2013 VOLKSWAGEN TOUAREG lock

Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Side window with window diversity antenna for:
– Radio
– Central locking
(3) Roof antenna for:
– Cell phone
– Navigation
(4) Roof rack
(5) Outside door handle
(6) Outside mirror
– Additional turn signal light
(7) Lift points for the jack
(8) Receiver for the trailer hitch

Driver door overview

Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Indicator for power locking system
(2) Memory buttons for storing the driver seat and outside mirror settings  –  –  – 3%4
(3) Door handle
(4) Power locking switch for locking and unlocking the vehicle 0

Lower front center console

Fig. 7 Overview of lower front center console (4MOTION).
Key to fig. 7:
(1) Automatic transmission selector lever
(2) Storage compartment
– with 12 Volt socket
(3) Starter button for Keyless Access locking and starting system 34!24 – 34/0
()
(4) Button for:
– Electronic parking brake G
(5) Button for:
– Driving with electric motor %--/$%
– Anti-slip regulation (ASR) m
(6) Rotary knob for setting drive mode (On-road / Off-road)
(7) Cup holders
(8) Storage compartment in the center armrest

Front passenger side overview

Fig. 9 Overview of the passenger side.
Key to fig. 9:
(1) Air vents z
(2) Passenger front airbag location in the instrument panel (approximate)
(3) Opening handle for the lockable glove compartment

.NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
.Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
.Remote control vehicle key functions can be temporarily disrupted by interference from trans-
mitters near the vehicle that use the same frequency range (such as radio equipment or cellular
phones).
.Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
.If the remote control vehicle key buttons or the power locking buttons ⇒ fig. 24 are pushed
repeatedly in quick succession, the power locking system is switched off for a brief period to help keep
it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Emergency key

Fig. 18 Releasing the emergency key and removing it from the remote control vehicle key.

Fig. 19 Releasing the emergency key and removing it from a remote control vehicle key with a panic button.

Replacing the cover
x Insert the thin left side of the cover ⇒ fig. 21 (2) in the remote control vehicle key and press the
thick right side down until the cover locks into place.
x Reinsert the emergency key into the remote control vehicle key.
.NOTICE
x Changing the battery improperly can damage the remote control vehicle key.
x Using the wrong battery can damage the remote control vehicle key. Replace a dead battery
with a new one that has the same voltage, size, and specifications.
x Make sure the plus and minus poles of the battery are correctly positioned.
.Dispose of old batteries in an environmentally responsible manner and keep them out of the
reach of children.
.Batteries of the type used in your remote control vehicle key may contain Perchlorate Material.
Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding handling and disposal of these batteries. Authorized Volkswagen dealers and
authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that
you have them perform this service for you.
Synchronizing the remote control vehicle key

Power locking and closing system

Description of the power locking system
