2013 VOLKSWAGEN TOUAREG window

Side view

Fig. 1 Vehicle side overview.
Key to fig. 1:
(1) Fuel filler flap
(2) Side window with window diversity antenna for:
– Radio
– Central locking
(3) Roof antenna for:
– Cell phone
– Navigation
(4) Roof rack
(5) Outside door handle
(6) Outside mirror
– Additional turn signal light
(7) Lift points for the jack
(8) Receiver for the trailer hitch

Rear view

Fig. 3 Vehicle rear overview.
Key to fig. 3:
(1) Roof antenna for:
– Cell phone
– Navigation
(2) High-mounted brake light
(3) Rear window
– Rear window defroster
(4) Rear window wiper
(5) Taillights
(6) Area of:
– Button to open the rear hatch
– Camera of the Rear Assist
– License plate lighting
(7) Rear license plate bracket
(8) Sensors for rear Park Distance Control
(9) Rear towing eye mount behind a cover
(10) Receiver for the trailer hitch

– Rear window wiper Z
– Automatic wipe/wash for rear window \
– Lever with buttons for the Volkswagen Information System (Basic version) 42)0- , /+/2%3%4
(6) Fog light button
(7) Headlight switch

x OR: The rear hatch is opened.
x OR: The vehicle is mechanically unlocked using the emergency vehicle key.
Convenience features
To use the convenience closing feature to close all power windows, hold your finger on the lock sensor
surface ⇒ fig. 25 (2) on the outside of the door handle for a few seconds until the windows close.
Remove your finger from the lock sensor surface (2) to stop the function. If you touch the unlock
sensor surface 1 on the inside of the door handle immediately after releasing the lock sensor surface 1
(arrow), all of the windows will open (safety function). Pinch protection is active during convenience
closing of the windows.
The settings in the Settings – Convenience menu determine which doors open when the door
handle sensor surface is touched.
.CAUTION
If a valid vehicle key is within range of the rear hatch, the Easy Open feature can deploy unin-
tentionally in some cases and open the rear hatch: for example, when sweeping the ground
or floor below the rear bumper, if there is a strong stream of water or steam or when CARry-
ing out maintenance or repairs around the rear bumper. If the rear hatch opens unintentional-
ly, it can injure anyone or damage anything in its way.
x Never leave a valid vehicle key within range of the rear hatch unattended.
.NOTICE
The door handle sensor surfaces can be activated by a strong stream of water or steam if a
valid vehicle key is within range of the vehicle. All windows may open if you turn the spray of
water or steam away from and then back onto the door handle sensor surface in quick succes-
sion.
.The door may not open if the outside and inside door handles are used at the same time.
.If the automatic transmission is not in Park (P) position, the electronic steering column lock will
not lock and the vehicle will not lock via sensors in the front door handles or the remote control vehicle
key.
.If the vehicle battery or the battery in the remote control vehicle key is weak or dead, it might not
be possible to unlock and lock the vehicle using Keyless Access The vehicle can still be manually
locked or unlocked with the emergency key.
.The driver message Key not in range appears in the instrument cluster display if there is
no remote control vehicle key inside the vehicle or if the system does not recognize the remote control
vehicle key. The key may not be recognized, for example, if it is covered by something that interferes
with the signal (such as a briefcase), or if the remote control vehicle key battery is weak. Electronic
devices such as cell phones can also interfere with the signal.
.Dirt on the door handles that contains a lot of salt (especially in winter) can affect the way the
door handle sensors work. Cleaning the door handles can help with this problem.

Power windows

Switches in the driver door
Key to fig. 32:
(1) For the windows in the front doors.
(2) For the windows in the rear doors.
(3) Safety switch.
Opening or closing windows

Function Action
Opening: Press the switch.
Closing: Pull the switch
Stopping automatic
movement:
Press/pull the switch again.
v
The safety switch (left/right) (3) deactivate the left
hand and right hand power windows in the rear
doors. The yellow indicator light in the switch lights
up when activated. The electric child safety locks
also prevent the rear doors from being opened from
the inside.

The power windows operate only when the ignition is switched on.
You can still use the power windows for several minutes after the ignition is switched off as long as the
driver or front passenger door has not been opened. When the vehicle key has been removed from
the ignition and the driver door has been opened, the power windows cannot be opened or closed.
.A separate button for controlling the window is located in the front passenger door.
Power windows – features

Function Using the remote control vehicle key
Convenience
opening Press and hold the unlock button on the remote control vehicle key.
Convenience closing Press and hold the lock button on the remote control vehicle key.

From outside the vehicle (vehicles with Keyless Access), hold your finger on the lock sensor surface
on the outside of the door handle for a few seconds until the windows close.
Convenience closing closes the windows first and then the power sunroof.
The Infotainment System can be used to set various convenience opening options.
Setting convenience opening options in the Infotainment System
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select Remote control keyfrom the list.
If the check box in a function key is checked =, the feature is switched on.

Function key: supplementary information
= Front windows: Convenience opening opens front windows. Tap the function key to deactivate the
feature.
= Rear windows: Convenience opening opens rear windows. Tap the function key to deactivate the
feature.

.WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power
windows for several minutes after the ignition is switched off as long as the driver or front
passenger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power
windows and keep them from being opened and closed.
.If the power windows malfunction, the one-touch feature, as well as pinch protection will not
work properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
right away.
.Convenience closing of the power windows from the outside requires removing the cover cap of
the lock cylinder on the driver door. The cover cap must be reinstalled after the vehicle is locked.

Not wearing or improperly fastening safety belts increases the risk of severe or fatal injuries. Safety
belts can work only when they are properly positioned on the body. An improper seating position
significantly impairs the protection provided by safety belts. This can cause severe or even fatal
injuries. Improper seating positions also increase the risk of serious injury or death when an airbag
deploys and strikes an occupant who is not in the proper seating position. The driver is responsible for
all passengers and especially children riding in the vehicle.
The following are only some examples of seating positions that will increase the risk of serious injury
or death.
Therefore, whenever the vehicle is moving:
x Never stand up in the vehicle.
x Never stand on the seats.
x Never kneel on the seats.
x Never ride with the seat backrest reclined.
x Never lean up against the instrument panel.
x Never lie down on the rear seat.
x Never sit on the edge of the seat.
x Never sit sideways.
x Never lean out the window.
x Never put your feet out the window.
x Never put feet on the instrument panel.
x Never rest your feet on the seat cushion or back of the seat.
x Never ride in the footwell.
x Never sit on the front or rear center armrests.
x Never ride without your safety belt properly fastened.
x Never ride in the luggage compartment.
.WARNING
Contact with parts of the vehicle interior can cause serious personal injury in a crash.
x Always make sure that all vehicle occupants stay in a proper seating position and are
properly restrained whenever the vehicle is moving.
x Improper seating positions increase the risk of serious and fatal injury, especially when an
airbag deploys and strikes a passenger in an improper seating position.
