2013 VOLKSWAGEN TOUAREG turn signal

.WARNING
Improper use of high beams can distract and blind others, causing accidents and serious
injuries.
.The turn signal light works only when the ignition is switched on. The emergency flasher works
even when the ignition is switched off.
.The indicator light flashes twice as fast if a turn signal bulb is burned out.
.High beams can only be switched on when low beams are on.
Switching lights on and off

Fig. 84 Next to the steering wheel: Light switch.

x To switch on the fog lights : first turn the light switch to position , then pull the light switch out
to the first detent.
x To switch off the fog lights, push the switch back in from the first detent. To then turn off the
headlights, turn the switch to position /..
Acoustic warning when lights are not switched off
In the following situations, a warning chime will sound if you take the key out of the ignition and open
the driver door. This is to remind you that lights are still on.
x If the parking lights are switched on.
x Light switch in position .
.WARNING
Daytime running lights and parking lights are not bright enough to let you see ahead or be
seen by others when it is dark.
x Always switch on the low beam headlights at dusk or when it is dark and whenever the
weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright
enough and will not let you see far enough ahead for safety, especially at dusk or when it is
dark. Always switch on the low beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on,
a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
x Even if automatic headlight control is switched on, the low beam headlights may still not
come on by themselves in fog or heavy rain. You have to switch on the low beam headlights
manually.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features

Lights with LED-technology
You cannot replace the LEDs. Contact your authorized Volkswagen dealer or an authorized
Volkswagen Service Facility for assistance.
.WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. (DRL) are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low
beam headlights at dusk or when it is dark.
x If automatic headlight control (AUTO) is switched on, the low beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low beam headlights yourself.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

If the light switch is in the AUT O position, the outside vehicle lighting and the instrument lighting are
automatically switched on at dusk/nightfall and off in normal daylight in the following situations ⇒ :

Automatic activation: Automatic deactivation/change to daytime
running lights:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.
If you drive faster than about 87 mph (140 km/h)
for several seconds.
If you drive slower than about 40 mph (65 km/h)
for several seconds.
If the rain sensor recognizes heavy rain and
switches the windshield wipers on.
If the windshield wipers have not moved for
several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
The Adaptive Front Lighting System can be switched on and off in the Infotainment System.
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Assist systems function key on the screen.
x Select the menu item Light assistance (main beam control)from the list.
x Tap Adaptive front lighting system (AFS) to enable or disable this feature.
On some models, the headlights move independently of each other, even in straight-ahead driving.
They adapt to weather conditions and speed to better illuminate the roadway. The headlights return to
their original position after a delay, depending on the speed of the vehicle.
.WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low
beam headlights at dusk or when it is dark.
x If automatic headlight control (AUTO) is switched on, the low beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low beam headlights yourself.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

On road : the start point for the route guidance will be reached using public roads as far as
possible.
Off-road : the start point for route guidance will be reached in off-road mode and any available
roads will not be used.

When route guidance starts, the system will switch to the map view.
An audible signal is given when the starting point of the waypoint tour has been reached.
During route guidance
Characteristics of the terrain are ignored during route guidance. A driving recommendation will be
given about 55 yards (50 meters) before reaching a turning point. You should therefore drive slowly
and follow recommendations for turning as far as possible!
Changes in the direction of travel will be given in relation to the current direction of travel, such as
.“Please travel in direction 9 o'clock!”.
The tendency of the direction of travel will be shown in the instrument cluster display using arrows.
Stopping route guidance
x Press the Infotainment button .NAV in the map display to open the Waypoint navigation
menu.
x Press the Stop function key.
Stopping waypoint navigation

Fig. 205 Waypoint navigation menu.
.

Switching Park Distance Control on and off manually
x Push the  or ∗ .button once when the ignition is switched on to switch Park Distance Control
on.
x Push the  or ∗ .button again when the ignition is switched on to switch Park Distance Control
off.
The indicator light in the button comes on and stays on as long as the feature is active. The indicator
light in the button comes on and stays on as long as the feature is active.
Switching Park Distance Control on and off automatically
x Automatic activation: Shift into reverse.
x OR: Drive forward slowly (less than about 6 - 9 mph /10 - 15 km/h) and approach to within about
38 inches (95 cm) of an obstacle.
x OR: If the vehicle rolls backwards.
x Automatic deactivation: Drive faster than about 6-9 mph (10 - 15 km/h).
A chime sounds to tell you that the system is on. If the chime does not sound, PDC is not working.
Have the system inspected by an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an
obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System .
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is
engaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an
authorized Volkswagen Service Facility.
.WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
.If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light
in the button starts blinking, this means there is a malfunction in the Park Distance Control system.
Switch off the Park Distance Control system with the button and have it immediately checked by an
authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
