2013 VOLKSWAGEN TOUAREG sunroof

Symbols on the roof console

Symbol Meaning
*  s  Interior and reading lights
> ≅ ? Power sunroof


Function Using the remote control vehicle key
Convenience
opening Press and hold the unlock button on the remote control vehicle key.
Convenience closing Press and hold the lock button on the remote control vehicle key.

From outside the vehicle (vehicles with Keyless Access), hold your finger on the lock sensor surface
on the outside of the door handle for a few seconds until the windows close.
Convenience closing closes the windows first and then the power sunroof.
The Infotainment System can be used to set various convenience opening options.
Setting convenience opening options in the Infotainment System
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select Remote control keyfrom the list.
If the check box in a function key is checked =, the feature is switched on.

Function key: supplementary information
= Front windows: Convenience opening opens front windows. Tap the function key to deactivate the
feature.
= Rear windows: Convenience opening opens rear windows. Tap the function key to deactivate the
feature.

.WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power
windows for several minutes after the ignition is switched off as long as the driver or front
passenger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power
windows and keep them from being opened and closed.
.If the power windows malfunction, the one-touch feature, as well as pinch protection will not
work properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
right away.
.Convenience closing of the power windows from the outside requires removing the cover cap of
the lock cylinder on the driver door. The cover cap must be reinstalled after the vehicle is locked.

Power sunroof

Applicable only in Canada
Opening or closing the power sunroof

Fig. 33 In the headliner: Rotary switch for the power sunroof. (A) Turn the rotary switch to slide the sunroof
open or closed. (B) Press or pull the switch to tilt open or to close.
.

The sunshade opens automatically when the power sunroof opens if the shade was previously
completely closed or in front of the glass roof. The sunshade remains in the previous position and
does not close automatically with the sunroof. The sunshade cannot be closed completely until the
power sunroof is closed.
If your power sunroof will not close properly, do not try to close it yourself, doing so can cause serious
and expensive damage that will not be covered by any Volkswagen Limited Warranty. Special
knowledge and tools are required to close the power sunroof if it will not close on its own. To help
prevent damage to the sunroof, have an authorized Volkswagen dealer or an authorized Volkswagen
Service Facility help you close and repair the power sunroof.
.The comfort position (B) provides sufficient ventilation without loud wind noise.
Applicable only in the United States
Opening or closing the power sunroof

Fig. 34 In the headliner: Rotary switch for the power sunroof. (A) Turn the rotary switch to slide the sunroof
open or closed. (B) Press or pull the switch to tilt open or to close.

Function Switch position Action
To tilt open the tilting roof
fully:
(4) Push the rear part of the switch briefly.
To stop the one-touch
feature:
(4) or (5) Push or pull switch again briefly.
To set an intermediate
position: (4) to (5) Pull or push the rear part of the switch briefly
until the desired position is reached.
To close fully: (5) Pull the rear part of the switch briefly.

The power sunroof only works when the ignition is on. You can still open or close the power sunroof
for several minutes after you switch off the ignition, as long as the driver or front passenger door has
not been opened.
All procedures are interrupted as soon as the rotary switch is operated.
The sunshade opens automatically when the power sunroof opens if the shade was previously
completely closed or in front of the glass roof. The sunshade remains in the previous position and
does not close automatically with the sunroof. The sunshade cannot be closed completely until the
power sunroof is closed.
If your power sunroof will not close properly, do not try to close it yourself, doing so can cause serious
and expensive damage that will not be covered by any Volkswagen Limited Warranty. Special
knowledge and tools are required to close the power sunroof if it will not close on its own. To help
prevent damage to the sunroof, have an authorized Volkswagen dealer or an authorized Volkswagen
Service Facility help you close and repair the power sunroof.
.The comfort position provides sufficient ventilation without loud wind noise.
Applicable only in the United States
Opening or closing the sunshade

Fig. 35 In the headliner: Buttons for sunshade.

Function Response
To open fully (one-touch
feature): Briefly press the ⇒ fig. 35 (1) button.
To stop the one-touch
feature: Briefly press the (1) button or the (2) button.
To set an intermediate
position:
Keep the (1) button or (2) button pressed until the position has been
reached.
To close fully (one-touch
feature): Briefly press the (2) button.

You can still use the sunshade for several minutes after the ignition is switched off as long as the
driver or passenger door has not been opened.
When the power sunroof is completely open the sunshade is automatically moved to a ventilation
position.
When the power sunroof is in the tilt position the sunshade will also open a small gap.
When the power sunroof is open, the electrical sunshade can only be closed up to the front edge
of the glass roof.
Applicable only in Canada
Opening or closing the sunshade

Fig. 36 In the headliner: Buttons for sunshade.

Function Response
To close fully (one-touch
feature): Briefly press the (2) button.

You can still use the sunshade for several minutes after the ignition is switched off as long as the
driver or passenger door has not been opened.
When the power sunroof is completely open the sunshade is automatically moved to a ventilation
position.
When the power sunroof is in the tilt position the sunshade will also open a small gap.
When the power sunroof is open, the electrical sunshade can only be closed up to the front edge
of the glass roof.
Power sunroof – convenience closing feature
