d Are engine oil and other operating fluids that meet Volkswagen quality and performance require-
ments available where you will be driving? For more information, please see ⇒ Booklet Warranty
and Maintenance.
d Does the factory installed navigation system work in the countries where you will be driving, and is
navigation data available?
d Are special or heavy-duty tires necessary for the kind of driving expected?
.NOTICE
Volkswagen is not responsible for mechanical damage that may result from substandard fuel
or service or the unavailability of Genuine Volkswagen parts.
Driving through water on roads

Technical data

Fig. 16 Vehicle identification number (VIN).

Engine data

Track 1, rear 65.7 inches (1670 mm)
Ground clearance 7.9 inches (200 mm 2)

Hybrid drive vehicle

Length 188.8 inches (4795 mm)
Width 76.4 inches (1940 mm)
Height (unloaded) 68.4 inches (1737 mm)
Wheelbase 113.9 inches (2893 mm)
Minimum turning circle diameter (wall to wall) 1 39 feet (11.9 m)
Track 1, front 64.5 inches (1638 mm)
Track 1, rear 65.3 inches (1658 mm)
Ground clearance 7.9 inches (200 mm) 2

.NOTICE
x Please be CAReful when parking your vehicle in areas with parking barriers or curbs. These
vary in height and could damage your bumper and related parts if the front of your vehicle hits
a barrier or curb that is too high while your are getting into or out of a parking spot.
x Always be CAReful when you enter a driveway or drive up or down steep ramps or over
curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as
bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).

2 Approx. figure for fully loaded standard vehicle; varies depending on your vehicle's equipment (engine,
tires, wheels, tire inflation pressure, driving situation and other factors).

Vehicle key set

Remote control vehicle keys

Fig. 17 Remote control vehicle key with panic button.

.NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
.Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
.Remote control vehicle key functions can be temporarily disrupted by interference from trans-
mitters near the vehicle that use the same frequency range (such as radio equipment or cellular
phones).
.Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
.If the remote control vehicle key buttons or the power locking buttons ⇒ fig. 24 are pushed
repeatedly in quick succession, the power locking system is switched off for a brief period to help keep
it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Emergency key

Fig. 18 Releasing the emergency key and removing it from the remote control vehicle key.

Fig. 19 Releasing the emergency key and removing it from a remote control vehicle key with a panic button.
