Lower front center console

Fig. 7 Overview of lower front center console (4MOTION).
Key to fig. 7:
(1) Automatic transmission selector lever
(2) Storage compartment
– with 12 Volt socket
(3) Starter button for Keyless Access locking and starting system 34!24 – 34/0
()
(4) Button for:
– Electronic parking brake G
(5) Button for:
– Driving with electric motor %--/$%
– Anti-slip regulation (ASR) m
(6) Rotary knob for setting drive mode (On-road / Off-road)
(7) Cup holders
(8) Storage compartment in the center armrest

Press button ⇒ fig. 24:
0 Unlock the vehicle.
1 Lock the vehicle.

The power locking switch works whether the ignition is switched on or off, but only when all doors are
closed.
If the vehicle is locked with the remote control vehicle key, the power locking switch is deactivated.
If the vehicle is locked with the power locking switch:
The indicator light 1 in the power locking switch comes on to indicate that all doors and the rear hatch
are locked.
x The anti-theft alarm system is not turned on.
x Opening doors or the rear hatch from the outside is not possible, at a traffic light, for example.
x Doors can be unlocked and opened separately from inside the vehicle by pulling the door handle to
open the door. The indicator light 1 goes out. The unopened doors and rear hatch remain locked and
cannot be opened from the outside.
x An open driver door will not be locked. This helps keep the driver from being locked out of the
vehicle.
The vehicle is unlocked if you push the 0 button while the vehicle is standing still. Depending on the
settings in the Convenience sub-menu, it may also be unlocked when you take the vehicle key out of
the ignition or, on vehicles with Keyless Access, when you open the driver door (Auto. open).
Unlocking or locking vehicles with Keyless Access

Fig. 25 (A) Ranges of the Keyless Access locking and starting system. Outside the vehicle: Unlocking range.
Inside the vehicle: starting range. (B) Keyless Access locking and starting system: Sensor 1 for unlocking on
the inside of the front door handles. Sensor for locking on the outside of the door handles 2.

Unlocking and locking the rear hatch (Keyless Entry for the rear hatch)
If the vehicle is locked and a valid vehicle key is within range A of the rear hatch, it unlocks automati-
cally when opened.
x Open and close the rear hatch as you would a standard rear hatch.
The rear hatch locks automatically when it is closed except in the following situations:
x The vehicle is completely unlocked.
x When an authorized vehicle key is inside the vehicle.
Sensor-controlled rear hatch opener (Easy Open)
When a valid vehicle key is within range A of the rear hatch, the rear hatch can be unlocked and
opened by moving your foot within the sensor’s range ⇒ fig. 26 below the rear bumper.
x Switch off the ignition and remove any vehicle key in the ignition.
x Stand in front of the middle of the rear bumper.
x Quickly move the side of your body, your foot and shin as close to the bumper as possible. Your
shin must be in the upper part of the sensor’s range and your foot in the lower part (1).
x Quickly move your shin out of range (2). The rear hatch opens automatically.
The high-mounted brake light and the turn signals flash once to show that the Easy Open feature is
opening the rear hatch.
The rear hatch locks automatically after closing if the vehicle was locked before and a valid vehicle key
is not inside the vehicle. If the vehicle key used to open the vehicle is inside the vehicle, the rear hatch
opens again.
Easy Open may not work properly or at all in the following situations (examples):
x If the rear bumper is very dirty.
x If the rear bumper has salty water on it after driving on salted roads.
x If a trailer hitch has been retrofit on the vehicle.
Easy Open may be automatically deactivated in heavy rain to help prevent unintentional deployment
caused by water running down the vehicle, for example.
Locking with a second vehicle key
If a remote control vehicle key is inside the passenger compartment, the vehicle can be locked from
the outside only if a second valid key is within range.
A key that was inside the vehicle when it was locked from the outside is reactivated:
x By pressing a button on the deactivated key.
x By pressing a door handle sensor when the deactivated key is outside of the vehicle, but within
range.
x By starting the engine with the starter button on the front center console.
Automatic deactivation of sensors
If the vehicle has not been unlocked or locked for a longer period of time, the proximity sensors in the
passenger door are automatically deactivated.
If a sensor on the door handle of a locked vehicle is activated too often, for instance by a bush or
hedge that rubs against the vehicle, the sensors in the door handle on that side of the vehicle are
switched off for 30 minutes.
The sensors become active again when the vehicle is locked with the vehicle key and the ignition is
switched on one time.
The sensors become active again if one of the following events occurs:
x 30 minutes have passed.
x OR: The vehicle is unlocked using the V button in the remote control vehicle key.

x OR: The rear hatch is opened.
x OR: The vehicle is mechanically unlocked using the emergency vehicle key.
Convenience features
To use the convenience closing feature to close all power windows, hold your finger on the lock sensor
surface ⇒ fig. 25 (2) on the outside of the door handle for a few seconds until the windows close.
Remove your finger from the lock sensor surface (2) to stop the function. If you touch the unlock
sensor surface 1 on the inside of the door handle immediately after releasing the lock sensor surface 1
(arrow), all of the windows will open (safety function). Pinch protection is active during convenience
closing of the windows.
The settings in the Settings – Convenience menu determine which doors open when the door
handle sensor surface is touched.
.CAUTION
If a valid vehicle key is within range of the rear hatch, the Easy Open feature can deploy unin-
tentionally in some cases and open the rear hatch: for example, when sweeping the ground
or floor below the rear bumper, if there is a strong stream of water or steam or when CARry-
ing out maintenance or repairs around the rear bumper. If the rear hatch opens unintentional-
ly, it can injure anyone or damage anything in its way.
x Never leave a valid vehicle key within range of the rear hatch unattended.
.NOTICE
The door handle sensor surfaces can be activated by a strong stream of water or steam if a
valid vehicle key is within range of the vehicle. All windows may open if you turn the spray of
water or steam away from and then back onto the door handle sensor surface in quick succes-
sion.
.The door may not open if the outside and inside door handles are used at the same time.
.If the automatic transmission is not in Park (P) position, the electronic steering column lock will
not lock and the vehicle will not lock via sensors in the front door handles or the remote control vehicle
key.
.If the vehicle battery or the battery in the remote control vehicle key is weak or dead, it might not
be possible to unlock and lock the vehicle using Keyless Access The vehicle can still be manually
locked or unlocked with the emergency key.
.The driver message Key not in range appears in the instrument cluster display if there is
no remote control vehicle key inside the vehicle or if the system does not recognize the remote control
vehicle key. The key may not be recognized, for example, if it is covered by something that interferes
with the signal (such as a briefcase), or if the remote control vehicle key battery is weak. Electronic
devices such as cell phones can also interfere with the signal.
.Dirt on the door handles that contains a lot of salt (especially in winter) can affect the way the
door handle sensors work. Cleaning the door handles can help with this problem.

Function Using the remote control vehicle key
Convenience
opening Press and hold the unlock button on the remote control vehicle key.
Convenience closing Press and hold the lock button on the remote control vehicle key.

From outside the vehicle (vehicles with Keyless Access), hold your finger on the lock sensor surface
on the outside of the door handle for a few seconds until the windows close.
Convenience closing closes the windows first and then the power sunroof.
The Infotainment System can be used to set various convenience opening options.
Setting convenience opening options in the Infotainment System
x Switch on the ignition.
x Press the CARInfotainment button.
x Tap the Settingsfunction key on the screen.
x Select Remote control keyfrom the list.
If the check box in a function key is checked =, the feature is switched on.

Function key: supplementary information
= Front windows: Convenience opening opens front windows. Tap the function key to deactivate the
feature.
= Rear windows: Convenience opening opens rear windows. Tap the function key to deactivate the
feature.

.WARNING
Improper use of power windows can result in serious personal injury.
x Never let anyone get in the way of a power window when closing it.
x When locking the vehicle from the outside, make sure that no one, especially children,
remains in the vehicle. The windows will not open in case of an emergency.
x Always take the key with you when you leave the vehicle. You can still use the power
windows for several minutes after the ignition is switched off as long as the driver or front
passenger door has not been opened.
x Always use the safety switch when children are in the back seat to disable the rear power
windows and keep them from being opened and closed.
.If the power windows malfunction, the one-touch feature, as well as pinch protection will not
work properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility
right away.
.Convenience closing of the power windows from the outside requires removing the cover cap of
the lock cylinder on the driver door. The cover cap must be reinstalled after the vehicle is locked.

⇒ fig. 41 Press or move the control in the direction of the arrow or in the area shown.
(A) (1) or (2) Adjust lumbar support.
(3) or (4) Adjust lumbar support height.
(B) (1) or (2) Adjust backrest side supports.
(C) (1) Slide the seat backward or forward.
(2) and (3) Raise or lower the seat cushion.
(2) or (3) Adjust seat cushion angle.
(D) Forward or
backwards.
Adjust backrest angle.

.WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has
been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key
in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the
unsupervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjusted, or
while calling up the stored memory settings for the front seats. In an emergency, stop
automatic seat adjustment by pressing a seat adjustment switch.
.NOTICE
To help prevent damage to electrical parts in the seats, do not kneel on the front seats or apply
concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
When entering and exiting the vehicle, be CAReful not to come into contact with any switches
that could change the seat adjustment.
Starting the engine stops seat adjustment.

Lights
up Possible cause Proper response
Engine cannot be started with starter
button (Keyless Access).
Start the engine with the remote control
vehicle key. Take the vehicle to an authorized
Volkswagen dealer or an authorized
Volkswagen Service Facility and have the
system checked.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
.WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn
on the emergency flashers, stop the engine, and use other warning devices to warn
approaching traffic.
.NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Vehicle key positions in the ignition switch

Fig. 241 In the ignition switch: Vehicle key positions.
.

Starter button

Fig. 242 In the front center console: Starter button of the Keyless Access locking and starting system.
.
