2013 VOLKSWAGEN TOUAREG alarm

.NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
.Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
.Remote control vehicle key functions can be temporarily disrupted by interference from trans-
mitters near the vehicle that use the same frequency range (such as radio equipment or cellular
phones).
.Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
.If the remote control vehicle key buttons or the power locking buttons ⇒ fig. 24 are pushed
repeatedly in quick succession, the power locking system is switched off for a brief period to help keep
it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Emergency key

Fig. 18 Releasing the emergency key and removing it from the remote control vehicle key.

Fig. 19 Releasing the emergency key and removing it from a remote control vehicle key with a panic button.

Press button ⇒ fig. 24:
0 Unlock the vehicle.
1 Lock the vehicle.

The power locking switch works whether the ignition is switched on or off, but only when all doors are
closed.
If the vehicle is locked with the remote control vehicle key, the power locking switch is deactivated.
If the vehicle is locked with the power locking switch:
The indicator light 1 in the power locking switch comes on to indicate that all doors and the rear hatch
are locked.
x The anti-theft alarm system is not turned on.
x Opening doors or the rear hatch from the outside is not possible, at a traffic light, for example.
x Doors can be unlocked and opened separately from inside the vehicle by pulling the door handle to
open the door. The indicator light 1 goes out. The unopened doors and rear hatch remain locked and
cannot be opened from the outside.
x An open driver door will not be locked. This helps keep the driver from being locked out of the
vehicle.
The vehicle is unlocked if you push the 0 button while the vehicle is standing still. Depending on the
settings in the Convenience sub-menu, it may also be unlocked when you take the vehicle key out of
the ignition or, on vehicles with Keyless Access, when you open the driver door (Auto. open).
Unlocking or locking vehicles with Keyless Access

Fig. 25 (A) Ranges of the Keyless Access locking and starting system. Outside the vehicle: Unlocking range.
Inside the vehicle: starting range. (B) Keyless Access locking and starting system: Sensor 1 for unlocking on
the inside of the front door handles. Sensor for locking on the outside of the door handles 2.

Anti-theft alarm system

The buttons 1, 2, and 3.on the roof keypad ⇒ fig. 37 between the sun visors can operate up to 3
separate remote control devices (for example, a gate and garage door, a house alarm, or a lighting
system).
Getting ready to program
x Please read the product manufacturer's instructions before programming the garage door opener
or other device.
x Safely park the vehicle within range of the device to be programmed.
x Switch the ignition on, but do not start the engine.
Menu Garage door opener in the Infotainment System
Call up the Garage door opener menu in the Infotainment System ⇒ fig. 38.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select Garage door openerfrom the list.

Function key: Effect
Program buttons: Buttons 1, 2 or 3 can be programmed after you tap the function key. Follow the
instructions on the Infotainment System screen.
Delete button assignment: Deletes the programming of buttons 1, 2, and 3⇒ fig. 37.
Version information: Most recent programming information for your authorized Volkswagen dealer or
authorized Volkswagen Service Facility.

Programming information
You must complete the programming process within 5 minutes. If you exceed this time limit, the
programming is cancelled.
If programming is cancelled, a red LED lights up in the keypad and the turn signals flash once.
Programming unassigned buttons
x Complete the programming preparation steps described above.
x Press unassigned button in the roof keypad .
x Follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3
times.
Repeat these steps with another unassigned garage door opener button to use that button to control
another device.
Programming previously assigned buttons
x Complete the programming preparation steps described above.
x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Garage door opener from the list.
x Tap the Program button function key and follow the instructions on the Infotainment System screen.
The orange LED in the keypad also blinks to indicate that programming is in progress.
If programming is successful, a green LED in the keypad will light up and the turn signals will flash 3
times.

.WARNING
High voltage systems in the engine compartment can cause electrical shocks or even
electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially CAReful when using jumper
cables. The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the engine is running or
being started:
– Never touch ignition cables. Never touch other components of the high-voltage
electronic ignition system.
– Never touch the wiring of the HID - High Intensity Discharge (Xenon) headlights.
.WARNING
Moving parts in the engine compartment can cause serious personal injury on contact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can
cause serious personal injury. Always remember that the radiator fan is temperature-
controlled and can come on suddenly even when the engine has been switched off for a while
and the key has been removed from the ignition.
x If you have to perform a check or repair when the engine is running, there are more risks
from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the
high-voltage ignition system. Always use extreme CARe.
– Always make sure that jewelry, loose clothing and long hair do not get caught in
rotating engine parts. Before starting any work remove your jewelry, take off your necktie,
tie back and cover your hair, and do not wear clothing that can hang down and get caught
in moving engine parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a
check. The vehicle will start to move even if the parking brake is on.
x Never leave any objects in the engine compartment, for example cleaning rags and tools.
Objects left behind can cause malfunctions, engine damage, and even fires.
.WARNING
Operating fluids and some materials in the engine compartment can catch fire easily, causing
burns and other serious personal injuries!
x Do not smoke.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the engine. These fluids
can ignite on hot engine parts and cause injuries.
x If work on the fuel system or the electrical system is necessary:
– Always disconnect the 12 Volt vehicle battery. Make sure the vehicle is unlocked when
you disconnect the battery, or the alarm will go off. Never touch the electrical wiring of the
ignition system.
– Never work near heaters, water heaters, or other open flames.
x Always have a functional, approved fire extinguisher nearby.
