2013 VOLKSWAGEN TOUAREG Owners Manual

2D: Setting orientation of map
x Press the

Favorite destinations on the map
A favorite category can be specified for stored destinations Favorite destinations can be displayed on
the map with the orange favorite icon assigned to them (private T or business P
The list of favorite destinations is called up from the Destination entry menu .
Points of interest on the map
Points of interest can be selected as a navigation destination .
Points of interest are divided into point of interest categories. These point of interest categories are
assigned to blue point of interest icons (such as as * hotel and , petrol station).A list of
available point of interest categories can be called up from the Map settings menu. Map icons can
be selected there for display .
Display detailed information on points of interest
x Press the symbol on the map briefly to display a window with further information.
Due to the map scale, there may be several entries behind one symbol on the map, in which case a
list appears for selecting an entry.
x Select the required entry by pressing.
Function keys for further operation are displayed in the information window that appears.
x Selecting points of interest and favorite destinations from the map .
x TMC traffic reports on the map .
3D models on the map
An abstract 3D city model can be displayed in the 6 3D display type for some cities (such as Berlin).
In addition, special historical buildings and sights of interest are displayed as photo-realistic 3D
models.
To display these, autozoom needs to be switched off in some cases and you have to zoom further into
the map .
The display of 3D city models and 3D sights of interest is enabled and disabled in the map settings .
.If no symbols or 3D models can be displayed due to the scale, turn the setting knob clockwise
⇒ fig. 123 (3) in order to zoom in on the map.
Map settings: selecting map symbols
.

Function key: effect on map
= 3D landmarks: Photo-realistic 3D models of special historical buildings and landmarks are
displayed10.
= 3D city model: Buildings in cities are displayed as abstract 3D models16.
= P Important destinations (business):Shows favorite destinations from the “business” category that
were selected upon saving with P.
= T Important destinations (private): Shows favorite destinations from the “private” category that were
selected upon saving with T.
= > ...Activated point of interest categories are displayed.


10 Only available for some cities.

Introduction
Before using

Before using the cellular telephone (cell phone) control for the first time, CARry out the
following steps. This will enable you to use the cell phone control safely and make full use of
the functions it provides:
d Follow the basic safety instructions Ü.
d Familiarize yourself with the controls.
d Read the instruction manual of the cell phone or audio player you wish to
pair with the unit.

Safety information
.WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
x Setting the sound volume too high may damage your hearing. This applies even if you are
exposed to high volumes for short periods only.
x Your call may be cut off or you may be unable to make calls if you are in an area with no
cell phone network coverage, an area where the network is very weak or, in some cases, in a
tunnel, garage or underpass. This also means that no emergency calls can be made.
x In some countries, an emergency call is supported only if the cell phone is connected to
the telephone control containing an “unlocked” SIM CARd with sufficient credit or if a valid
SIM CARd is in the SIM CARd reader.
.WARNING
The volume may suddenly get louder change when you switch media source or connect a
new audio source.
x Always lower the volume before switching media source or connecting a new audio
source.

.WARNING
A cell phone on the seat, instrument panel or in other places can be thrown around the inside
of the vehicle during a sudden braking maneuver, a crash or other accident and injure vehicle
occupants.
x Never attach a cell phone to, or place it on, a door, the windshield, or above or near the
areas marked “AIRBAG” on the steering wheel, the instrument panel, and the seat backrests,
or between these areas and the vehicle occupants. The cell phone could cause serious injury
in an accident, especially when the airbags inflate.
.WARNING
Always switch off the cell phone when refueling and in areas with a risk of explosion. The
electromagnetic radiation can cause sparks that can ignite fuel vapors and cause a fire.
x The cell phone can automatically log itself into the cell phone network again when the
Bluetooth® connection to the telephone control is interrupted.
.WARNING
If a cell phone not connected to an external aerial is used in the vehicle, electromagnetic
radiation in the interior could exceed limit values. This also applies if the outside antenna is
not installed properly.
x Heart specialists advise that cell phones can adversely affect the way pacemakers work.
Always keep the cell phone and its integrated antenna at least 8 inches (20 cm) away from a
pacemaker.
x Never CARry a cell phone that is switched on in the breast pocket directly over a
pacemaker.
x If you suspect there may be interference with a pacemaker or other medical device, switch
the cell phone off immediately.
.NOTICE
x Your cell phone and the telephone control must always be switched off in areas where
special regulations apply and when the use of cell phones is forbidden. Radiation from a
switched-on mobile phone can interfere with sensitive technical and medical devices,
potentially causing malfunctions or damage to the devices.
x High speeds, poor weather and road conditions as well as the network quality may impair
telephone calls in the vehicle and lead to loss of connection.
General information
When pairing a cell phone with the telephone control using the hands-free profile (HFP) observe the
information for use of a cell phone in the vehicle without connection to the external aerial .
Only use compatible Bluetooth® devices. Information on compatible Bluetooth products is available
from your Volkswagen dealer or on the Internet.
Follow the operational instructions of the mobile phone and the accessory manufacturer.
You may experience poor reception or may be cut off in areas where the signal is weak.

Most electrical devices are shielded against RF (high-frequency) signals. In rare cases, however,
electronic devices may not be shielded against high-frequency signals emitted by the telephone
control. Interference may occur.
.Some countries may have restrictions regarding the use of Bluetooth devices. Information can
be obtained from the local authorities.
.When connecting the telephone control with a device using Bluetooth, read the device's
operating manual for detailed safety information. Use only Bluetooth-compatible devices.

Description

via a Bluetooth connection. The cell phone logs itself out of the GSM network and logs into the
telephone control using the data from the “borrowed” SIM CARd. The telephone is then controlled
exclusively via the controls in the vehicle. The mobile phone goes into standby mode. This Bluetooth
profile allows all telephone control functions and the exterior aerial to be used to the full.
x Bluetooth Hands-Free Profile (HFP): If a cell phone is connected via HFP to the telephone
control, you can make calls wireless via the hands-free system. Many other telephone control
functions are not available. The vehicle's exterior aerial can thus not be used.
x Advanced Audio Distribution Profile (A2DP): Bluetooth profile for transferring audio signals .
.Volkswagen recommends pairing a cell phone with the telephone control via Bluetooth-rSAP in
order to use all telephone control functions.
Components of the telephone control

Fig. 222 3 button module in the roof: Controls for the telephone control.
.
