2013 VOLKSWAGEN TOUAREG Owners Manual

(8) PHONEInfotainment button3 for accessing the telephone functions .
Switching on or off

.WARNING
The volume may suddenly get louder when you switch media source or connect a new audio
source.
x Always lower the volume before switching media source or connecting a new audio
source.
.NOTICE
Excessively loud or distorted playback can damage the vehicle speakers.
If the base volume on the Infotainment System has been considerably increased to play a certain
audio source, lower the volume again before switching to another audio source.
Function keys on screen

Fig. 124 Setup main menu (SETUP).

Fig. 125 Navigation settings.
.

Function keys start functions or open submenus. In submenus the name of the currently selected
menu is displayed in the title bar ⇒ fig. 124 (A).
Press the

Fig. 127 Station list in radio mode.
.

.

Input windows with on-screen keyboard

Fig. 130 General view of an input window with on-screen keyboard.

Function keys Action and effect
y
Pressing briefly highlights all function keys for which special
characters are available.
Press a function key to open the pop-up window to select a special
character.
: Press to switch between upper and lower case.
; Press to open the input window for numbers and special characters or
to go back to the letter input window. OR: A-Z
. . Press to enter a space.
Ë and £ Press to move the cursor to the left or right in the input line.
OK Press to accept the suggestion in the input line and close the input
window.
$ Press to delete characters in the input line from right to left.
C Press to open the list of remaining items that match the text you have
entered.
* (or here: 14) Displays the number and opens the list of entries that are still
available corresponding to the specifications.
¿ Press to close the input window.

Additional displays and display options

Voice operation
