2023 GENESIS GV60 Owners Manual

4-28
Instrument Cluster
Stop vehicle and check power
supply
ORG3EVQ011051L
This warning message is displayed when
a failure occurs in the power supply
system.
In this case, park the vehicle in a safe
location and tow your vehicle to the
nearest by an authorized retailer of
Genesis Branded products.
Check virtual engine sound system
OOSEV040512L
This message is displayed when there is
a problem with the Virtual Engine Sound
System (VESS).
In this case, have the vehicle inspected
by an authorized retailer of Genesis
Branded products.
Check electric vehicle system
ORG3EVQ011048L
This warning message is displayed when
there is a problem with the electric
vehicle control system.
Refrain from driving when the warning
message is displayed.
In this case, have the vehicle inspected
by an authorized retailer of Genesis
Branded products.

4-29
04
LCD Display Control
OJWEV071144
The LCD display modes can be changed by using the control switches.
Switch operation Function
Press Analogue / Digital gauge mode change
, Press UP, DOWN switch for changing view mode
PressSelect switch for pop up
Widget navigation mode on/off
Press and holdSelect/reset switch for pop up
Hide/show widget
Tripple press
x3Reset for trip computer
View modes
View modes Explanation
Driving AssistDriving Assist view displays the status of the vehicle’s Driver
Assistance systems.
Map view Show map and navigation related information
AR View Show AR navigation and navigation related information
Normal viewShow trip computer or widget on center without background
information
The information provided may differ depending on which features are applicable to
your vehicle.
LCD DISPLAY

4-30
Instrument Cluster
OJWEV041025E
Driving Assist, Map, AR, Normal View
Mode are displayed in the center of the
instrument cluster.
Driving Assist view
OJWEV041005
The status of Lane Keeping Assist, Smart
Cruise Control, Lane Following Assist,
Highway Driving Assist, etc., is displayed
when Driving Assist view is selected.
For more details, refer to each function
information section in chapter 7.

4-31
04
Widget
In the Widget, using the optical mouse
(), you may change through items in
the following order.
OJWEV041025E
Drive info
This display shows the trip distance, the
average energy consumption, and the
total driving time.
The information is combined for each
ignition cycle.
To manually reset the information, triple
press the (
) button when viewing the
Drive Info. The trip distance, the average
energy consumption, and total driving
time will reset simultaneously.
The driving information will continue to
be counted while the vehicle is in the
ready (
) mode (for example, when
the vehicle is in traffic or stopped at a
stop light.)
Information
The vehicle must be driven for a minimum
of 300 meters (0.19 miles) since the last
ignition key cycle before the driving
information is recalculated.
OJWEV041026E
After Recharging
Trip distance, total driving time and
average energy consumption after
the vehicle has been recharged are
displayed. To reset manually, triple press
the (
) button the steering wheel when
‘After recharging’ is displayed.

4-32
Instrument Cluster
OJWEV041027E
Accumulated info
This display shows the accumulated trip
distance, total driving time and average
energy consumption.
The information is accumulated starting
from the last reset.
To manually reset the information,
triple press the (
) button when
viewing the Accumulated driving info.
The trip distance, the average energy
consumption, and total driving time will
reset simultaneously.
The accumulated driving information
will continue to be counted while the
vehicle is in the ready (
) mode (for
example, when the vehicle is in traffic or
stopped at a stop light).
Information
The vehicle must be driven for a minimum
of 300 meters (0.19 miles) since the last
ignition key cycle before the accumulated
driving information is recalculated.
OJWEV041033L
Tire pressure / Tyre pressure
The tire pressure of each tire is displayed.
For more details, refer to “Tire Pressure
Monitoring System (TPMS)” section in
chapter 8.

4-33
04
OJWEV041008L
Energy flow / Driving force distribution (if
equipped)

[The electric vehicle system informs
the drivers its energy flow in various
operating modes.

[The distribution status of the driving
power of the front and rear wheels are
displayed when Auto 4WD mode is
activated.
For more details, refer to "All Wheel
Drive (AWD)" section in chapter 6.
OJWEV041043E
Driving assist information
The current operation conditions of
Manual Speed Limit Assist, Smart Cruise
Control, Lane Following Assist, Highway
Driving Assist, etc., is displayed.
Option Menu
Press the OK switch to enter Option
menu.
WARNING
To avoid driver distractions, do not
adjust the setting while driving which
may lead to an accident.
Information
The information provided may differ
depending on which functions are
applicable to your vehicle.
Menu Explanation
Driver Assistance
settingsTo directly display
“Driver Assistance”
menu on the
infotainment system
screen

4-34
Instrument Cluster
9(+,&/(6(77,1*6

5
Accessing Your Vehicle ..................................................................................... 5-5Smart Key ...................................................................................................................... 5-5
Immobilizer System .................................................................................................... 5-11
Genesis Digital Key .......................................................................................... 5-12Digital Key (Smart Phone) ...........................................................................................5-12
Digital Key (Card Key) ................................................................................................. 5-18
Personalized Profile and Vehicle Settings ................................................................ 5-22
Used Vehicle/Digital Key Maintenance .................................................................... 5-25
Limitations of the System .......................................................................................... 5-25
Face Connect .................................................................................................. 5-26Face Connect Settings ............................................................................................... 5-26
Face Connect Operation ............................................................................................ 5-28
Limitations of Face Connect...................................................................................... 5-28
When Purchasing a Used Vehicle .............................................................................. 5-29
Legal Compliance ...................................................................................................... 5-29
Fingerprint Authentication System ................................................................ 5-30Fingerprint Authentication System Settings ............................................................5-30
Fingerprint Authentication System Operation ..........................................................5-31
Limitations of the System .......................................................................................... 5-32
Used vehicle ............................................................................................................... 5-32
Over-The-Air Software Update ....................................................................... 5-33Downloading Software .............................................................................................. 5-33
Approving Software Update ...................................................................................... 5-33
Preparing Software Update ....................................................................................... 5-33
Updating Software ..................................................................................................... 5-34
Door Locks ....................................................................................................... 5-36Operating Door Locks from Outside the Vehicle .....................................................5-36
Operating Door Locks from Inside the Vehicle ........................................................ 5-37
Automatic Door Lock and Unlock Features ............................................................. 5-40
Child-protector Rear Door Locks .............................................................................. 5-41
Electronic Child Safety Lock ...................................................................................... 5-41
Vehicle Auto-Shut Off Function ................................................................................5-43
