. Push the keyfobbutton two or three times to
check its operation.
See a NISSAN dealer if you need any assistance
for replacement.
If the battery is removed for any reason
other than replacement, perform step 4
above.

Be careful not to touch a circuit board
and a battery terminal.

An improperly disposed battery can
harm the environment. Always confirm
local regulations for battery disposal.

The keyfob is water-resistant; however,
if it does get wet, immediately wipe
completely dry.

When changing batteries, do not let
dust or oil get on the keyfob.
FCC Notice:
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.This device complies with RSS-210 of In-
dustry Canada and Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received, in-
cluding interference that may cause undes-
ired operation of the device.
Maintenance and do-it-yourself
8-25


06.4.14/T30-J/V5.0


1. Clearance light
2. Headlight/Daytime running light
3. Front turn signal light/Front park light
4. Front fog light (if so equipped)
5. Map light/Room light
6. Side turn signal light
7. Driving light (if so equipped)
8. Front side marker light
9. Room light
10. Stop/tail light
11. Luggage room light
12. Rear turn signal light
13. High-mounted stop light
14. Back-up light
15. License plate light
16. Step light
17. Rear side marker light
SDI1933
LIGHTS8-26
Maintenance and do-it-yourself


06.4.14/T30-J/V5.0


HEADLIGHTS
ReplacingThe headlight is a semi-sealed beam type which
uses a replaceable headlight (halogen) bulb. A
bulb can be replaced from inside the engine
compartment without removing the headlight
assembly.
CAUTION

High pressure halogen gas is sealed
inside the halogen bulb. The bulb
may break if the glass envelope is
scratched or the bulb is dropped.

When handling the bulb, do not touch
the glass envelope.

Do not touch the bulb.

Use the same number and wattage as
originally installed:
Bulb no. (Wattage)
H4 (60/55W) - Halogen low/high-
beam

Do not leave the bulb out of theheadlight reflector for a long period
of time as dust, moisture, and smoke
may enter the headlight body and
affect the performance of the head
light.
1. Disconnect the battery negative cable.
2. Disconnect the electrical connector from the
rear end of the bulb.
3. Pull off the rubber cap
1.
4. Push and turn the retaining pin
2
to loosen
it.
5. Remove the headlight bulb. Do not shake or
rotate the bulb when removing it.
6. Install the new bulb in the reverse order of
removal.
SDI1946
Maintenance and do-it-yourself
8-27


06.4.14/T30-J/V5.0


HEADLIGHT AIMThe aim of the headlights may require adjust-
ment when replacing the headlight assembly or
when the vehicle’s front body has been repaired.
When the adjustment is required, follow these
procedures, or have them adjusted by a NISSAN
dealer.
Before performing the headlight aim adjustment:

Check the pressure of all tires for the correct
inflation pressure.

Check that the tools and spare tire are
stowed securely.
Check that the fuel and lubricants levels are
filled to correct capacities.

Unload all luggage and other items, which
may influence the vehicle’s height level.

Load a weight on the driver’s seat that is
equivalent to the weight of a driver.
Stopping the vehicle1. Park the vehicle on a level surface vertical to
the wall or screen to which the headlights will
be projected.
2. Move the vehicle close to the wall to deter-
mine the point P as shown in the illustration.The point P must be:
“H” is the distance between the headlight
center point to the level surface.
“W
L” is the distance between the left and
right headlight centers.
3. Mark point P on the wall or screen.
4. Back up the vehicle 5,000 mm (197.0 in,
16.4 ft) straight away from the wall or screen.
“L” is the distance between the wall or screen
to the vehicle’s front bumper.
5. Apply the parking brake.
SDI1664A
SDI1665
8-28
Maintenance and do-it-yourself


06.4.14/T30-J/V5.0


Be sure that the vehicle is parked directly vertical
to the wall on which the headlights will be
projected.Adjusting the headlight aim1. Turn on the headlight low beam.
2. Open the hood.
3. Turn the aiming adjustment screws
1
2,
located inside the engine compartment, until
the headlight projection, on the wall or
screen, does not move.
NOTE:
The aim adjustment screws are locatedon each side of the headlights. The
lower screw
1
is used to adjust the
horizontal aim. The upper screw
2
is
used to adjust the vertical aim.
The screws can be turned indefinitely in
each direction. Therefore be sure to ob-
serve the headlight projection move-
ment to determine the necessary turn-
ing amount.
4. Turn the lower screws
1
in the opposite
direction until the headlight projection be-
comes 70 mm (2.76 in) below the point P.
Once the left headlight has been adjusted,
perform right side adjustment as well.
“C” is the distance between point P and point
3.
5. Turn the upper screws
2
in the opposite
direction until the horizontal headlight projec-
tion’s turn point
3is directly below the point
P. Once the left headlight has been adjusted,
perform right side adjustment as well.
SDI1666A
Maintenance and do-it-yourself
8-29
