2006 NISSAN X-TRAIL Owners Manual

4. Before driving, be sure the brake warning
light goes out.
WARNING

Be sure the parking brake is fully
released before driving. Failure to do
so can cause brake failure and lead
to an accident.

Do not release the parking brake
from outside the vehicle.

Do not use the gear shift in place of
the parking brake. When parking, be
sure the parking brake is fully en-
gaged.

Do not leave children unattended in a
vehicle. They could release the park-
ing brake and cause an accident.
WARNING
Do not use the cruise control when driv-
ing under the following conditions:

it is not possible to keep the vehicle
at a set speed.

in heavy traffic or in traffic that varies
in speed.

on winding or hilly roads.

on slippery roads (rain, snow, ice,
etc.).

in very windy areas.
Doing so could cause a loss of vehicle
control and result in an accident.
CAUTION
On manual transmission models, do not
shift into N(Neutral) without depressing
the clutch pedal when the cruise control
is set. Should this occur, depress the
clutch pedal and turn the main switch
off immediately. Failure to do so maycause engine damage.
PRECAUTIONS ON CRUISE
CONTROL
If the cruise control system malfunctions, it
cancels automatically. The SET indicator light
on the meter panel then blinks to warn the
driver.

If the SET indicator light blinks, turn the
cruise control main switch off and have the
system checked by a NISSAN dealer.

The SET indicator light may blink when the
cruise control main switch is turned on while
pushing the ACCEL/RES, SET/COAST, or
CANCEL switch (located on the steering
wheel). To properly set the cruise control
system, perform the preceding steps in the
order indicated.
CRUISE CONTROL
5-16
Starting and driving


06.4.14/T30-J/V5.0


1. MAIN (ON⋅OFF) switch
2. RESUME/ACCELERATE switch
3. CANCEL switch
4. SET/COAST switchCRUISE CONTROL OPERATIONSThe cruise control allows driving at a speed
between 40 to 144 km/h (25 to 89 MPH)
without keeping your foot on the accelerator
pedal.
To turn on the cruise control,push the main
switch on. The CRUISE indicator light on the
meter panel will come on.
To set at cruising speed,accelerate yourvehicle to the desired speed, push the
SET/COAST switch and release it. (The SET
indicator light will come on.) Take your foot off
the accelerator pedal. Your vehicle will maintain
the set speed.

To pass another vehicle,depress the ac-
celerator pedal. When you release the pedal,
the vehicle will return to the previously set
speed.

The vehicle may not maintain the set speed
when going up or down steep hills. If this
happens, drive without the cruise control.
To cancel the preset speed,follow either of
these three methods:
a) Push the cancel switch; The SET indicator
light will go out.
b) Tap the brake pedal; The SET indicator light
will go out.
c) Turn the main switch off. Both the CRUISE
indicator and SET indicator lights will go out.

If you depress the brake pedal while pushing
the ACCEL/RES set switch and reset at the
cruising speed, turn the main switch off once
and then turn it on again.

The cruise control will automatically be can-
celled if the vehicle slows down below ap-
proximately 13 km/h (8 MPH).
Move the selector lever to N (Neutral) posi-
tion. The SET indicator light will go out.
To reset at a faster cruising speed,use one
of the following three methods:
a) Depress the accelerator pedal. When the
vehicle attains the desired speed, push and
release the SET/COAST switch.
b) Push and hold the ACCEL/RES set switch.
When the vehicle attains the speed you
desire, release the switch.
c) Push, then quickly release the ACCEL/RES
set switch. Each time you do this, the set
speed will increase by about 1.6 km/h (1
MPH).
To reset at a slower cruising speed,use one
of the following three methods:
a) Lightly tap the brake pedal. When the vehicle
attains the desired speed, push the
SET/COAST switch and release it.
b) Push and hold the SET/COAST switch. Re-
lease the switch when the vehicle slows
down to the desired speed.
c) Push, then quickly release the SET/
COAST switch. Each time you do this, the set
speed will decrease by about 1.6 km/h (1
MPH).
SSD0397
Starting and driving
5-17


06.4.14/T30-J/V5.0


To resume the preset speed,push and re-
lease the ACCEL/RES set switch. The vehicle
will resume the last set cruising speed when the
vehicle speed is over 40 km/h (25 MPH).
CAUTION
During the first 2,000 km (1,200 miles),
follow these recommendations to ob-
tain maximum engine performance and
ensure the future reliability and
economy of your new vehicle. Failure to
follow these recommendations may re-
sult in shortened engine life and re-
duced engine performance.

Avoid driving for long periods at constant
speed, either fast or slow. Do not run the
engine over 4,000 rpm.

Do not accelerate at full throttle in any gear.

Avoid quick starts.

Avoid hard braking as much as possible.

Do not tow a trailer for the first 800 km (500
miles).
Accelerate slowly and smoothly. Maintain
cruising speeds with a constant accelerator
position.

Drive at moderate speeds on the highway.
Driving at high speed will lower fuel economy.

Avoid unnecessary stopping and braking.
Maintain a safe distance behind other ve-
hicles.

Use a proper gear range which suits road
conditions. On level roads, shift into high gear
as soon as possible.

Avoid unnecessary engine idling.

Keep your engine tuned up.

Follow the recommended periodic mainte-
nance schedule.

Keep the tires inflated at the correct pres-
sure. Low pressure will increase tire wear and
waste fuel.

Keep the front wheels in correct alignment.
Improper alignment will cause not only tire
wear but also lower fuel economy.

Air conditioner operation lowers fuel
economy. Use the air conditioner only when
necessary.

When cruising at highway speeds, it is more
economical to use the air conditioner andBREAK-IN SCHEDULE INCREASING FUEL ECONOMY
5-18
Starting and driving


06.4.14/T30-J/V5.0


leave the windows closed to reduce drag.
The ALL MODE 4X4 system is used to select
2WD, AUTO or LOCK depending on the driving
conditions.
ALL MODE 4X4 system electronically controls
the coupling. Move the 4WD mode switch to
select 2WD, AUTO or LOCK.
WARNING
A vehicle equipped with 4WD (Four-
Wheel Drive) should never be tested
using a two wheel dynamometer, orsimilar equipment. Make sure you in-
form the test facility personnel that your
vehicle is a 4WD equipped vehicle be-
fore it is placed on a dynamometer.
Failure to do so may result in transmis-
sion damage or unexpected vehicle
movement which could result in serious
vehicle damage or personal injury.
SSD0349A
4WD MODE SWITCH
USING FOUR-WHEEL DRIVE
(4WD) (if so equipped)
Starting and driving
5-19


06.4.14/T30-J/V5.0


4WD mode switch Wheels driven4WD mode indicator light
(
,
) Use conditions
2WDFront wheels
The wheel drive mode is in
Two-Wheel Drive (2WD) when
driving on the normal road.*1Goes offFor driving on dry, paved
roads (Economy drive)
AUTODistribution of torque to the
front and rear wheels changes
automatically, depending on
road conditions encountered
[ratio; 100 : 0 (2WD)→50 :
50 (4WD)]. This results in im-
proved driving stability.
For driving on paved or
slippery roads
LOCK Four-Wheel Drive (4WD)*2
/
For driving on rough
roads
*1: 2WD mode may change to 4WD mode automatically during quick acceleration.
The 4WD mode indicator light does not illuminate.
*2: LOCK mode will change to AUTO mode automatically, when the vehicle is accelerated.
4WD MODE SWITCH OPERATIONSThe 4WD mode switch electronically controls
the coupling. Move the switch to select between
each mode, 2WD, AUTO and LOCK, depending
on driving conditions.
WARNING
Depending on the driving condition, the
4WD mode may automatically changefrom 2WD to 4WD even when the 2WD
mode switch is selected.*
Do not start engine while in the 2WD,
AUTO or LOCK mode in the following
cases:

When on a free-roller or jacking up
the front tires with the rear tires on
the ground.

When towing with the rear tires
raised from the ground.
* The 4WD mode indicator light does not illumi-
nate even if the mode automatically changes
from 2WD to 4WD while driving.
4WD shift tips
If the 4WD mode switch is operated while
making a turn, accelerating or decelerating,
or if the key switch is turned off while in the
AUTO or LOCK, you may feel a jerk. This is
normal.

The oil temperature of power train parts will
increase if the vehicle is continuously oper-
ated under conditions where the difference in
rotation between the front and rear wheels is
large (wheels slip) by driving the vehicle
5-20
Starting and driving


06.4.14/T30-J/V5.0


off-road through sand, mud or water or free-
ing a stuck vehicle. In this case, the 4WD
warning light blinks rapidly and the 4WD
mode changes to the 2WD mode to protect
the power train parts. If you stop driving with
the engine idling and wait until the warning
light stops blinking, the 4WD returns to the
AUTO mode.

Brake distance in the 4WD mode is the same
as 2WD.

Even if the mode automatically changes to
the AUTO mode when driving with the LOCK
mode selected, the indicator light stays in the
LOCK mode.
WARNING

Do not place a 4WD equipped vehicle
on a two wheel dynamometer or raise
two wheels off the ground and shift
the transmission to any D (drive) or R
(reverse) position. Doing so may re-
sult in transmission damage or unex-
pected vehicle movement which
could result in serious vehicle dam-
age or personal injury.
When driving straight, shift the 4WD
lock switch to 2WD, AUTO or LOCK.
Do not operate the 4WD lock switch
when making a turn or reversing.

Do not operate the 4WD mode switch
(2WD, AUTO and LOCK) with the front
wheel spinning.

Engine idling speed is high while
warming up the engine. Be especially
careful when starting or driving on
slippery surfaces with the 4WD lock
switch set in AUTO.
4WD WARNING LIGHTThe 4WD warning light is located in the instru-
ment panel.
The 4WD warning light comes on when the key
SSD0142B
Starting and driving
5-21


06.4.14/T30-J/V5.0


switch is turned to ON. It turns off soon after the
engine is started.
If any malfunction occurs in the 4WD system
when the key switch is ON, the warning light will
either remain illuminated or blink.
High-temperature power-train oil makes the
warning light blink rapidly (about twice per sec-
ond). The driving mode will change to 2WD.
AUTO mode may change to LOCK mode before
the warning light blinks. This is normal. If the
warning light blinks rapidly during operation,
stop the vehicle in a safe place immediately.
Then if the light goes off after a while, you can
continue driving.
A large difference between the diameters of
front and rear wheels will make the warning light
blink slowly (about once per two seconds). Pull
off the road in a safe area, and idle the engine.
Check that all tire sizes are the same, tire
pressure is correct and tires are not worn.
Change the 4WD mode switch into 2WD and
do not drive fast.
WARNING
Do not attempt to test a 4WD equipped
vehicle with two wheels on a two wheeldynamometer and the other two wheels
raised. Doing so may result in transmis-
sion damage or unexpected vehicle
movement which could result in serious
vehicle damage or personal injury.
CAUTION

If the 4WD warning light comes on
while driving, AUTO or LOCK mode
will be changed to two-wheel drive
condition. Reduce the vehicle speed
and be especially careful when driv-
ing. Have your vehicle checked by a
NISSAN dealer as soon as possible.

Never drive on dry hard surface roads
in the LOCK mode, as this will over-
load the power-train and may cause a
serious malfunction.

The power-train may be damaged if
you continue driving with the warning
light blinking rapidly.
5-22
Starting and driving


06.4.14/T30-J/V5.0


WARNING

Do not stop or park the vehicle over
flammable materials such as dry
grass, waste paper or rags. They may
ignite and cause a fire.

Never leave the engine running while
the vehicle is unattended.

Never leave children unattended in
the vehicle.1. Firmly apply the parking brake.
2.Manual transmission models:
Place the shift lever in the R (Reverse) posi-
tion. When parking on an uphill grade, place
the shift lever in the 1st position.
Automatic transmission models:
Move the automatic transmission selector
lever to the P (Park) position.
WARNING

Safe parking procedures require that
both the parking brake be set and the
transmission be placed into P (Park)
for automatic transmission models
or in an appropriate gear for manual
transmission models. Failure to do
so could cause the vehicle to move
unexpectedly or roll away and result
in an accident.

Make sure the automatic transmis-
sion selector lever has been pushed
as far forward as it can go and cannot
be moved without depressing the
button on the side of the lever.
3. To help prevent the vehicle from rolling into
the street when parked on a sloping drive
way, it is a good practice to turn the wheels
as illustrated.

HEADED DOWNHILL WITH CURB:
1
Turn the wheels into the curband move the
vehicle forward until the curbside wheel
gently touches the curb.
SSD0067C
PARKING/PARKING ON HILLS
Starting and driving
5-23


06.4.14/T30-J/V5.0
