Storing telephone numbers to speed dial buttons

Fig. 232 Speed dial settings menu: Assignment of speed dial buttons.

Fig. 233 Telephone control main menu: Newly assigned speed dial button.
.

Dialing with speed dial buttons
x In the PHONE main menu, briefly press an assigned speed dial button to dial the telephone
number stored to that button.
Editing assigned speed dial buttons
x In the PHONE main menu, press and hold an assigned speed dial button until the Speed dial
settings menu opens.
x OR: Access the Speed dial settings menu with the SETUP Infotainment button and in the following
order via the Telephone and Speed dial function keys.
x Press one of the function keys to edit its entry.
x To delete all entries for a speed dial button, press the x To close the speed dial menu without applying changes, press the

Functions during a telephone call

When a connection is made to a dialed telephone number, the PHONE main menu changes to the
telephone call view ⇒ fig. 234.
Holding a call26
x Press the 5function key to “mute” the current telephone call (display: Call being held).
x Press the  function key to resume the call.
While a call is being held, no sound is transmitted. Conversations in the vehicle cannot be heard by
the other party.
Ending a telephone call
x Press the ^ function key to end the current call.
The PHONE main menu is displayed again ⇒ fig. 233.
DTMF tones
Every telephone button has a specific DTMF tone assigned to it. DTMF tones are used, for example,
to send a password or to select an employee in a call center or to access the voice mail.
x If you are asked to enter a sequence of characters during a telephone call, open the keypad by
pressing the ofunction key and enter the characters ⇒ fig. 235.
Making an additional call, “toggling calls” and “call waiting”

Fig. 236 Telephone call with call on hold.
.

“Call waiting”: accepting an additional incoming call
x If another party calls while you are already on the telephone, the new caller's telephone number or
name appears in the second line of the screen (display: Waiting).
x To reject the new call, press the ^function key in the Waiting line.
x OR: To take the new call as an additional call, press the function key  in the Call on hold line.
If you take the new call, the first call is put on hold, but not ended (in .⇒ fig. 236:
Call being held).
“Toggling”: changing between 2 parties
While you have 2 active calls, Call being held is shown in the line of the party who is on hold.
x Press the 5 function key in the Call being held line to resume this call and put the other call
on “hold”.
x OR: To end one of the calls, press the function key ^in the line for that call.
During any call, it is only possible to hold one additional call. Several parties can be brought together
in a conference call .
.If functions such as “toggling” and “conference” are used, the active call is shown first. If a call in
the list is ended, the order of the calls in the list could be refreshed.
Making a conference call

Fig. 237 Adding another party to a conference call.

Fig. 238 Detailed view of a conference call.

.

Settings

Fig. 240 Telephone settings menu.
.
