2013 VOLKSWAGEN TOUAREG remote control

Remote control vehicle keys

Fig. 17 Remote control vehicle key with panic button.

.NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
.Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
.Remote control vehicle key functions can be temporarily disrupted by interference from trans-
mitters near the vehicle that use the same frequency range (such as radio equipment or cellular
phones).
.Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
.If the remote control vehicle key buttons or the power locking buttons ⇒ fig. 24 are pushed
repeatedly in quick succession, the power locking system is switched off for a brief period to help keep
it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Emergency key

Fig. 18 Releasing the emergency key and removing it from the remote control vehicle key.

Fig. 19 Releasing the emergency key and removing it from a remote control vehicle key with a panic button.

Replacing the remote control vehicle key battery

Fig. 21 Removing battery cover from the remote control vehicle key.

Fig. 22 Opening battery compartment of the remote control vehicle key.
.

Replacing the cover
x Insert the thin left side of the cover ⇒ fig. 21 (2) in the remote control vehicle key and press the
thick right side down until the cover locks into place.
x Reinsert the emergency key into the remote control vehicle key.
.NOTICE
x Changing the battery improperly can damage the remote control vehicle key.
x Using the wrong battery can damage the remote control vehicle key. Replace a dead battery
with a new one that has the same voltage, size, and specifications.
x Make sure the plus and minus poles of the battery are correctly positioned.
.Dispose of old batteries in an environmentally responsible manner and keep them out of the
reach of children.
.Batteries of the type used in your remote control vehicle key may contain Perchlorate Material.
Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding handling and disposal of these batteries. Authorized Volkswagen dealers and
authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that
you have them perform this service for you.
Synchronizing the remote control vehicle key

Locking the vehicle after airbag inflation
If the airbags are activated during a collision, the entire vehicle is unlocked. Depending on the severity
of the damage, the vehicle can be locked after a collision when the airbags have deployed as follows:

Function Action
Locking the vehicle with the
power locking switch:
– Switch the ignition off.
– Open a door once.
– Press power locking switch 1
Locking the vehicle with the
remote control vehicle key:
– Switch the ignition off and on again.
OR: Remove the remote control vehicle key from the ignition.
– Open a door once.
– Lock the vehicle with the remote control vehicle key.

Indicator light in the driver door

After the vehicle is locked: Meaning
The red LED light flashes for about 2 seconds in short
intervals, then slower.
The vehicle is locked.
Red LED light lights up continuously for about 30 se-
conds.
Locking system malfunction. See an
authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.

.If the remote control vehicle key buttons or one of the power locking buttons are pushed repeat-
edly in quick succession, the power locking system is switched off for a brief period to help keep it
from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened during this time, the vehicle is automatically locked afterwards.
Unlocking and locking the vehicle from the outside

Fig. 23 Buttons in the remote control vehicle key.
.

Function Using the buttons on the remote
control vehicle key ⇒ fig. 23
Using the emergency key
Unlock the vehicle. Press the 0 button twice to open all
doors and the rear hatch.
Insert the emergency key into the
driver door lock and turn counter-
clockwise. Keep turned for
convenience opening.
Lock the vehicle. Press the 1 button and keep it
pressed for convenience closing.
Insert the emergency key into the
driver door lock and turn clockwise.
Keep turned for convenience
closing.
Unlock the rear hatch. Press the & button. Insert the emergency key into the
driver door lock and turn counter-
clockwise.

Note: Depending on the settings for the power locking system in the .Comfort sub-menu, it may be
necessary to press the 0 button twice to unlock all doors and the rear hatch.
The remote control vehicle key unlocks and locks the vehicle only when the battery in the remove
control vehicle key have enough power, and the remote control vehicle key is within a few
yards/meters of the vehicle. All turn signals flash to confirm that the vehicle is locked.
x All turn signals flash once and the horn beeps once to confirm that the vehicle has been locked.
The horn beep can be disabled by deactivating the “ATA confirmation” feature in the Convenience
submenu.
x All turn signals flash twice to confirm that the vehicle has been unlocked.
If the turn signals do not flash to confirm locking, one or more doors, the rear hatch or the engine hood
is not locked.
If the driver door is open, the vehicle cannot be locked with the remote control vehicle key.
If the vehicle was unlocked with the remote control vehicle key and the door or the rear hatch has not
been opened in about 30 seconds, the vehicle is automatically locked again. This feature helps pre-
vent the vehicle from staying unlocked unintentionally.
Unlocking and locking the vehicle from the inside

Fig. 24 On all 4 doors: Power locking switch.

Press button ⇒ fig. 24:
0 Unlock the vehicle.
1 Lock the vehicle.

The power locking switch works whether the ignition is switched on or off, but only when all doors are
closed.
If the vehicle is locked with the remote control vehicle key, the power locking switch is deactivated.
If the vehicle is locked with the power locking switch:
The indicator light 1 in the power locking switch comes on to indicate that all doors and the rear hatch
are locked.
x The anti-theft alarm system is not turned on.
x Opening doors or the rear hatch from the outside is not possible, at a traffic light, for example.
x Doors can be unlocked and opened separately from inside the vehicle by pulling the door handle to
open the door. The indicator light 1 goes out. The unopened doors and rear hatch remain locked and
cannot be opened from the outside.
x An open driver door will not be locked. This helps keep the driver from being locked out of the
vehicle.
The vehicle is unlocked if you push the 0 button while the vehicle is standing still. Depending on the
settings in the Convenience sub-menu, it may also be unlocked when you take the vehicle key out of
the ignition or, on vehicles with Keyless Access, when you open the driver door (Auto. open).
Unlocking or locking vehicles with Keyless Access

Fig. 25 (A) Ranges of the Keyless Access locking and starting system. Outside the vehicle: Unlocking range.
Inside the vehicle: starting range. (B) Keyless Access locking and starting system: Sensor 1 for unlocking on
the inside of the front door handles. Sensor for locking on the outside of the door handles 2.

Unlocking and locking the rear hatch (Keyless Entry for the rear hatch)
If the vehicle is locked and a valid vehicle key is within range A of the rear hatch, it unlocks automati-
cally when opened.
x Open and close the rear hatch as you would a standard rear hatch.
The rear hatch locks automatically when it is closed except in the following situations:
x The vehicle is completely unlocked.
x When an authorized vehicle key is inside the vehicle.
Sensor-controlled rear hatch opener (Easy Open)
When a valid vehicle key is within range A of the rear hatch, the rear hatch can be unlocked and
opened by moving your foot within the sensor’s range ⇒ fig. 26 below the rear bumper.
x Switch off the ignition and remove any vehicle key in the ignition.
x Stand in front of the middle of the rear bumper.
x Quickly move the side of your body, your foot and shin as close to the bumper as possible. Your
shin must be in the upper part of the sensor’s range and your foot in the lower part (1).
x Quickly move your shin out of range (2). The rear hatch opens automatically.
The high-mounted brake light and the turn signals flash once to show that the Easy Open feature is
opening the rear hatch.
The rear hatch locks automatically after closing if the vehicle was locked before and a valid vehicle key
is not inside the vehicle. If the vehicle key used to open the vehicle is inside the vehicle, the rear hatch
opens again.
Easy Open may not work properly or at all in the following situations (examples):
x If the rear bumper is very dirty.
x If the rear bumper has salty water on it after driving on salted roads.
x If a trailer hitch has been retrofit on the vehicle.
Easy Open may be automatically deactivated in heavy rain to help prevent unintentional deployment
caused by water running down the vehicle, for example.
Locking with a second vehicle key
If a remote control vehicle key is inside the passenger compartment, the vehicle can be locked from
the outside only if a second valid key is within range.
A key that was inside the vehicle when it was locked from the outside is reactivated:
x By pressing a button on the deactivated key.
x By pressing a door handle sensor when the deactivated key is outside of the vehicle, but within
range.
x By starting the engine with the starter button on the front center console.
Automatic deactivation of sensors
If the vehicle has not been unlocked or locked for a longer period of time, the proximity sensors in the
passenger door are automatically deactivated.
If a sensor on the door handle of a locked vehicle is activated too often, for instance by a bush or
hedge that rubs against the vehicle, the sensors in the door handle on that side of the vehicle are
switched off for 30 minutes.
The sensors become active again when the vehicle is locked with the vehicle key and the ignition is
switched on one time.
The sensors become active again if one of the following events occurs:
x 30 minutes have passed.
x OR: The vehicle is unlocked using the V button in the remote control vehicle key.
