.NOTICE
Even though the transmission is in Park (P), the vehicle may move a couple of inches (a few
centimeters) forwards or backwards if you take your foot off the brake pedal after stopping the
vehicle without first firmly setting the parking brake.
.If the vehicle battery is dead, the electronic parking brake cannot be released. Use a jump-start
.
.You may hear noises when setting or releasing the electronic parking brake.
.If the electronic parking brake is not used for a while, an automatic system check will
occasionally run when the vehicle is parked. This system check makes audible noises.
Parking
.
Removing the engine compartment cover requires a certain degree of skill. If you have any doubts at
all, Volkswagen recommends having the cover removed by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
Jump-starting
If the 12 Volt electrical system is not working because the 12 Volt vehicle battery is dead, the hybrid
vehicle can be started with the high-voltage hybrid battery if its charge is adequate. For this purpose,
the vehicle has jump start terminals in the engine compartment. You must open the opening for jump
starting. ⇒ fig. 259 (5) in the cover ⇒ fig. 259 (3) to get to the jump-start terminals in the engine
compartment .
Hybrid warning labels
There are additional warning labels that warns against touching hybrid system components. The
warning labels are placed:
x on each high-voltage component for example in the engine compartment or underneath the
luggage compartment ⇒ fig. 257 A.
x in the engine compartment on the hood latch CARrier B.
For procedures regarding stickers and labels .
.NOTICE
When refilling operating fluids, make sure not to confuse them. Otherwise serious
malfunctions and engine damage can occur!
Removing and installing engine compartment cover
Fig. 259 Engine hood open: Engine compartment cover.
.
Explanation of fig. 259:
(1) Center cover.
(2) Right cover.
(3) Left cover.
(4) Retainers.
(5) Opening for jump starting.
(6) Warning label for high-voltage hybrid components.
(7) Engine compartment seal.
Engine compartment covers (1) and (3) must be removed in the following situations:
x Changing light bulbs in the left headlight assembly.
Engine compartment covers (1) and (2) must be removed in the following situations:
x Changing light bulbs in the right headlight assembly.
x Adding engine coolant to the low temperature coolant circuit .
Removing engine compartment cover
When removing any part of the engine compartment cover, always pull CARefully on the relevant
attachment points ⇒ .
x Open the engine hood
.WARNING
High voltage systems in the engine compartment can cause electrical shocks or even
electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially CAReful when using jumper
cables. The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the engine is running or
being started:
– Never touch ignition cables. Never touch other components of the high-voltage
electronic ignition system.
– Never touch the wiring of the HID - High Intensity Discharge (Xenon) headlights.
.WARNING
Moving parts in the engine compartment can cause serious personal injury on contact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can
cause serious personal injury. Always remember that the radiator fan is temperature-
controlled and can come on suddenly even when the engine has been switched off for a while
and the key has been removed from the ignition.
x If you have to perform a check or repair when the engine is running, there are more risks
from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the
high-voltage ignition system. Always use extreme CARe.
– Always make sure that jewelry, loose clothing and long hair do not get caught in
rotating engine parts. Before starting any work remove your jewelry, take off your necktie,
tie back and cover your hair, and do not wear clothing that can hang down and get caught
in moving engine parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a
check. The vehicle will start to move even if the parking brake is on.
x Never leave any objects in the engine compartment, for example cleaning rags and tools.
Objects left behind can cause malfunctions, engine damage, and even fires.
.WARNING
Operating fluids and some materials in the engine compartment can catch fire easily, causing
burns and other serious personal injuries!
x Do not smoke.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the engine. These fluids
can ignite on hot engine parts and cause injuries.
x If work on the fuel system or the electrical system is necessary:
– Always disconnect the 12 Volt vehicle battery. Make sure the vehicle is unlocked when
you disconnect the battery, or the alarm will go off. Never touch the electrical wiring of the
ignition system.
– Never work near heaters, water heaters, or other open flames.
x Always have a functional, approved fire extinguisher nearby.
