2013 VOLKSWAGEN TOUAREG Owners Manual

Rollover warning
.

Before driving off-road the first time
Before you drive your vehicle off-road, we urge you to take an appropriate off-road driving course.
Taking a course is especially important if you have little or no experience driving off-road. Even more
experienced off-roaders can benefit from an off-road driving course.
A good course can show you how to handle the vehicle in a wide range of off-road situations and how
to more safely deal with difficult terrain Driving off-road demands a different attitude and very different
skills compared with highway driving. Your safety and that of your passengers will depend on your
knowledge, skill, and caution as a driver ⇒ .
.WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist above. Follow commonly accepted safety
practices and use common sense.
x All occupants must sit properly and wear safety belts whenever the vehicle is moving.
General rules and good driving practices
.

.WARNING
Off-road driving can be dangerous, can lead to accidents, vehicle damage, stranding in
remote areas, and serious personal injury.
x Never drive too fast or for terrain and weather conditions.
x Always adjust your speed and driving style to road, terrain, traffic, and weather
conditions.
x Always avoid sudden, sharp maneuvers that increase the risk of loss of vehicle control or
getting stuck.
x When driving off-road look and think ahead, expect the unexpected.
x To reduce the risk of loss of control and serious personal injury, never use the cruise
control when driving off-road. Cruise control is designed for highway use. It is completely
unsuitable for off-road situations and can even be dangerous when used off-road.
.NOTICE
Always make sure the vehicle has enough ground clearance. Severe damage to the underbody
can occur if the vehicle bottoms out. The damage could disable the vehicle and leave you
stranded.
.“Tread lightly” is an educational program designed to increase public awareness of land use
regulations and responsibilities in our nation's wilderness areas. Volkswagen supports the U.S. Forest
Service and the Bureau of Land Management in encouraging you to preserve our national forests and
other public and private lands by “treading lightly”.
Technical terms explained

Fig. 281 Illustration of grade (gradient angle) A and lateral angle B.
.

Term Explanation Technical data
Ground clearance This is the vertical distance between the
level ground and the lowest part on the
vehicle.
Front: maximum 8.6 inches
(214 mm).
Rear: maximum 10.4 inches
(261 mm).
Fording depth in
standing water
Distance between the point on the ground
that touches the tire and the engine air
intake duct.
Maximum 20 inches (500 mm).
Gradient angle The number of feet (meters) in altitude
gained when traveling 100 ft (30.48 m) is
given as a percentage or in degrees
⇒ fig. 281 A.
Information on the maximum slope the
vehicle can climb unassisted (depends on
road surface and engine power).
Maximum permissible 31 degrees
(corresponds to 60 %).
Lateral angle
(vehicle slope)
The maximum angle the vehicle may be
driven across terrain without the vehicle
rolling over (depends on height of center
of gravity) B.
Maximum permissible
35 degrees.
Breakover angle Maximum permitted angle given in
degrees that a vehicle driven at low speed
can clear a ramp without the underbody of
the vehicle scraping the ramp
Maximum 20 degrees.
Approach/departure
angle
Transition from horizontal plane to a slope,
or from a slope to flat ground.
Maximum angle in degrees the vehicle can
be driven at low speed along an
embankment without the bumper or
underbody scraping.
Front: maximum 25 degrees.
Rear: maximum 26 degrees.
Fall line This is the vertical drop route.
Articulation Articulation capability of the vehicle while driving on one side over an object.

.WARNING
Never exceed the recommended maximum values in the above table. Exceeding these values
will result in serious personal injury and/or damage to your vehicle.
x All values listed above are for ideal conditions and assume firm, even surfaces that are
dry and not slippery.
x Off-road conditions will always be less than ideal. Always reduce the maximum values
listed in the table above to allow an adequate margin of safety between the ideal maximum
value and your vehicle's actual off-road situation.
Useful off-road driving equipment
.

Checklist
Checklist: Useful off-road driving equipment ⇒ :
d Water, compass, maps, flashlight and spare batteries.
d Cable winch, tow rod or tow rope strong enough for your vehicle.
d Cell phone, shovel, blankets, and rubber boots, tape measure, and yardstick.
d Vehicles without tire mobility set: Electric air compressor to connect to the 12 Volt outlet in the
vehicle for inflating the tires.
d A wooden plank about 2 inches thick and 3 feet long or similar aluminum frame as traction aid for a
stuck vehicle or as a base for the vehicle jack.
d Snow chains for all 4 tires, additional spare tires, and tire mobility set.
.WARNING
Accidents and severe personal injury can result from the improper use of tools or equipment
as well as from the use of tools or equipment that are damaged or not right for the job to be
done.
Safety and off-road driving
.

.WARNING
Not wearing safety belts, or wearing them improperly will increase the risk of serious injuries
when driving off-road. Holding the steering wheel improperly will reduce your ability to
control the vehicle and can also increase the risk of injury when driving off-road.
x Properly worn safety belts are the single most effective means of reducing the risk of
serious injury and death during sudden braking or driving maneuvers and in automobile
accidents. For this reason, always wear your safety belt properly and make sure all
passengers wear their safety belts properly as well whenever the vehicle is moving.
x Never wrap your thumbs around the steering wheel rim. When driving off-road, obstacles
in front of the wheels can make the steering wheel jerk suddenly in your hands and cause
personal injury. Rest your thumbs pointing up on the on the surface of the steering wheel at
the 3 and 9 o'clock positions.

Off-road driving situations

Selecting the right gear
.
