2006 MERCEDES-BENZ ML500 Owner's Manual

248 Controls in detailDriving systems
Release the cruise control lever.
The new speed is set.
Each time the set speed is changed, DSR
will appear in the multifunction dis-
play and the newly set speed is shown.
Off-road driving program
The off-road driving program is designed to
assist the driver when driving off-road in
terrain and crossing water. The off-road
driving program adjusts the engine power
and shifting of the automatic transmission
to be more suitable for the off-road use of
the vehicle. In addition, the ABS, ESP
®,
and 4-ETS designed for off-road use are
automatically activated.
In the following situations you should
switch to the Off-road driving program:


during off-road driving


when crossing water


when towing up or down on steep
gradientsThe switch is located on the lower part of
the center console.
1Switch for Off-road driving program
2Indicator lamp
iThe new speed is set and the vehicle
will accelerate or decelerate. Keep in
mind that it may take a brief moment
until the vehicle has reached the new
set speed.iThe set speed is canceled when DSR is
switched off. If DSR is switched on
again, DSR will use the programmed
default speed (
page 176).


249 Controls in detail
Driving systems
Switching Off-road driving program on
Press switch1 (
page 248).
Indicator lamp2 comes on. The
symboly appears in the lower
multifunction display.
Switching Off-road driving program off

Press switch1 again.
Indicator lamp2 goes out. The
symboly disappears.
Air suspension package*
Air suspension automatically optimizes
your vehicle’s suspension tuning and regu-
lates the vehicle level. The system consists
of two components:

Suspension tuning: Adaptive Damping
System (ADS) (
page 249)


Vehicle level control (
page 250)
Adaptive Damping System (ADS)*
The fine tuning of the damping and suspen-
sion is dependent on:

your driving style


road surface conditions


your personal ADS settings


your personal vehicle level settingsThe switch is located on the lower part of
the center console.
1ADS switch
2Indicator lamp for SPORT setting
3Indicator lamp for COMF setting
The following settings are available:


AUTO (for normal driving situations)
Indicator lamps2 and3 are out.


SPORT (for sporty driving)
Indicator lamp2 comes on.


COMF (for comfort driving)
Indicator lamp3 comes on.

250 Controls in detailDriving systems
Start the engine (
page 34).

Press ADS switch1 repeatedly until
the desired suspension tuning is
reached.
Vehicle level control*
The vehicle level control automatically
regulates the ride height to

reduce fuel consumption


improve driving stability by lowering
the center of gravity
The vehicle automatically regulates its ride
height based on the set vehicle height and
the current speed:


The ride height of the vehicle is re-
duced with increasing vehicle speed.


The ride height of the vehicle changes
from the high-speed level back to the
normal highway level as the vehicle
speed is decreased.
The parked vehicle begins adjusting to the
set vehicle level as soon the doors and tail-
gate are


unlocked
or


opened.
In order to operate the vehicle level control
switch (
page 252), however, the engine
must be running.
For safety reasons, the vehicle lowers only
when all doors are closed. The lowering
procedure is interrupted as soon as a door
is opened. The lowering will resume as
soon as all doors are closed.
iThe setting is stored when you turn off
the engine.
Warning!
G
Please be aware that by raising the vehicle
level, the center of gravity also rises. There-
fore, always ensure that the vehicle level is
as low as possible. With higher ride height
the ESP
® may activate earlier in certain
situations.
Warning!
G
Make sure that no one is near the wheel
housing or under the vehicle when you lower
the vehicle while it is standing still. Limbs
could become wedged into or under the ve-
hicle.
For safety reasons, the vehicle can only be
lowered with the doors closed. Lowering is
interrupted if a door is opened and will con-
tinue after the door is closed again.

251 Controls in detail
Driving systems
!
Keep in mind that in rough or uneven
terrain, adjusting the vehicle to a lower
level may cause the vehicle underbody
to come in contact with the ground and
result in damage to the vehicle under-
body. Always make sure the vehicle
has sufficient ground clearance before
adjusting it to a lower level.!Before jacking up the vehicle with
equipment that lifts one or more of the
wheels completely off of the ground,
remove the SmartKey from the starter
switch.!Please also note the information in the
section on towing (
page 472).
iThe activation thresholds are defined
by the set suspension tuning
(page 249).
iThe high-speed level is not available if
towing a trailer. For more information
on towing a trailer, see “Trailer towing”
(page 314).
iFor off-road driving, please observe the
corresponding section in this manual
(page 306).

252 Controls in detailDriving systems
Setting the vehicle level*
The switch is located on the lower part of
the center console.
1Vehicle level switch
2Indicator lampThe following vehicle chassis ride heights
can be selected using the vehicle level
switch in the center console:
The following is the approximate change in
ride height as compared to the highway
level for each of the level settings:
iThe vehicle is automatically lowered to
the high-speed level when the vehicle
exceeds a certain speed threshold and
is automatically raised to the highway
level when vehicle speed drops below a
certain speed threshold. Note the ex-
ception in the ADS SPORT mode, where
the system disregards the highway lev-
el and automatically lowers the vehicle
to the high-speed level.
In comparison to vehicle behavior
when in the ADS AUTO mode,

the vehicle is lowered to the
high-speed level when set to the
SPORT mode,


and remains at the highway level
over a greater speed range when
set to the COMFORT mode.
Level
Driving situation
Raised
For off-road driving or
driving in rough ter-
rain. The indicator
lamp is on.
Highway/High-
speed
For driving on paved
roads in fair or better
condition. The indica-
tor lamp is off.
Level
Ride height
Raised
+ 3.1 in (80 mm)
Highway
+/- 0 in (0 mm)
High-speed
- 0.6 in (-15 mm)

253 Controls in detail
Driving systems
Setting the raised level
Only select the raised level if appropriate
for the driving situation encountered.
Otherwise:

fuel consumption may increase


handling characteristics of the vehicle
may be unfavorable

Start the engine (
page 34).
If the indicator lamp2 is off:

Press switch1.
Indicator lamp2 flashes. The vehicle
adjusts to the raised level.
The following message appears in the mul-
tifunction display while the level is being
set:When the raised level is reached, the
following message appears in the multi-
function display for five seconds:
Indicator lamp2 (
page 252) comes on
continuously.
You can select the raised level at speeds
up to 40 mph (64 km/h). At higher speeds,
the message
Level selection not
permitted appears in the multifunction
display.Setting the highway/high-speed level

Start the engine (
page 34).
If the indicator lamp2 (page 252) is
on:

Press switch1 (
page 252).
Indicator lamp2 flashes. The vehicle
adjusts to the highway/high-speed
level.
The following message appears in the
multifunction display while the level is
being set:
iThe message can be cleared by press-
ing theèÿk or
buttonj on the multifunction
steering wheel.
iThe message can be cleared by press-
ing theèÿk or
buttonj on the multifunction
steering wheel.


254 Controls in detailDriving systemsWhen the highway/high-speed level is
reached, the following message appears in
the multifunction display for five seconds:
Indicator lamp2 (
page 252) goes out.The following applies additionally when
towing a trailer:


The vehicle is lowered to the highway
level when it reaches a speed of 5 mph
(8 km/h).


The high-speed level is not available.


The restrictions that apply to towing
also apply when using accessories that
are connected to the trailer power
socket, such as an accessory bicycle
rack.
Parktronic* system (Parking assist)
iThe vehicle is lowered to the highway
level if:

the vehicle speed is above 55 mph
(88 km/h)


the speed stays between 40 mph
(64km/h) and 55mph (88km/h)
for approximately 20 seconds
iDepending on the ADS setting
(page 249), the vehicle will be low-
ered to the high-speed level when trav-
eling at higher speeds. At speeds below
40 mph (64 km/h) at the latest, it will
be returned to the highway level.
Warning!
G
Parktronic is a supplemental system. It is
not intended to, nor does it replace, the
need for extreme care. The responsibility
during parking and other critical maneuvers
always rests with the driver.
Special attention must be paid to objects
with smooth surfaces or low silhouettes
(e.g. trailer couplings, painted posts, or road
curbs). Such objects may not be detected by
the system and can damage the vehicle.
The operational function of the Parktronic
system can be affected by dirty sensors, es-
pecially at times of snow and ice. See
“Cleaning the Parktronic system sensors”
(page 377).
Interference caused by other ultrasonic sig-
nals (e.g. working jackhammers, car wash,
or the air brakes of trucks) can cause the
system to send erratic indications, and
should be taken into consideration.


255 Controls in detail
Driving systems
The Parktronic system is an electronic
parking aid and designed to assist the
driver during parking maneuvers. It visually
and audibly indicates the relative distance
between the vehicle and an obstacle.
The Parktronic system is automatically
activated when you switch on the ignition,
release the parking brake, and set the
automatic transmission toD,R, orN.
The Parktronic system deactivates at
speeds over approximately 11 mph
(18 km/h). At lower speeds the Parktronic
system turns on again.
The Parktronic system also deactivates
when you set the automatic transmission
toP or depress the parking brake pedal.The Parktronic system monitors the sur-
roundings of your vehicle with six sensors
in the front bumper and four sensors in the
rear bumper.
1Sensors in the front bumper
Range of the sensors
To function properly, the sensors must be
free of dirt, ice, snow and slush. Clean the
sensors regularly, being careful not to
scratch or damaging the sensors, see
“Cleaning the Parktronic* system sensors”
(
page 377).
Warning!
G
Make sure no persons or animals are in the
area in which you are maneuvering. You
could otherwise injure them.
