The red zone at the end of the scale indicates maximum permissible engine rpm (revolutions
per minute) for all gears after the break-in period. Before reaching this region, select the next
higher selector level position .(D), or ease your foot off the accelerator⇒ .
(3) Displays
(4) Speedometer
(5) Reset button for the trip odometer display (trip) and button to display the engine code.
– Push and hold the 0.0 .button about 1 second in order to reset to zero.
– Push the 0.0 .button again and hold it for about 3 seconds to display the previous value.
– Push and hold the 0.0 .button for more than 10 seconds to display the vehicle's engine
code. You must do this when the ignition is on, but the engine is not running.
(6) Fuel gauge
.NOTICE
x To help prevent engine damage, always avoid high engine speeds, full throttle acceleration
and heavy engine loads when the engine is cold.
x To help prevent engine damage, the tachometer needle should only enter the red zone
(warning zone) briefly.
.Up-shifting early into the next higher gear saves fuel and reduces engine noise.
Applicable only in Canada
Instrument overview

Fig. 11 Instrument cluster in the instrument panel.

(5) Reset button for the trip odometer display (trip) and button to display the engine code.
– Push and hold the 0.0 .button about 1 second in order to reset to zero.
– Push the 0.0 .button again and hold it for about 3 seconds to display the previous value.
– Push and hold the 0.0 .button for more than 10 seconds to display the vehicle's engine
code. You must do this when the ignition is on, but the engine is not running.
(6) Fuel gauge
.NOTICE
x To help prevent engine damage, always avoid high engine speeds, full throttle acceleration
and heavy engine loads when the engine is cold.
x To help prevent engine damage, the tachometer needle should only enter the red zone
(warning zone) briefly.
.Up-shifting early into the next higher gear saves fuel and reduces engine noise.
Displays

Fig. 12 In the instrument cluster display: A: Open engine hood, B: Open rear hatch, C: Open front driver side
door, D: Open rear passenger side door.

.Do not reset the service reminder between service intervals; otherwise, incorrect information
will be displayed.
.The service reminder disappears after a few seconds when the engine is running or the
OK button on the multi-function steering wheel has been pushed.

x Stop the opening process at the desired opening angle.
x Press the .button in the open rear hatch ⇒  for at least 3 seconds. This saves the opening
angle.
The warning flashers will blink and a chime will sound to confirm that the angle has been saved.
To completely open the rear hatch again you must first save a new opening angle.
x Unlock the rear hatch and open it to the saved position.
x Manually push open the rear hatch as far as it will go. This requires some strength.
x Press the .button in the open rear hatch for at least 3 seconds.
x The opening angle has been reset to the factory setting.
.WARNING
Improper or unsupervised closing of the rear hatch can cause severe injuries.
x Never leave your vehicle unattended or let children play around your vehicle, especially
with the rear hatch left open. A child could crawl into the vehicle and pull the rear hatch shut,
becoming trapped and unable to get out. A closed vehicle can become very hot or very cold
depending on the season. Temperatures can quickly levels that can cause unconsciousness
or death, particularly to small children.
.WARNING
A closed rear hatch cannot open completely and an open rear hatch cannot close
automatically if a luggage rack is installed on it or if it is covered by a heavy layer of snow. In
this case, you will have to hold the rear hatch or prop it up to keep it open.
.NOTICE
Before opening or closing the rear hatch, make sure there is enough room to do so, as for
example when the vehicle has a trailer or is in a garage.
.NOTICE
x Remove any luggage or bicycle rack mounted on the rear hatch before opening the hatch.
.NOTICE
If the system is operated too often in succession, it will shut itself off to help prevent
overheating.
x The feature can be used again as soon as the system has cooled down. In the meantime,
the rear hatch can be opened or closed by hand, though this requires some strength.
x If the vehicle battery or the fuse is blown when the rear hatch is open, the rear hatch system
must be reset. To reset the rear hatch, it must be closed once.
Make sure that the remote control vehicle key is not in the luggage compartment before closing
the rear hatch.

Enabling and disabling the “Coming home” and “Leaving home” functions
The “Coming home” and “Leaving home” functions can be enabled or disabled in the Infotainment
System.
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select the menu item External lightingin the list.
x Tap Leaving homeor Coming hometo enable or disable the feature.
The feature is enabled when the check box in the Leaving homeor Coming homefunction key is checked =.
Switching the “Coming home” and “Leaving home” functions on and off
The “Coming home” feature must be switched on manually. The “Leaving home” feature is
automatically controlled by a low-light sensor.

“Coming home” Action
Switch on: – Switch off the ignition.
– Operate the headlight flasher for about 1 second.
Opening the driver door switches on the “Coming home” feature. The delay
period starts when the last vehicle door or the rear hatch is closed. The
“Coming home” lighting is switched on when the driver door is open, the
headlight switch is set to AUTO, and the low light sensor detects darkness.
The delay period starts once the last vehicle door or the rear hatch is closed.
Switch off: – Automatically after the preset delay period is over.
– Automatically if any door or the rear hatch is still open about 60 seconds
after activation.
– Turn the light switch to the  position.
– Switch on the ignition.


“Leaving home” Action
Switch on: – Unlock the vehicle when the light switch is not in the O position and the low-
light sensor registers darkness. Unlock the vehicle if the light switch is in the
AUTO position and the low-light sensor registers darkness.
Switch off: – Automatically after the preset delay period is over.
– Lock the vehicle.
– Turn the light switch to the / position.
– Switch on the ignition.

Background lighting in the outside mirrors
The background lighting in the outside mirrors lights up the area close to the doors while you are
getting into or out of the vehicle. It is switched on when the vehicle is unlocked, a vehicle door is
opened, or the “Coming home” or “Leaving home” feature is activated. If the vehicle is equipped with a
light sensor, the background lighting in the outside mirrors is only switched on in darkness.

Changes made in settings menus are automatically applied once the menu is closed.

Function key: Effect
Dynaudio Confidence: Dynaudio Confidence settings
Treble - Bass: Changing sound character. Change settings by moving the slider ?.
Balance - Fader: Changing the sound focus
Volume: Volume settings
= Speed-dependent volume adjustment: If the speed-dependent volume is activated, the audio volume is
automatically raised as the vehicle speed increases.
When speed-dependent volume is switched on in vehicles with Dynaudio Confidence®,the volume
of individual frequencies is automatically raised or reduced depending on the road noise caused by
the rising vehicle speed. This “reduces” the road noise in the vehicle.

Changing the sound focus (balance and fader) using the vehicle diagram
x Press the Balance – Fader function key.
The crosshair in the vehicle diagram shows the current sound focus in the vehicle interior.
x Place your finger on the crosshair and, without lifting it off, drag it across the screen. Lift your finger
off the screen once the sound focus is in the required position
x OR: Press the point in the interior view where you want the sound focus to be.
x OR: Move the sound focus step by step by pressing the arrow buttons on the left of the screen.
Press the function key between the arrow buttons to return the sound focus to the center of the interior
view.
Changing volume settings and adjustments
It is possible to preset some volume settings and adjustments.
x In the Setup Tone main menu, press the Volume function key.
x Press one of the function keys in the Volume settings menu to open the corresponding settings
menu.
Telephone 1):Set output volume for telephone calls in the vehicle.
Voice guidance: Set output volume for navigation announcements during route guidance
Reduced audio volume: Set by how much the volume of other audio sources should be reduced during an
announcement (navigation, voice operation) or a telephone call1. While you adjust the volume
reduction, the volume of the currently active audio source is reduced at the level of the setting as you
change it.
While you adjust volume settings, the corresponding audio source is played at the level of the setting
as you change it.
Dynaudio Confidence®
Additional settings are available if the vehicle is equipped with the RNS 850 and Dynaudio.
x In the Sound settings main menu, press the Dynaudio Confidencemain menu.
Press one of the function keys in the Dynaudio settings menu to open the corresponding settings
menu.
Sound focus: Optimize sound effects, frequency ranges and sound focus for different sitting positions in
the vehicle.
Surround: Set level of surround effect.

Selecting stations stored to station buttons

Fig. 140 RADIO main menu: Preset 4 selected.
.

Function key: Effect
£ Station list: All available stations and channels can be browsed in sequence with the arrow
buttons.
£ Presets: Only stations and channels that are stored to station buttons can be browsed with the
arrow buttons.
Presets: Select the station buttons to be displayed
Press one of the functions buttons Presets x...xto display the desired group of station buttons in
the main menu RADIO.
= HD radio: HD radio is activated
Delete Presets: When Delete is pressed, all stations and channels stored to station buttons are deleted.
SIRIUS ID: Displays the Sirius ID
Sort stations: the station list shows all satellite stations as selected:
Station number : in the all categories view arranged according to channel number.
Category/Station name : in the category view arranged according to station name.
Category/Station no. : in the category view arranged according to channel number.
Station name : in the all categories view arranged according to station name.
Category filter: restrict selection of stations to certain categories.
If the check box in the = Category filter on function key is deactivated, all categories are
displayed and all stations can be selected.
