2013 VOLKSWAGEN TOUAREG steering wheel adjustment

.WARNING
Always adjust seat, safety belts and head restraints properly before driving and make sure
that all passengers are properly restrained.
x Push the passenger seat as far back as possible. Always be sure that there are at least 10
inches (25 cm) between the front passenger's breastbone and the instrument panel.
x Always adjust the driver's seat and the steering wheel so that there are a distance of 10
inches (25 cm) between your breastbone and the center of the steering wheel.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor
while keeping your knee(s) slightly bent. The distance to the instrument panel in the knee
area must be at least 4 inches (10 cm).
x If these requirements cannot be met for physical reasons, contact an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility to see whether adaptive
equipment is available.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands
at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the
driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places
inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the
wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag
inflates.
x Pointing the steering wheel toward your face decreases the ability of the driver's airbag to
help protect you in a collision.
x Never drive with backrests reclined or tilted back farther than necessary to drive
comfortably. The farther back the backrests are tilted the greater the risk of injury caused by
incorrect positioning of the safety belts and improper seating position.
x Never drive with the front seat passengers backrest tilted forward. If the front airbag
deploys, the front backrest can be forced backward and injure passengers on the rear seat.
x Sit as far back as possible from the steering wheel and the instrument panel.
x Always sit upright with your back against the backrest with the front seats properly
adjusted. Never lean against or place any part of your body too close to the area where the
airbags are located.
x Rear seat passengers who are not properly seated and restrained are more likely to be
seriously injured in a crash.
.WARNING
Improper adjustment of the seats can cause accidents and severe injuries.
x Never adjust the seats while the vehicle is moving. Your seat may move unexpectedly and
you could lose control of the vehicle. In addition, you will not be in the correct seating
position while adjusting the seat.
x Adjust the front seat height, angle and longitudinal direction only if the seat adjustment
area is clear.
x The adjustment of the front seats must not be restricted by things in the footwell in front
of or behind the seats.
Examples of improper seating positions

Proper seating position

Fig. 39 The driver should never sit closer than 10 inches (25 cm) of the steering wheel.

Fig. 40 Proper safety belt positioning and head restraint adjustment.

x Tall people should pull the head restraint all the way up.
x Adjust the seat back backrest angle to an upright position so that your back is in full contact with it
when the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly.
Driver - Seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 39. When adjusting the proper distance to the steering wheel, grasp the
top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the
9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside
the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can
cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your
face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help
protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping
your knee(s) slightly bent and the distance to the dashboard in the knee area is at least 4 inches (10
cm).
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the
airbag is deployed.
Electrical controls on the driver and passenger seat

Fig. 41 Driver seat: controls to adjust lumbar support A, side supports B, seat cushion C, and seat back rest
angle D.

Adjusting the steering wheel position

Fig. 49 Manual adjustment for the steering wheel position.

Fig. 50 Behind the steering wheel on the steering column: electrical adjustment for steering wheel.

.WARNING
Improper use of the steering column adjustment feature can result in serious personal injury
and even death.
x Always pull the lever ⇒ fig. 49 (1) firmly upward after adjusting the steering column so that
the steering wheel does not change position suddenly while the vehicle is moving.
x Never adjust the steering column while the vehicle is moving. If you find that you need to
adjust the steering wheel while driving, stop the vehicle in a safe place and make the proper
adjustment.
x Never adjust the steering wheel so that it points toward your face. Always make sure that
the steering wheel points toward your chest. Otherwise, the airbag system cannot protect
you properly in the event of a crash.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands
at the 9 o'clock and 3 o'clock positions to help reduce the risk of serious personal injury if the
driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands anywhere
inside the steering wheel or on the steering wheel hub. Holding the steering wheel the wrong
way increases the risk of severe injury to the arms, hands, and head if the driver front airbag
deploys.
Center armrest

Fig. 51 1 part and 2 part front center armrest.

Storing driver seat settings to the driver door memory buttons
x Apply the electronic parking brake.
x Shift the transmission into neutral.
x Sit on the driver seat and adjust it to the desired position
x Adjust both outside mirrors
x Adjust the steering wheel position
x Press the SET button until the LED lights up (arrow).
x Within about 10 seconds press the desired memory button 1, 2 or 3⇒ fig. 55. The LED will
extinguish and a chime signal will confirm the memory storage.
Storing front passenger seat settings to the front passenger door memory buttons
x Apply the electronic parking brake.
x Shift the transmission into Neutral (N).
x Sit on the front passenger seat and adjust it to the desired position
x Switch on the ignition.
x Press the SET button until the LED lights up (arrow).
x Within about 10 seconds press the desired memory button 1, 2 or 3 The LED will go out and a
chime sounds to confirm that settings have been.
Storing the passenger side outside mirror setting for backing up
x Apply the electronic parking brake.
x Shift the transmission into Neutral (N).
x Switch on the ignition.
x Briefly press the desired memory button 1, 2 or 3 on the driver door.
x Shift the transmission into Reverse (R).
x Adjust the passenger outside mirror, to provide good visibility of the curb for example.
x The mirror position you have set is automatically stored and assigned to the selected memory
button.
The passenger-side outside mirror automatically adjusts back from the position stored for backing up
when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is rotated
from (R) into a different position.
Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x Charging condition of the vehicle battery is weak.
x Repeated pressing of the SET button within about 10 seconds.
x Readjustment of the seat position within about 10 seconds after pressing the SET button.
Recalling stored memory settings
x With the vehicle door open and the ignition off , the stored setting positions can be recalled and set
automatically. For this, tap the corresponding memory button 1, 2 or 3 in the respective vehicle door
briefly. After about 10 minutes, the stored positions can not be set automatically.
x OR: With the vehicle door closed and the ignition .on press and hold the corresponding memory
button on the vehicle door until the stored positions are reached.

The lights stay on for about 10 seconds (lighting delay period). The “Coming home” and
“Leaving home” functions can be enabled and disabled in the Infotainment System.
If the “Coming home” feature is switched on and the driver door is opened, no acoustic warning
will sound to alert that the light is still on.
Instrument panel lighting , headlight range adjustment

Fig. 85 Next to the steering wheel: Control for instrument cluster lighting.
