3 Pre-driving checks and adjustmentsKeys ......................................................................................... 3-2
NISSAN Vehicle Immobilizer System keys ............... 3-2
Door locks .............................................................................. 3-3
Locking with key ............................................................. 3-3
Locking with inside lock knob..................................... 3-3
Locking with power door lock switch ....................... 3-4
Child safety rear door lock ........................................... 3-4
Remote keyless entry system ............................................ 3-5
How to use remote keyless entry system ................ 3-5
Battery replacement ....................................................... 3-6
Hood ........................................................................................ 3-7Back door ............................................................................... 3-7
Fuel-filler door ....................................................................... 3-9
Opening fuel-filler door ................................................. 3-9
Fuel-filler cap ................................................................... 3-9
Steering wheel .................................................................... 3-10
Tilt operation .................................................................. 3-10
Mirrors ................................................................................... 3-11
Inside rearview mirror .................................................. 3-11
Outside rearview mirrors ............................................ 3-12
Vanity mirror ................................................................... 3-13


06.4.14/T30-J/V5.0


1. Master key (x2)
2. Key number plate
A key number plate is supplied with your keys.
Record the key number and keep the key num-
ber plate in a safe place except in the vehicle. If
you lose your keys, see an NISSAN dealer for
duplicates by using the key number.
A key number is only necessary when you have
lost all keys and do not have one to duplicate
from. If you still have a key, a NISSAN dealer can
duplicate it.
NISSAN VEHICLE IMMOBILIZER
SYSTEM KEYSYou can only drive your vehicle using the master
or valet keys which are registered to the NISSAN
Vehicle Immobilizer System components in your
vehicle. These keys have a transponder chip in
the key head.
The master key can be used for all the locks.
The valet key cannot be used for glove box lock.
To protect belongings when you leave a key with
someone, give them the valet key only.
Never leave these keys in the vehicle.
NVIS KEY — Master key:
If you still have a key, the key number is not
necessary when you need extra NISSAN Vehicle
Immobilizer System keys. Your NISSAN dealer
can duplicate it. As many as 5 NISSAN Vehicle
Immobilizer System keys can be used with one
vehicle. You should bring all the registered keys
that you have to a NISSAN dealer for registra-
tion. This is because the registration process will
erase all memory of the NISSAN Vehicle Immo-
bilizer System components. After the registration
process, these components will only recognize
keys coded into the NISSAN Vehicle Immobilizer
System during registration. Any key that is not
given to your dealer at the time of registration will
no longer be able to start your vehicle.
CAUTION
Do not allow the NISSAN Vehicle Immo-
bilizer System key, which contains an
electrical transponder, to come into
contact with salt water. This could affect
system function.
SPA1981A
KEYS3-2
Pre-driving checks and adjustments


06.4.14/T30-J/V5.0


WARNING

Always have the doors locked while
driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from uninten-
tionally opening the doors, and will
help keep out intruders.

Before opening any door, always
look for and avoid oncoming traffic.

Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls.
Unattended children could become
involved in serious accidents.
LOCKING WITH KEYThe power door lock system allows you to lock
or unlock all doors simultaneously.

Turning the driver’s door key to the front of
the vehicle
1
will lock all doors (including
the back door).

Turning the driver’s door key one time to the
rear of the vehicle2
will unlock the driver’s
door. From that position, returning the key to
neutral (where the key can only be removed
and inserted) and turning it to the rear again
within 5 seconds will unlock all doors.
LOCKING WITH INSIDE LOCK
KNOBTo individually lock the doors, move the inside
lock knobto the LOCK
1
position, then close
the door.
To unlock, pull the inside lock knobup to the
UNLOCK
2
position.
When locking the door without a key, be
sure not to leave the key inside the vehicle.
SPA1333A
SPA1814
DOOR LOCKS
Pre-driving checks and adjustments
3-3


06.4.14/T30-J/V5.0


LOCKING WITH POWER DOOR
LOCK SWITCHOperating the power door lock switch will lock
or unlock all doors (driver and front passenger
sides).
To lock the doors, push the power door lock
switch located on the driver’s armrest to the
LOCK position
1
with the driver’s or front
passenger’s door open, then close the door.
When locking the door this way, be certain
not to leave the key inside the vehicle.
To unlock, push the power door lock switch to
the UNLOCK position2.
Lockout protectionWhen the power door lock switch (driver or front
passenger) is moved to the LOCK position
1
with the key in the ignition and any door open, all
doors will lock and unlock automatically. This
helps to prevent the keys from being accidentally
locked inside the vehicle.
CHILD SAFETY REAR DOOR LOCKThe child safety rear door lock helps prevent
doors from being opened accidentally, espe-
cially when small children are in the vehicle.
When the lever is in the LOCK position
1,
the rear door can be opened only from the
outside.
To disengage, move the lever to the FREE
position
2.
SPA2136
SPA1720A
3-4
Pre-driving checks and adjustments


06.4.14/T30-J/V5.0


It is possible to lock/unlock all doors (including
the back door) and activate the panic alarm by
using the keyfobfrom outside the vehicle.
Before locking the doors, make sure the
key is not left in the vehicle.
The keyfobcan operate at a distance of approxi-
mately 10 m (33 ft) from the vehicle. (The
effective distance depends upon the conditions
around the vehicle.)
As many as five keyfobs can be used with one
vehicle. For information concerning the purchase
and use of additional keyfobs, contact a NISSAN
dealer.
The keyfobwill not function when:

the battery is discharged,

the distance between the vehicle and the
keyfobis over 10 m (33 ft).
The panic alarm will not activate when the
key is in the ignition switch.
CAUTION
The following conditions or occurrences
will damage the keyfob.

Do not allow the keyfob to become
wet.
Do not drop the keyfob.

Do not strike the keyfob sharply
against another object.

Do not place the keyfob for an ex-
tended period in an area where tem-
peratures exceed 60°C (140°F).
If a keyfob is lost or stolen, NISSAN
recommends erasing the ID code of that
keyfob. This will prevent the keyfob
from unauthorized use to unlock the
vehicle. For information regarding the
erasing procedure, please contact a
NISSAN dealer.
HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM
Locking doors1. Remove the ignition key.*1
2. Close all the doors.*2
3. Push the LOCK button
A
on the keyfob.
4. All the doors will lock.
All of the doors will lock when the LOCK
button on the keyfob is pushed even
though a door remains open and/or the
ignition key is in the ONposition.
SPA1397C
REMOTE KEYLESS ENTRY
SYSTEM
Pre-driving checks and adjustments
3-5


06.4.14/T30-J/V5.0


5. The hazard indicator flashes twice.

When the LOCK button is pushed with all
doors locked, the hazard indicator flashes
twice as a reminder that the doors are already
locked.
*1: Doors lock with the keyfobwhile a key is in
the ignition switch. However, the panic
alarm will not activate when the key is in the
ignition switch.
*2: Doors lock with the keyfobwhile any door is
open. However, hazard indicator and horn
mode will not function.Unlocking doors1. Push the UNLOCK button
B
on the keyfob
once.

The driver’s door unlocks

The hazard indicator flashes once if all doors
are completely closed with the ignition key in
any position except the ON position.

The interior light turns on and the light timer
activates for 30 seconds when the switch is
in the DOOR or centerposition with the
ignition key in any position except the ON
position.
2. Push the UNLOCK button
B
on the keyfob
again within 5 seconds.
All doors unlock

The hazard indicator flashes once if all doors
are completely closed.
If the following operation is not carried out
within 5 minutes after pressing the
UNLOCK button, all doors will be locked
automatically.

any door is opened.

the ignition key is turned to the ON
position
The interior light can be turned off without
waiting for 30 seconds by turning the ignition
switch to the ON position or by locking the
doors with the keyfob.
Using the panic alarmIf you are near your vehicle and feel threatened,
you may activate the alarm to call attention as
follows:
1. Push the PANIC button
Con the keyfobfor
longer than 0.5 seconds.
2. The theft warning alarm and headlights will
stay on for 30 seconds.
3. The panic alarm stops when:

It has run for 30 seconds, or
The LOCK or the UNLOCK button is
pressed, or

The PANIC button is pushed on the keyfob
for more than 0.5 seconds.
BATTERY REPLACEMENTSee the “8. Maintenance and do-it-yourself”
section for battery replacement.
3-6
Pre-driving checks and adjustments


06.4.14/T30-J/V5.0


1. Pull the hood lock release handle
1
located
below the instrument panel; the hood will
then spring up slightly.
2. Move the lever
2
at the front of the hood
with your fingertips and raise the hood.
3. Insert the assist bar3
into the slot in the
front edge of the hood.
4. When closing the hood, reset the assist bar
to its original position, then slowly close the
hood and make sure it locks into place.
WARNING

Make sure the hood is completely
closed and latched before driving.
Failure to do so could cause the hood
to fly open and result in an accident.

If you see steam or smoke coming
from the engine compartment, to
avoid injury do not open the hood.
The power door lock system allows you to
lock or unlock all doors including the back
door simultaneously.

Pull the opener handle to open the back door.
WARNING
Do not drive with the back door open.
This could allow dangerous exhaust
gases to be drawn into the vehicle. See
“Precautions when starting and driving”
in the “5. Starting and driving” section
SPA1817
SPA1722A
