Locking the vehicle after airbag inflation
If the airbags are activated during a collision, the entire vehicle is unlocked. Depending on the severity
of the damage, the vehicle can be locked after a collision when the airbags have deployed as follows:

Function Action
Locking the vehicle with the
power locking switch:
– Switch the ignition off.
– Open a door once.
– Press power locking switch 1
Locking the vehicle with the
remote control vehicle key:
– Switch the ignition off and on again.
OR: Remove the remote control vehicle key from the ignition.
– Open a door once.
– Lock the vehicle with the remote control vehicle key.

Indicator light in the driver door

After the vehicle is locked: Meaning
The red LED light flashes for about 2 seconds in short
intervals, then slower.
The vehicle is locked.
Red LED light lights up continuously for about 30 se-
conds.
Locking system malfunction. See an
authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.

.If the remote control vehicle key buttons or one of the power locking buttons are pushed repeat-
edly in quick succession, the power locking system is switched off for a brief period to help keep it
from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened during this time, the vehicle is automatically locked afterwards.
Unlocking and locking the vehicle from the outside

Fig. 23 Buttons in the remote control vehicle key.
.


One or more driving lights not working or
cornering light malfunction.
Replace burned out bulb or
if all light bulbs are OK, visit an authorized
Volkswagen dealer or authorized Volkswagen
Service Facility.
Adaptive Front Lighting System
malfunction.
8 One or more brake lights burned out.
Replace the light bulb that isn't working. If all
light bulbs are OK, see an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.

Adaptive Front Lighting System (AFS)
malfunction.
See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
 Headlight range adjustment malfunction. See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
 Parking lights switched on.
; All license plate lights not working.
Replace the light bulbs that aren't working. If
all light bulbs are OK, see an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
Fog lights switched on.



Left or right turn signal.
If necessary check the vehicle and trailer
lighting. The indicator light blinks twice as fast if a
turn signal is not working on the vehicle
or the trailer.
 Daytime running lights (DRL) on.
$2,
 High beams switched on or headlight
flashers in use.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, stop
the engine, turn on the emergency flashers, and use other warning devices to warn
approaching traffic.
x Never park the vehicle in areas where the hot catalytic converter and exhaust system can
come into contact with dry grass, brush, spilled fuel, oil, or other material that can catch fire.
x A broken down vehicle presents a high accident risk for itself and others. Switch on
emergency flashers and set up a warning triangle to warn oncoming traffic.

Lights
up
Possible cause Proper response
F Rain sensor malfunction.
Switch ignition off and on again. If the
indicator light comes on again and stays on,
contact an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility .
W Windshield and/or rear window wiper
malfunction.
Switch ignition off and on again. If the
indicator light comes on again and stays on,
contact an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility.
Y Windshield and rear window washer fluid
level too low.
Refill windshield washer reservoir at the next
opportunity.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 90 Operating the front windshield wiper.

Fig. 91 Operating the rear wiper.

Lights
up Possible cause Proper response
Engine cannot be started with starter
button (Keyless Access).
Start the engine with the remote control
vehicle key. Take the vehicle to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility and have the
system checked.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn
on the emergency flashers, stop the engine, and use other warning devices to warn
approaching traffic.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Vehicle key positions in the ignition switch

Fig. 241 In the ignition switch: Vehicle key positions.
.

Lights up Possible cause Proper response
h È BRAKE Hill Hold malfunction.
Take the vehicle to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility and have the
system checked.
k Hill Descent Assist switched on. .


Flashes Possible cause Proper response
k Hill Descent assist is regulating the
speed. .

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Hill Hold
.

Switching Park Distance Control on and off manually
x Push the  or ∗ .button once when the ignition is switched on to switch Park Distance Control
on.
x Push the  or ∗ .button again when the ignition is switched on to switch Park Distance Control
off.
The indicator light in the button comes on and stays on as long as the feature is active. The indicator
light in the button comes on and stays on as long as the feature is active.
Switching Park Distance Control on and off automatically
x Automatic activation: Shift into reverse.
x OR: Drive forward slowly (less than about 6 - 9 mph /10 - 15 km/h) and approach to within about
38 inches (95 cm) of an obstacle.
x OR: If the vehicle rolls backwards.
x Automatic deactivation: Drive faster than about 6-9 mph (10 - 15 km/h).
A chime sounds to tell you that the system is on. If the chime does not sound, PDC is not working.
Have the system inspected by an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an
obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System .
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is
engaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an
authorized Volkswagen Service Facility.
.WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
.If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light
in the button starts blinking, this means there is a malfunction in the Park Distance Control system.
Switch off the Park Distance Control system with the button and have it immediately checked by an
authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

Automatic window fog detection
Automatic window fog detection checks whether the windows are fogged up and if necessary
automatically adjusts the air flow to the windshield and side windows or switches on the windshield
heating. If the fan or the air conditioner AC is turned off, automatic window fog detection cannot work
properly.
Residual heat mode
The residual engine heat can be used for a limited time to heat the passenger compartment when the
ignition is switched off.
x Switch off the ignition.
x Push the REST .button. The feature will appear in the Climatronic display.
x Press the REST .button again to switch the feature off early.
The feature is switched off if it is draining the battery too much, and it does off automatically after 30
minutes. The fan speed is reduced to save energy.
Applying driver settings to all climate zones
The driver-side settings for temperature, fan speed, and air distribution can be applied to all of the
other climate zones.
x Push the SYNC .button. The indicator light in the button lights up and the changes are applied to
all climate zones.
x Push the SYNC .button again to cancel the feature.
The synchronization feature is deactivated if individual settings are entered for one of the other
climate zones using the Climatronic control unit. In this case, the indicator light in the SYNC .button
goes out.
Air conditioner does not work
The air conditioner may not switch on for one the following reasons:
x The engine is not running (or a hybrid vehicle is not ready to drive).
x The fan is turned off.
x The air conditioner fuse has blown.
x The ambient air temperature is colder than +38 °F (+3 °C).
x The air conditioner compressor has been temporarily switched off due to excessive engine coolant
temperature.
x There is another malfunction in the vehicle. Have the air conditioner checked by an authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
Special considerations
When it is very hot and humid outside, water condensation can drip from the air conditioner
evaporator and form a puddle under the vehicle. This is normal and does not indicate a leak.
The climate control system adjusts the passenger compartment temperature as fast as possible
considering the outside temperature.
Due to residual moisture in the air conditioner, the windshield may fog up after the engine is
started. Switch on the windshield defroster to help evaporate the condensation as quickly as possible.
The air coming out the vents and flow through the passenger compartment and out through the
vents below the rear window. Do not cover these slots with clothing or other objects.

Lights up Possible cause or meaning ⇒  Proper response
b No engine restart possible! AdBlue fill
level too low.
Stop the vehicle at a safe and appropriate
place with level pavement and refuel
AdBlue
b
No engine restart possible! AdBlue-
system malfunction.
Have the system checked by an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
together
with
>
b AdBlue level is low.
Refill the AdBlue tank within the indicated
number of miles or kilometers Volkswagen
recommends going to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
b
AdBlue system malfunctioning or not
filled standard AdBlue.
Have the system checked by an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
together
with
>
b AdBlue level is low.
Refill the AdBlue tank within the indicated
number of miles or kilometers Volkswagen
recommends taking the vehicle to an
authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
b
AdBlue system malfunctioning or not
filled standard AdBlue.
Have the system checked by an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility.
together
with
>

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
AdBlue information
.
