x Weight distribution is especially bad if the towing vehicle is empty and the trailer is loaded. If you
absolutely must drive with this combination, drive with extra CARe and at a reduced speed.
Starting off with a trailer on hills
Depending on how steep the hill is and the combined towing weight, a parked vehicle with trailer can
roll backwards when you first start moving.
When starting off with a trailer on a hill:
x Depress and hold the brake pedal.
x Pull and hold the G button to use the electronic parking brake to keep the vehicle and trailer from
rolling backwards.
x Put the transmission in Drive (D).
x Release the brake pedal.
x Drive ahead slowly at first.
x Do not release the G button until the engine has enough driving power for the vehicle to start
moving.
x Drive ahead slowly
.WARNING
Improper trailer towing can cause loss of vehicle control and serious personal injury.
x Driving with a trailer and CARrying heavy or bulky items changes the way the vehicle
handles and increases the distance it needs to stop safely.
x Always watch what is happening up ahead and around you. Brake earlier than you would
if you were not towing a trailer.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Reduce your speed even more than you otherwise would when going downhill and under
unfavorable load, weather, or wind conditions.
x Drive especially CARefully and accelerate gently. Always avoid sudden maneuvers and
hard braking.
x Be especially CAReful when passing other vehicles.
x Reduce speed immediately if the trailer shows even the slightest sign of swaying.
x Never try to stop the swaying by accelerating.
x Always obey speed limits. In some areas speed limits for vehicles towing trailers are lower
than for vehicles without trailers.

x Press the NAVInfotainment button twice in quick succession. After changing to the map display, the
main menu Navigation is displayed.
x Press the e function key to switch menu by menu from a navigation submenu to the Navigation
main menu.
x You can switch back and forth between the map view and the Navigation main menu by pressing
the NAVInfotainment button.
The Navigation main menu is displayed either in “normal” Destination mode or in Tour mode or as the
Waypoint navigation menu ⇒ fig. 201.
If Tour mode ⇒ fig. 161 is displayed .
If the Waypoint navigation menu is displayed .
Display of the last destination
In the upper third of the screen, the destination last used as route guidance is displayed.
x Briefly touch the display box to show the displayed destination in the detailed view.
x Press the New destinationfunction key followed by the + Addressfunction key to show the displayed
destination in the Address entry menu and edit it .
If no destination is displayed, this means no route guidance has been started or that the
destination memory has been deleted manually .
Function keys in the Navigation main menu

Function key: Effect
Options : Defines route options for calculating a route .
Position : opens the current position in the detailed view and displays the coordinates.
Store : stores the displayed position in the destination memory .
D: Stores the current position as a “Flagged destination” in the destination memory .
': Enter home address or show home address in the Navigation main menu .
New destination : opens the selection menu for entry of destination .
Memory: Opens a pop-up window for storing the current destination, loading stored destinations or
managing destinations .
Route: Opens options for route guidance .
Route list: Shows street names or street designations of the route section to be driven.
Remove area to avoid: Removes an entered route exclusion.
Avoid area: To enter a route exclusion.
Extras: opens a pop-up window.

Accept new stopover: for entering a stopover .
Tour mode: for switching to tour mode in order to drive to several destinations during route
guidance .
Offroad: for navigation in off-road areas (waypoint navigation) .
Start: Starts route guidance to the displayed destination .

On road : the start point for the route guidance will be reached using public roads as far as
possible.
Off-road : the start point for route guidance will be reached in off-road mode and any available
roads will not be used.

When route guidance starts, the system will switch to the map view.
An audible signal is given when the starting point of the waypoint tour has been reached.
During route guidance
Characteristics of the terrain are ignored during route guidance. A driving recommendation will be
given about 55 yards (50 meters) before reaching a turning point. You should therefore drive slowly
and follow recommendations for turning as far as possible!
Changes in the direction of travel will be given in relation to the current direction of travel, such as
.“Please travel in direction 9 o'clock!”.
The tendency of the direction of travel will be shown in the instrument cluster display using arrows.
Stopping route guidance
x Press the Infotainment button .NAV in the map display to open the Waypoint navigation
menu.
x Press the Stop function key.
Stopping waypoint navigation

Fig. 205 Waypoint navigation menu.
.

x Press the NAV Infotainment button or the ... ...function key to switch to the Navigation main
menu.
x In the Navigation main menu, press the NAV Infotainment button or MAP function key to switch
back to the map view.
The map is displayed in the most recently selected type (2D or 3D). 3D and “Autozoom” are activated
by default .
Alternative routes: Selecting a calculated route
In the Navigation settings menu, you can specify that 3 alternative routes are suggested on the
map after the start of route guidance. These 3 routes correspond to the available route criteria Fast,
Short and Economical route Route 1 corresponds to the current setting in this case.
x Select the required route by pressing on the right of the map.
The setting for the route criteria in the Route options menu is changed accordingly.
If no route is selected then route guidance starts automatically after about one minute, using the
setting selected in the Route options.
Interrupting route guidance
Active route guidance can be stopped and later resumed from the new vehicle position at any time in
the Navigation main menu.
x In the Navigation main menu, press the Stop function key ⇒ fig. 209.
x Press the Start function key to continue route guidance ⇒ fig. 206.
Provision of navigation recommendations

Fig. 210 3D map display during route guidance.

Lights
up Possible cause Proper response
Engine cannot be started with starter
button (Keyless Access).
Start the engine with the remote control
vehicle key. Take the vehicle to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility and have the
system checked.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn
on the emergency flashers, stop the engine, and use other warning devices to warn
approaching traffic.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Vehicle key positions in the ignition switch

Fig. 241 In the ignition switch: Vehicle key positions.
.

On Hybrid vehicles depending on the environmental conditions and the current operating state
of the vehicle, either the combustion engine will be started or pure electric departure will be
enabled. This leaves the combustion engine off for the time being. In both cases, the vehicle
REA DY indicator will be displayed in the instrument cluster ⇒ table .
To stop the engine, again turn the vehicle key to the left or right and release. vehicle key can
then be removed from ignition switch.
To switch off the engine, turn the vehicle key either clockwise or counterclockwise and release.
The vehicle key can be removed from the ignition switch when the transmission shift lever is in
the (P) position.
If you use the wrong key
If an unauthorized remote control vehicle key has been inserted into the ignition switch, it can be
removed as follows:
x The vehicle key cannot be removed from the ignition unless both the key and the selector lever
have been moved to the correct position. Press the release button on the transmission selector lever,
move the selector lever to the Park (P) position and release the button. The vehicle key can now be
removed.
.WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. The engine can be started and
vehicle systems such as the power windows can be operated, leading to serious personal
injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the
vehicle. The doors can be locked with the remote control vehicle key. This could result in
people being trapped in the vehicle in an emergency. For example, depending on the time of
year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat build-up in the passenger and luggage compartment of a parked vehicle can result in
temperatures in the vehicle that are much higher than the outside temperatures, particularly
in summer. Temperatures can quickly reach levels that can cause unconsciousness and
death, particularly to small children.
x Never remove the key from the ignition switch while the vehicle is moving or rolling to a
stop. The steering wheel will lock and you will not be able to steer or control the vehicle.
.Leaving the key in the ignition for a long time when the engine is not running will drain the
vehicle battery.
.Leaving the selector lever for a long period of time in any position other than Park (P) when the
ignition is switched off can drain the vehicle battery.
. The vehicle key can be removed from the ignition switch only when the transmission is in Park
.(P). You may have to press the release button on the transmission selector lever to put the lever into
Park (P).

.WARNING
“Starting fluids” can explode and can cause a “run-away” vehicle condition.
x Never use starting assist fluids.
.NOTICE
x You can damage the starter or the engine if you try to start the engine when the vehicle is
still moving, or if you try to restart the engine right after switching it off.
x Avoid high engine speeds, full throttle acceleration and heavy engine loads when the
engine is cold.
x Do not try to start the engine by pushing or towing the vehicle. Unburned fuel can get into
the catalytic converter and damage it. The steering column may also be locked.
.Do not let your vehicle warm up while standing; instead, start driving right away after making
sure that you have good visibility through all windows. This will help the engine reach operating
temperature faster and keep down emissions.
.If the battery in the remote control vehicle key is weak or dead, the engine cannot be started
with the starter button. In this case, remove the starter button from the ignition switch and insert the
remote control vehicle key into the ignition switch to start the vehicle.
.Major consumers of electricity are temporarily switched off when the engine is being started.
.After starting a cold engine, there may be increased operating noises for a few seconds. This is
normal and harmless.
Stopping the engine
.

Automatic Shift Lock (ASL)
The Automatic Shift Lock (ASL) in Park (P) and Neutral (N) prevents drive positions from being
engaged inadvertently, which would cause the vehicle to move.
To release the ASL, depress and hold the brake pedal with the ignition switched on. Press the release
button on the selector lever at the same time.
The ASL is not engaged if the selector lever is moved quickly through Neutral (N) (e.g., when shifting
from Reverse (R) to Drive (D)). This makes it possible to “rock” the vehicle backwards and forwards if
it is stuck in snow or mud. The ASL engages automatically if the brake pedal is not depressed and the
lever is in Neutral (N) for more than about 1 second and the vehicle is traveling no faster than about
3 mph (5 km/h).
.WARNING
Moving the selector lever to the wrong position can cause loss of vehicle control, a collision,
and serious personal injury.
x Never accelerate when moving the selector lever.
x When the engine is running and a drive position is engaged, the vehicle will start to move
as soon as the brake pedal is released.
x Never shift into Reverse or Park when the vehicle is moving.
.WARNING
Unintended vehicle movement can cause serious personal injury.
x Never get out of the driver's seat while the engine is running, especially when the
transmission is in a drive gear. If you must leave your vehicle while the engine is running,
always set the electronic parking brake and shift the transmission into Park (P).
x Never leave the vehicle in Neutral (N). It will roll down hills, whether the engine is running
or not.
x When the engine is running and a drive gear - Drive .(D), Sport Drive (S), or Reverse (R) -
has been selected, press and hold the brake pedal to keep the vehicle from moving. The
vehicle may “creep” and move forward or backward even if the engine is idling slowly.
x Never shift into Reverse .(R) or Park (P) when the vehicle is moving.
.NOTICE
Even though the transmission is in Park (P), the vehicle may move a couple of inches (a few
centimeters) forwards or backwards if you take your foot off the brake pedal after stopping the
vehicle without first setting the electronic parking brake.
.If the selector lever is moved into Neutral (N) by mistake when the vehicle is moving, take your
foot off the accelerator pedal. Wait until the engine speed has dropped to idle speed before moving
the selector lever into a drive gear.
.Leaving the selector lever for a long period of time in any position other than Park (P) when the
ignition is switched off can drain the vehicle battery.
