2013 VOLKSWAGEN TOUAREG turn signal

Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Side window with window diversity antenna for:
– Radio
– Central locking
(3) Roof antenna for:
– Cell phone
– Navigation
(4) Roof rack
(5) Outside door handle
(6) Outside mirror
– Additional turn signal light
(7) Lift points for the jack
(8) Receiver for the trailer hitch

Driver side overview

Fig. 5 Driver side overview.
Key to fig. 5:
(1) Air vents z
(2) Lever for:
– High beams
– Headlight flasher
– Turn signal lights

(3) Multi-function steering wheel controls :
– Volume setting for radio, navigation system notifications, or telephone calls (if applicable)
.& – '
– Mute switching for radio or activation of voice control (if applicable) 
– Display Phone main menu or accept telephone calls -
– Audio, Navigation .Ì –

Function Using the buttons on the remote
control vehicle key ⇒ fig. 23
Using the emergency key
Unlock the vehicle. Press the 0 button twice to open all
doors and the rear hatch.
Insert the emergency key into the
driver door lock and turn counter-
clockwise. Keep turned for
convenience opening.
Lock the vehicle. Press the 1 button and keep it
pressed for convenience closing.
Insert the emergency key into the
driver door lock and turn clockwise.
Keep turned for convenience
closing.
Unlock the rear hatch. Press the & button. Insert the emergency key into the
driver door lock and turn counter-
clockwise.

Note: Depending on the settings for the power locking system in the .Comfort sub-menu, it may be
necessary to press the 0 button twice to unlock all doors and the rear hatch.
The remote control vehicle key unlocks and locks the vehicle only when the battery in the remove
control vehicle key have enough power, and the remote control vehicle key is within a few
yards/meters of the vehicle. All turn signals flash to confirm that the vehicle is locked.
x All turn signals flash once and the horn beeps once to confirm that the vehicle has been locked.
The horn beep can be disabled by deactivating the “ATA confirmation” feature in the Convenience
submenu.
x All turn signals flash twice to confirm that the vehicle has been unlocked.
If the turn signals do not flash to confirm locking, one or more doors, the rear hatch or the engine hood
is not locked.
If the driver door is open, the vehicle cannot be locked with the remote control vehicle key.
If the vehicle was unlocked with the remote control vehicle key and the door or the rear hatch has not
been opened in about 30 seconds, the vehicle is automatically locked again. This feature helps pre-
vent the vehicle from staying unlocked unintentionally.
Unlocking and locking the vehicle from the inside

Fig. 24 On all 4 doors: Power locking switch.

Unlocking and locking the rear hatch (Keyless Entry for the rear hatch)
If the vehicle is locked and a valid vehicle key is within range A of the rear hatch, it unlocks automati-
cally when opened.
x Open and close the rear hatch as you would a standard rear hatch.
The rear hatch locks automatically when it is closed except in the following situations:
x The vehicle is completely unlocked.
x When an authorized vehicle key is inside the vehicle.
Sensor-controlled rear hatch opener (Easy Open)
When a valid vehicle key is within range A of the rear hatch, the rear hatch can be unlocked and
opened by moving your foot within the sensor’s range ⇒ fig. 26 below the rear bumper.
x Switch off the ignition and remove any vehicle key in the ignition.
x Stand in front of the middle of the rear bumper.
x Quickly move the side of your body, your foot and shin as close to the bumper as possible. Your
shin must be in the upper part of the sensor’s range and your foot in the lower part (1).
x Quickly move your shin out of range (2). The rear hatch opens automatically.
The high-mounted brake light and the turn signals flash once to show that the Easy Open feature is
opening the rear hatch.
The rear hatch locks automatically after closing if the vehicle was locked before and a valid vehicle key
is not inside the vehicle. If the vehicle key used to open the vehicle is inside the vehicle, the rear hatch
opens again.
Easy Open may not work properly or at all in the following situations (examples):
x If the rear bumper is very dirty.
x If the rear bumper has salty water on it after driving on salted roads.
x If a trailer hitch has been retrofit on the vehicle.
Easy Open may be automatically deactivated in heavy rain to help prevent unintentional deployment
caused by water running down the vehicle, for example.
Locking with a second vehicle key
If a remote control vehicle key is inside the passenger compartment, the vehicle can be locked from
the outside only if a second valid key is within range.
A key that was inside the vehicle when it was locked from the outside is reactivated:
x By pressing a button on the deactivated key.
x By pressing a door handle sensor when the deactivated key is outside of the vehicle, but within
range.
x By starting the engine with the starter button on the front center console.
Automatic deactivation of sensors
If the vehicle has not been unlocked or locked for a longer period of time, the proximity sensors in the
passenger door are automatically deactivated.
If a sensor on the door handle of a locked vehicle is activated too often, for instance by a bush or
hedge that rubs against the vehicle, the sensors in the door handle on that side of the vehicle are
switched off for 30 minutes.
The sensors become active again when the vehicle is locked with the vehicle key and the ignition is
switched on one time.
The sensors become active again if one of the following events occurs:
x 30 minutes have passed.
x OR: The vehicle is unlocked using the V button in the remote control vehicle key.

x OR: The rear hatch is opened.
x OR: The vehicle is mechanically unlocked using the emergency vehicle key.
Convenience features
To use the convenience closing feature to close all power windows, hold your finger on the lock sensor
surface ⇒ fig. 25 (2) on the outside of the door handle for a few seconds until the windows close.
Remove your finger from the lock sensor surface (2) to stop the function. If you touch the unlock
sensor surface 1 on the inside of the door handle immediately after releasing the lock sensor surface 1
(arrow), all of the windows will open (safety function). Pinch protection is active during convenience
closing of the windows.
The settings in the Settings – Convenience menu determine which doors open when the door
handle sensor surface is touched.
.CAUTION
If a valid vehicle key is within range of the rear hatch, the Easy Open feature can deploy unin-
tentionally in some cases and open the rear hatch: for example, when sweeping the ground
or floor below the rear bumper, if there is a strong stream of water or steam or when CARry-
ing out maintenance or repairs around the rear bumper. If the rear hatch opens unintentional-
ly, it can injure anyone or damage anything in its way.
x Never leave a valid vehicle key within range of the rear hatch unattended.
.NOTICE
The door handle sensor surfaces can be activated by a strong stream of water or steam if a
valid vehicle key is within range of the vehicle. All windows may open if you turn the spray of
water or steam away from and then back onto the door handle sensor surface in quick succes-
sion.
.The door may not open if the outside and inside door handles are used at the same time.
.If the automatic transmission is not in Park (P) position, the electronic steering column lock will
not lock and the vehicle will not lock via sensors in the front door handles or the remote control vehicle
key.
.If the vehicle battery or the battery in the remote control vehicle key is weak or dead, it might not
be possible to unlock and lock the vehicle using Keyless Access The vehicle can still be manually
locked or unlocked with the emergency key.
.The driver message Key not in range appears in the instrument cluster display if there is
no remote control vehicle key inside the vehicle or if the system does not recognize the remote control
vehicle key. The key may not be recognized, for example, if it is covered by something that interferes
with the signal (such as a briefcase), or if the remote control vehicle key battery is weak. Electronic
devices such as cell phones can also interfere with the signal.
.Dirt on the door handles that contains a lot of salt (especially in winter) can affect the way the
door handle sensors work. Cleaning the door handles can help with this problem.

The buttons 1, 2, and 3.on the roof keypad ⇒ fig. 37 between the sun visors can operate up to 3
separate remote control devices (for example, a gate and garage door, a house alarm, or a lighting
system).
Getting ready to program
x Please read the product manufacturer's instructions before programming the garage door opener
or other device.
x Safely park the vehicle within range of the device to be programmed.
x Switch the ignition on, but do not start the engine.
Menu Garage door opener in the Infotainment System
Call up the Garage door opener menu in the Infotainment System ⇒ fig. 38.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select Garage door openerfrom the list.

Function key: Effect
Program buttons: Buttons 1, 2 or 3 can be programmed after you tap the function key. Follow the
instructions on the Infotainment System screen.
Delete button assignment: Deletes the programming of buttons 1, 2, and 3⇒ fig. 37.
Version information: Most recent programming information for your authorized Volkswagen dealer or
authorized Volkswagen Service Facility.

Programming information
You must complete the programming process within 5 minutes. If you exceed this time limit, the
programming is cancelled.
If programming is cancelled, a red LED lights up in the keypad and the turn signals flash once.
Programming unassigned buttons
x Complete the programming preparation steps described above.
x Press unassigned button in the roof keypad .
x Follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3
times.
Repeat these steps with another unassigned garage door opener button to use that button to control
another device.
Programming previously assigned buttons
x Complete the programming preparation steps described above.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
x Tap the Program button function key and follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3
times.


One or more driving lights not working or
cornering light malfunction.
Replace burned out bulb or
if all light bulbs are OK, visit an authorized
Volkswagen dealer or authorized Volkswagen
Service Facility.
Adaptive Front Lighting System
malfunction.
8 One or more brake lights burned out.
Replace the light bulb that isn't working. If all
light bulbs are OK, see an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.

Adaptive Front Lighting System (AFS)
malfunction.
See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
 Headlight range adjustment malfunction. See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
 Parking lights switched on.
; All license plate lights not working.
Replace the light bulbs that aren't working. If
all light bulbs are OK, see an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
Fog lights switched on.



Left or right turn signal.
If necessary check the vehicle and trailer
lighting. The indicator light blinks twice as fast if a
turn signal is not working on the vehicle
or the trailer.
 Daytime running lights (DRL) on.
$2,
 High beams switched on or headlight
flashers in use.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, stop
the engine, turn on the emergency flashers, and use other warning devices to warn
approaching traffic.
x Never park the vehicle in areas where the hot catalytic converter and exhaust system can
come into contact with dry grass, brush, spilled fuel, oil, or other material that can catch fire.
x A broken down vehicle presents a high accident risk for itself and others. Switch on
emergency flashers and set up a warning triangle to warn oncoming traffic.

.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
.High Intensity Discharge (HID) headlights provide bright, uniform lighting to help you see and be
seen. The light comes from an electric arc between two electrodes in the gas-filled bulb. Over time, the
electrodes can wear down and the gap between them will get wider. The HID lamp’s control unit then
increases the voltage to keep the arc’s brightness constant. However, the commonly called “Xenon”
bulbs will also ultimately burn out. Before they burn out, HID lamps can flicker. A message will then
appear in the MFI. This is your reminder to see an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility to check the headlights.
Turn signal lever and high beam switch

Fig. 83 Turn signal lever and high beam switch.
.
