2006 MERCEDES-BENZ ML500 Owner's Manual

304 OperationDriving instructionsML 350
ML 500
Your vehicle is factory equipped with
“H”-rated tires, which have a speed rating
of 130 mph (210 km/h).
An electronic speed limiter prevents your
vehicle from exceeding a speed of
130 mph (210 km/h).
ML 350 (with Sport Package*)
ML 500 (with Sport Package*)
Your vehicle is factory equipped with
“W”-rated tires, which have a speed rating
of 168 mph (270 km/h).
An electronic speed limiter prevents your
vehicle from exceeding a speed of
130 mph (210 km/h).
Winter driving instructions
The most important rule for slippery or icy
roads is to drive sensibly and to avoid
abrupt acceleration, braking and steering
maneuvers. Do not use the cruise control
system under such conditions.
When the vehicle is in danger of skidding,
m ove gea r s el ec tor le ver to pos it ionN. Try
to keep the vehicle under control by
corrective steering action.Road salts and chemicals can adversely af-
fect braking efficiency. Increased pedal
force may become necessary to produce
the normal brake effect.
Depressing the brake pedal periodically
when traveling at length on salt-strewn
roads can bring road-salt-impaired braking
efficiency back to normal.
If the vehicle is parked after being driven
on salt-treated roads, the braking efficien-
cy should be tested as soon as possible af-
ter driving is resumed.
iFor information on speed ratings for
winter tires, see “Winter tires”
(page 369).
For additional general information on
tire speed markings on tire sidewall,
see “Tire speed rating” (
page 367).
iFor information on driving with snow
chains, see “Snow chains”
(page 370).
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of control loss.

305 Operation
Driving instructions
For more information, see “Winter driving”
(page 369).
Standing water
For more information, see “Driving through
water” (
page 310).
Warning!
G
Make sure not to endanger any other road
users when carrying out these braking ma-
neuvers.Warning!
G
If the vehicle becomes stuck in snow, make
sure that snow is kept clear of the exhaust
pipe and from around the vehicle with the
engine running. Otherwise, deadly carbon
monoxide (CO) gases may enter vehicle in-
terior resulting in unconsciousness and
death.
To assure sufficient fresh air ventilation,
open a window slightly on the side of the ve-
hicle not facing the wind.
Warning!
G
The outside temperature indicator is not de-
s i g n e d t o s e r v e a s a n i c e - w a r n i n g d e v i c e a n d
is therefore unsuitable for that purpose. In-
dicated temperatures just above the freez-
ing point do not guarantee that the road
surface is free of ice.
!Do not drive through flooded areas or
water of unknown depth. Before driving
through water, determine its depth.
Never accelerate before driving into
water. The bow wave could force water
into the engine and auxiliary equip-
ment, thus damaging them.
If you must drive through standing wa-
ter, drive slowly to prevent water from
entering the passenger compartment
or the engine compartment. Water in
these areas could cause damage to
electrical components or wiring of the
engine or transmission, or could result
in water being ingested by the engine
through the air intake, causing severe
internal engine damage. Any such dam-
age is not covered by the
Mercedes-Benz Limited Warranty.

306 OperationDriving instructionsOff-road driving
Read this chapter carefully before you be-
gin off-road travel.
Familiarize yourself with the vehicle char-
acteristics and gear changing before you
attempt any difficult terrain off-road driv-
ing. We recommend that you start out with
easy off-road travel.Special driving features for off-road
driving
The following driving features are available
for specific kind of operation:


Off-road – ABS (
page 94)


Off-road – ESP
® (page 98)


Off-road – 4-ETS (
page 99)


Start-off assist system (
page 191)


Downhill Speed Regulation (DSR)
(page 243)


Off-road driving program (
page 248)


Air suspension* (
page 249)
Warning!
G
Drive slowly in unknown terrain. This will
make it easier to recognize unexpected ob-
stacles and avoid damage to the vehicle.
To help avoid the vehicle rolling over, never
turn it around on steep inclines. If the vehi-
cle cannot complete the attempted climb,
back it down in reverse gear.
Do not drive along the side of a slope (dan-
ger of vehicle rollover). The vehicle might
otherwise rollover. If in doing so the vehicle
begins to show a tendency to roll, immedi-
ately steer into a line of gravity (straight up
or downhill).
Never let the vehicle roll backwards in idle.
You may lose control of the vehicle if you
use only the service brake.
Warning!
G
Sand, dirt, mud and other material having
friction property can cause exceptional wear
and tear as well as brake failure.
Have the brakes checked for dirt build-up
and cleaned. There is otherwise a risk that
full braking power may not be available in an
emergency.

307 Operation
Driving instructions
Off-road driving rules

Engage the Off-road driving program
(page 248) before driving under
off-road conditions.


If equipped with vehicle level control*,
make sure you select a vehicle level ap-
propriate to the topographical condi-
tions. Always make sure the vehicle
has enough ground clearance.


Fasten items being carried as securely
as possible (
page 259).


Always navigate gradients with the en-
gine on and with the transmission en-
gaged in a gear. Switch on the DSR
(page 245) to help maintain a preset
speed.Checklist before off-road driving
Engine oil level


Check the engine oil level with the
control system (ML 500 only)
(page 328), or with the oil dipstick
(ML 350 only) (
page 330).
Only with a proper oil level can the
vehicle obtain a trouble-free oil supply,
even on steep gradients.
iWe recommend keeping doors, tail-
gate, windows, and tilt/sliding sun-
roof* closed whenever driving in
off-road mode.
!Observe the following during off-road
driving:

Adjust vehicle speed to condition of
terrain. The more uneven, rutty and
steeper the terrain, the lower the
speed should be.


Watch out for obstacles, such as
rocks, holes, tree stumps and ruts.


Be especially careful when driving
in unknown territory. It may be nec-
essary to get out of the vehicle and
scout the path you intend to take.


Before driving through water, deter-
mine its depth.


Do not stop vehicle while immersed
in water, and do not shut off the
engine.


In sandy soil, please drive at a
steady speed as allowed by condi-
tions. This helps overcome the vehi-
cle rolling resistance and reduces
the likelihood of the vehicle sinking
into the ground.


Do not initiate jumps with the vehi-
cle. It interrupts the forward mo-
mentum of the vehicle.


Always drive onto slopes with the
engine running and the vehicle in
gear.

308 OperationDriving instructionsTires

Check the tread depth and maintain
specified tire inflation pressure
(a placard with the recommended tire
inflation pressures is located on the
driver’s door B-pillar).


Check tires for possible damage and
remove foreign objects.


Replace missing valve caps.
Rims


Dented or bent rims can cause tire in-
flation pressure loss and damage the
tire beads. For this reason, check and,
if necessary, change rims before driv-
ing off-road.
Vehicle tool kit


Check if the vehicle jack is functional.


In all cases take the vehicle tool kit, a
strong tow rope, a shovel and a small
plank (to put under the vehicle jack on
sandy soil) with you.Driving in steep terrain
Slope angle1 Overhange angle, front
2Overhange angle, rear


Switch to Off-road driving program
(page 248) before starting to drive
up or down steep inclines.


Driving on embankments, slopes and
other steep inclines should only be
done straight up or downhill, i.e. in the
line of gravity. Maximum vehicle climb-
ing ability is a 100% grade which is
equivalent to a slope angle of
45 degrees. Keep in mind that the
climbing ability of the vehicle depends
on terrain conditions.


Do not drive along the side of a slope
(danger of vehicle rollover). If in doing
so the vehicle begins to show a tenden-
cy to roll, immediately steer into a line
of gravity (straight up or downhill).
Vehicle with steel
suspension
1
2
31°
29°
Vehicle with Air
suspension
package*
1
2
Raised level
34°
31°
Highway
29°
26°

309 Operation
Driving instructions


To help avoid the vehicle rolling over,
never turn it around on steep inclines.
If the vehicle cannot complete the at-
tempted climb, back it down in reverse
gear. Switch on the DSR (
page 245)
to help maintain a speed when driving
downhill.


Utilize the engine’s braking power
when descending a slope, observe the
engine speed (do not overrev the en-
gine). Apply the service brake as need-
ed.


Check the brakes after a lengthy down-
grade drive.Traction in steep terrain


Be easy on the accelerator and watch
for continuous wheel traction when
driving in steep terrain.
The 4-ETS helps greatly when starting
out on a steep incline when the front
wheels have then the tendency to slip
due to the weight shifting towards the
rear axle.
The 4-ETS recognizes the situation and
limits the torque for the front wheels by
braking them. Simultaneously the
torque for the rear wheels is increased.Driving across a hilltop


Decelerate just ahead of a hilltop (do
not select gear rangeN), to prevent the
vehicle from speeding up too much af-
ter climbing a hill.
Use the momentum of the vehicle to
drive across the hilltop.
Driving in this manner allows the vehi-
cle to maintain ground contact when
cresting hills.
iAvoid excessive engine speeds – drive
with moderate engine speeds
(max. 3 000 rpm).
Select gear range2 or1 on the auto-
matic transmission (
page 187).

310 OperationDriving instructionsDriving downhill

Select gear range1 on the automatic
transmission (
page 187).


Drive downhill observing the same
rules as driving uphill (
page 308).


On steep inclines, use the Downhill
Speed Regulation (
page 243).


Drive slowly.


Do not drive at an angle to the incline.
Steer into the line of gravity and drive
with the front wheels pointing straight
downhill. Otherwise, the vehicle may
slide sideways off the path and roll
over.


Utilize the engine’s braking power to
reduce vehicle speed.
If this is insufficient, apply the brake
gently. Make sure the vehicle is moving
in the line of gravity.


Check the brakes after a lengthy down-
grade drive.Driving through water
1Fording depth


Before driving through water, deter-
mine its depth.
It should not be deeper than approxi-
mately 20 inches (50 cm).
Make sure you check the water bed.
The ground surface may not be firm
which may result in deeper waters than
expected when driving the vehicle
through it.


For vehicles with level control*, raise
the ride height (
page 250) if neces-
sary.


Switch to the Off-road driving program
(page 248) before driving through
water.


Select gear range1 or2 on the
automatic transmission (
page 187).


Avoid high engine speeds.


Drive through the water slowly and at a
constant speed.
Vehicles with steel
suspension
120 in (50 cm)
Vehicles with Air
suspension package*
1
Raised level
20 in (50 cm)

311 Operation
Driving instructions


Switch off the exterior lamps as well as
the automatic climate control.


Enter the water only at a shallow spot,
driving at walking speed.


Do not stop vehicle while immersed in
water, and do not shut off the engine.
There is a very high level of driving re-
sistance in water. The surface is slip-
pery and may not be firm, making
pulling away in water difficult and dan-
gerous.


Clean mud off the tire tread after driv-
ing through water.


To dry the brakes, apply pressure to the
brake pedal several times after leaving
the water.Crossing obstacles!Never accelerate before driving into
the water. The bow wave could force
water into the engine and auxiliary
equipment, thus damaging them.
!Obstacles can damage the vehicle
underbody or suspension components.
If possible use the assistance of a sec-
ond person outside the vehicle to scout
the path you intend to take and check
for adequate ground clearance when
you cross obstacles with your vehicle.
The person assisting you outside the
vehicle should always be a safe dis-
tance away from the vehicle and posi-
tioned so that he or she cannot get hurt
in case of any unexpected vehicle
movement.
After off-road driving or crossing obsta-
cles, inspect vehicle for any damage,
especially vehicle underbody and sus-
pension components. Failure to do so
can adversely affect the vehicle’s fu-
ture performance, including increased
chance of an accident.
