2013 VOLKSWAGEN TOUAREG Owners Manual

2.) Examples of optical deception by the camera: (examples)
The Rear Assist camera provides only two-dimensional images. Recesses and protruding objects on
the ground or protruding parts on other vehicles are difficult or impossible to identify due to the lack
of depth of field.
Objects or another vehicle may seem closer or farther away on the screen than they really are.
– When driving from a level surface onto an upward or downward slope.
– When driving up or down a slope onto a level surface.
– If the rear of the vehicle is heavily loaded.
– When approaching protruding objects. These objects can disappear from the field of view when
backing up.

Cleaning the camera lens
Keep camera lens clean and free from snow and ice.
x Engage the parking brake.
x Switch on the ignition.
x Select the reverse gear.
x Wet the camera lens with a commercially available alcohol-based glass cleaner and clean with a
dry cloth ⇒ .
x Remove snow with a brush.
x Remove ice with deicer spray ⇒ .
.NOTICE
x Never use abrasive cleaning agents to clean the camera lens.
x Never remove snow or ice on the camera lens with warm or hot water. This can damage the
camera lens.
.Volkswagen recommends practicing parking with Rear Assist in a safe place with little or no
traffic or in a parking lot under good visibility and weather conditions in order to familiarize yourself
with the system, the orientation lines and the way they work.
.Rear Assist cannot be activated when the factory-installed trailer hitch is electrically connected
to the trailer or the rear hatch is open.

Parking perpendicular to the road (Mode 1)

Fig. 266 On the screen: Orientation lines of the parking area behind the vehicle.
.

Orientation lines overview
Meaning of the orientation lines and areas projected on screen ⇒ fig. 267. All distances of the
orientation lines refer to a vehicle on a level surface.
(1) Safety distance: Area up to about 16 inches (40 cm) behind the vehicle on the road.
(2) Vehicle's width limits.
(3) Point to change steering angle.
When the yellow line touches the curb or any other parking space boundary, the steering wheel
must be turned in the opposite direction (close-up view).
(4) The parking area parallel to the vehicle which is needed for parking. The area shown must fit
completely into the parking space.
(5) Parked vehicle at the curb.
Parking
x Position the vehicle about 3 feet (1 meter) away from and parallel to the parking space and shift
into reverse.
x On the screen of the navigation system, activate Mode 2 for parallel parking.
x Back up slowly and steer the vehicle so that the yellow surface on the screen is flush with the side
boundary of the parking space (such as the curb) and stops short of any obstacle (5), such as another
vehicle.
x Turn the steering wheel as far as it will go into the direction of the parking space and slowly back
up.
x Once the yellow line (3) touches the side boundary of the parking space, such as a painted line or
a curb (close-up view), turn the steering wheel as far as it will go in the opposite direction.
x Continue backing up until the vehicles is positioned in the parking space parallel to the roadway. If
necessary, correct the parking position.
.It may take up to 5 seconds for the area detected by the sensors to be displayed on the factory-
installed radio or navigation screen.

Cruise Control System (CCS)

Applicable only in the United States
Indicator lights

Fig. 132 In the instrument cluster display: Cruise control status indications.

Applicable only in Canada
Indicator lights

Fig. 133 In the instrument cluster display: Cruise control status indications.

Cruise control operation

Fig. 134 On the left side of the steering column: Cruise control operating lever.

In order to: You must ⇒fig.134Result:
Reduce set speed (while
cruise control is actively
controlling vehicle
speed).
Push the lever briefly to the
30%%$ – position (–) to reduce
speed in increments of 5 mph
(10 km/h) and store.
Cruise control will slow the vehicle
down without braking by reducing the
flow of fuel to the engine until the new
lower speed is reached and saves the
new lower speed in the memory. Push and hold the lever in the
30%%$ – position (–) to reduce the
set speed until the lower desired
speed is reached and the button
is released.
Switch off cruise control. Move the lever to the /&&position
(B).
System is switched off. The set speed
is deleted.

Driving downhill with cruise control
If cruise control cannot maintain constant speed while driving downhill, slow the vehicle with the foot
brake and downshift if necessary.
Automatic deactivation
Cruise control speed regulation is automatically deactivated or temporarily interrupted:
x If the system detects an error that could affect the function of the cruise control.
x If the vehicle has accelerated and goes faster than the stored speed for a longer time.
x If the brake or clutch pedal is depressed.
x If the vehicle shifts gear (manual transmission).
x If an airbag deploys.
