2013 VOLKSWAGEN TOUAREG navigation system

Driver side overview

Fig. 5 Driver side overview.
Key to fig. 5:
(1) Air vents z
(2) Lever for:
– High beams
– Headlight flasher
– Turn signal lights

(3) Multi-function steering wheel controls :
– Volume setting for radio, navigation system notifications, or telephone calls (if applicable)
.& – '
– Mute switching for radio or activation of voice control (if applicable) 
– Display Phone main menu or accept telephone calls -
– Audio, Navigation .Ì –

Upper front center console

Fig. 6 Overview of upper front center console.
Key to fig. 6:
(1) Air vent for indirect ventilation
(2) Storage compartment
(3) Air vents z
(4) Radio or Radio & Navigation system (factory installed)
(5) Controls for:
– Climatronic
– Seat heating switch button A
(6) Located here:
– Switch for emergency flashers
– PASSENGER AIR BAG /&&  light (front airbag for front seat passenger)
– Park Distance Control system button ∗ or ∗

d Are engine oil and other operating fluids that meet Volkswagen quality and performance require-
ments available where you will be driving? For more information, please see ⇒ Booklet Warranty
and Maintenance.
d Does the factory installed navigation system work in the countries where you will be driving, and is
navigation data available?
d Are special or heavy-duty tires necessary for the kind of driving expected?
.NOTICE
Volkswagen is not responsible for mechanical damage that may result from substandard fuel
or service or the unavailability of Genuine Volkswagen parts.
Driving through water on roads

Safety information on Infotainment System
.WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
x Setting the sound volume too high may damage your hearing. This applies even if you are
exposed to high volumes for short periods only.
.WARNING
The volume level may suddenly get louder change when you switch media source or connect
a new audio source.
x Always lower the base volume before switching media source or connecting a new audio
source.
.WARNING
Driving recommendations and traffic symbols displayed by the navigation system may differ
from the current traffic situation.
x Traffic signs and traffic regulations have priority over the recommendations and displays
provided by the navigation system.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
.WARNING
External devices that are loose in the vehicle or not properly secured could be thrown around
the interior and cause injuries during a sudden driving or braking maneuver, or in a crash.
x Never put or attach an external device on a door, on the windshield or above or near to the
areas marked “AIRBAG” on the steering wheel, the instrument panel and the seat backrests,
or between these areas and the vehicle occupants. External devices could cause serious
injury in an accident, especially when the airbags inflate.

.WARNING
The volume may suddenly get louder when you switch media source or connect a new audio
source.
x Always lower the volume before switching media source or connecting a new audio
source.
.NOTICE
Excessively loud or distorted playback can damage the vehicle speakers.
If the base volume on the Infotainment System has been considerably increased to play a certain
audio source, lower the volume again before switching to another audio source.
Function keys on screen

Fig. 124 Setup main menu (SETUP).

Fig. 125 Navigation settings.
.

Fig. 133 Infotainment system without navigation: Settings main menu (CAR).

Navigation data
All navigation data required for navigation is stored in the unit navigation data memory.
Street routing is subject to ongoing changes like, for example, new streets, street names or street
numbers. The route guidance may be inaccurate or incorrect if the navigation data is no longer up to
date. You should therefore have the unit navigation data memory updated by a Volkswagen
dealership on a regular basis. The updates are subject to a fee.
Possible errors in navigation
When the navigation system cannot receive any data from GPS satellites (dense canopy of trees,
tunnel, underground CAR park), navigation can still continue using the vehicle sensors.
In areas that are not or only incompletely digitized on the data medium (such as one-way streets and
street type not sufficiently captured), the navigation system also tries to enable route guidance.
Please remember that the navigation may sometimes not be so accurate as usual if the precise
vehicle position cannot be determined.
Navigation main menu

Fig. 160 Navigation main menu: Destination mode.

Fig. 161 Navigation main menu: Tour mode.
.

Function key: Effect
Create new telephone numbers: Opens an input window where you can enter a telephone number
manually.
Create business navigation destination: Opens a menu where you can select a navigation destination for
the “Business P”favorites category or convert a stored mailing address into a navigation
destination .
Create business mailing address: Opens a menu to enter a mailing address manually in input windows.
Create business mailing address: Opens a menu where you can select a navigation destination for the
“Private T” favorites category or convert a stored mailing address into a navigation destination .
Create private mailing address: Opens a menu to enter a mailing address manually in input windows.
Read contact: The voice command stored under Last name and First name is read out .
= Private contact: The directory entry is only displayed when the corresponding user profile is loaded.
If the check box = is cleared, the directory entry is transferred to the general user profile and is
always displayed .

If the prefix Create ... is not displayed in a function key, corresponding information is already stored.
This information is displayed below the function key (such as in .: Business navigation destination).
Press the function key to display or modify the stored information ⇒ fig. 186.
Converting mailing addresses into navigation destinations
Information that is stored as Business mailing address or Private mailing address can be converted into
navigation destinations, such as the telephone directory entries of a connected cell phone.
x Press the Create private navigation destination or Create business navigation destination
.button.
x Press the Create navigation destination function key.
The mailing address is converted into a navigation destination in the Infotainment System and
displayed in the Address entry menu where it can be edited further .
x Touch the OKfunction key.
The mailing address is now stored as a navigation destination. The navigation destination is displayed
and can be edited again.
x Press the Efunction key to close the menu.
