2013 VOLKSWAGEN TOUAREG Owners Manual

Refueling

.WARNING
x Even if empty, portable fuel containers can leak and cause a fire and serious personal
injuries, especially in a crash.
x If, under exceptional circumstances, you must transport a portable fuel container, please
observe the following:
For your safety, we strongly recommend that you do not travel with a portable fuel container
in your vehicle.
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for
example, in the luggage compartment or on the rear hatch). Static electricity can build up
while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel
inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and
during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact
with the container. This will help prevent static electricity from discharging and causing a
fire.
– Always observe local and state or provincial laws about the use, storage, and
transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as
ANSI/ASTM F852-86.
.NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires,
and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel
when your vehicle has a gasoline engine can cause very serious and expensive engine and
fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance. These fuels contain substances that can severely
damage the fuel system and the engine if the engine is started.
x Vehicles with diesel engines must never be refueled or driven with gasoline, kerosene,
heating oil, or other non-specified fuels that have not been expressly approved for use with the
diesel engine. Other kinds of fuel will cause serious damage to the fuel system and the engine
that is not covered by any Volkswagen Limited Warranty.
.Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly,
following all applicable environmental regulations.
.There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility for assistance if necessary.

Indicator lights and fuel gauge

Fig. 275 In the instrument cluster: Fuel gauge for gasoline and diesel fuel.

.WARNING
Driving with a fuel tank that is almost empty can lead to stalling in traffic, a collision, and
serious personal injuries.
x When the fuel tank is almost empty, fuel supply to the engine can be interrupted,
especially when driving up an down hills. The interruption in fuel flow could stall the engine
during a maneuver in difficult terrain and make you lose control of the vehicle.
x Steering and braking assistance as well as ESC and related systems will not work if the
engine “sputters” or stalls due to lack of fuel.
x Always refuel when the tank is 1/4 full to reduce the risk of running out of fuel and stalling
in traffic.
.NOTICE
x Failure to heed warning lights or text WARNINGS can result in vehicle damage.
x Never drive until the fuel tank is completely empty. The irregular fuel supply can cause the
engine to misfire. This allows unburned fuel to get into the exhaust system and damage the
catalytic converter or the diesel particulate filter.
.NOTICE
If the fuel tank venting system malfunctions and the fuel tank cannot be properly vented before
refueling:
x Gasoline fumes can escape from the fuel filler neck, resulting in temporary odors.
x The fuel nozzle may shut off during refueling and it will take longer to refuel the vehicle.
Only in this situation can you continue to CARefully refuel your vehicle after the fuel nozzle
shuts off.
x See your Authorized Volkswagen dealer or authorized Volkswagen Service Facility to have
your vehicle checked.
.The small arrow next to the gas pump symbol in the fuel gauge shows the side of the vehicle
with the fuel filler flap.
Misfueling guard for diesel vehicles

Fig. 278 With open fuel cap: Misfueling guard in the fuel filler neck
.

The fuel filler neck of diesel vehicles is equipped with a misfueling guard ⇒ fig. 278. The misfueling
guard helps prevent filling the fuel tank of a diesel vehicle with gasoline, because the guard makes it
difficult to insert any type of filler nozzle other than the type commonly used for diesel fuel.
Damaged, worn out, or incorrect nozzles, as well as other means of refueling (portable fuel
containers, for example) will generally not open the misfueling guard and fuel from these sources
cannot easily flow into the tank. Using these incorrect or non-standard nozzles to refuel your diesel
vehicle can cause fuel spills, which can cause fires, explosions, burns, and other severe injuries.
The misfueling guard can generally only be properly opened with a correct nozzle from a standard
diesel fuel pump. Under certain circumstances it may be necessary to turn the nozzle back and forth
slightly with light pressure to open the misfueling guard. If the misfueling guard cannot be opened this
way, see the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility and
have the fuel system checked.
.WARNING
Spilled fuel can cause fires, explosions, burns, and other severe injuries.
x Do not refuel from devices other than correct, undamaged standard diesel fuel pump
nozzles.
x Always stop refueling once the pump nozzle switches off so that the tank does not
overflow.
.NOTICE
x It is your responsibility to put the right fuel in your vehicle and any damage that results is
not covered under the Emissions warranties or any other Volkswagen Limited Warranty.
x If you put any amount of the incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance.
x If diesel fuel should get on any rubber hose, it must be wiped off immediately. The same
applies if diesel fuel gets onto other parts of the vehicle, especially paint, tires, or a plastic
part. Wash the contaminated vehicle parts right away with soap and warm water to help
prevent leaks and serious damage.
x Never force a fuel nozzle in the misfueling guard. If you have problems inserting a fuel
nozzle, first check to make sure you are using the correct diesel fuel. If you are, go to a pump
with the standard diesel nozzle. Forcing a fuel nozzle in the misfueling guard can damage it so
that it can no longer help prevent misfueling.
Fuel capacities
.

Refueling checklist

Fuel

If quality gasoline with additives that do not contain metal is not available or engine malfunctions
occur, you should add the required additives while refueling ⇒ .
Not all gasoline additives are effective. Using the wrong additives can cause significant and expensive
damage to the engine and the catalytic converter. Never use additives that contain metal. Please note
that metal can be included in some aftermarket gasoline additives that are available to be added to
gasoline during or after refueling to help improve knock resistance or increase the octane rating.
Volkswagen recommends using only additives approved by Volkswagen. Appropriate additives as well
as instructions on how to use them are available from your authorized Volkswagen dealer or
authorized Volkswagen Service Facility. Do not add any other gasoline additives.
.NOTICE
You can damage the engine by using incorrect additives.
x Using incorrect gasoline additives can cause extensive engine damage as well as damage
to the catalytic converter.
x If you must fuel your vehicle with gasoline whose octane rating is too low, only drive with
the engine speed in the middle of the rpm range and with low engine load. Avoid high rpm and
heavy engine load. Otherwise, the engine could be damaged. Refuel your vehicle with gasoline
with the required octane rating as soon as possible.
x Do not use fuel that is labeled at the pump as containing metal. Lead replacement fuel
contains high concentrations of metallic additives. Engine damage could result.
x Fueling your vehicle just one time with leaded fuel or fuel that contains other metallic
additives can affect the performance of the catalytic converter and cause extensive damage to
it.
Diesel fuel
.
