2013 VOLKSWAGEN TOUAREG window

x Press the NAVInfotainment button twice in quick succession. After changing to the map display, the
main menu Navigation is displayed.
x Press the e function key to switch menu by menu from a navigation submenu to the Navigation
main menu.
x You can switch back and forth between the map view and the Navigation main menu by pressing
the NAVInfotainment button.
The Navigation main menu is displayed either in “normal” Destination mode or in Tour mode or as the
Waypoint navigation menu ⇒ fig. 201.
If Tour mode ⇒ fig. 161 is displayed .
If the Waypoint navigation menu is displayed .
Display of the last destination
In the upper third of the screen, the destination last used as route guidance is displayed.
x Briefly touch the display box to show the displayed destination in the detailed view.
x Press the New destinationfunction key followed by the + Addressfunction key to show the displayed
destination in the Address entry menu and edit it .
If no destination is displayed, this means no route guidance has been started or that the
destination memory has been deleted manually .
Function keys in the Navigation main menu

Function key: Effect
Options : Defines route options for calculating a route .
Position : opens the current position in the detailed view and displays the coordinates.
Store : stores the displayed position in the destination memory .
D: Stores the current position as a “Flagged destination” in the destination memory .
': Enter home address or show home address in the Navigation main menu .
New destination : opens the selection menu for entry of destination .
Memory: Opens a pop-up window for storing the current destination, loading stored destinations or
managing destinations .
Route: Opens options for route guidance .
Route list: Shows street names or street designations of the route section to be driven.
Remove area to avoid: Removes an entered route exclusion.
Avoid area: To enter a route exclusion.
Extras: opens a pop-up window.

Accept new stopover: for entering a stopover .
Tour mode: for switching to tour mode in order to drive to several destinations during route
guidance .
Offroad: for navigation in off-road areas (waypoint navigation) .
Start: Starts route guidance to the displayed destination .

area you have selected in a previous window, you will not be able to find the street at the street
selection stage.
Finishing destination input
x Press the Start route guidance function key to start route guidance to the entered destination .
x OR: Press the Store in directoryfunction key to store the destination in the destination memory .
Address entry menu

Fig. 165 Navigation main menu with destination.

Fig. 166 Address input menu with destination address.
.

Show details: Shows the destination in the detail view.
Show destination on map: Shows the destination on the map .
Loading a destination from the directory
The Load from directory menu only displays directory entries for which route guidance can be
started (display: symbol 3)
The directory needs to be opened for editing in order to display or edit all directory entries .
x Press the * Directoryfunction key ⇒ fig. 162.
x Press the desired directory entry in the Load from directory menu.
x If more than one navigation destination is stored for a directory entry, you then need to select the
desired navigation destination by touching the screen.
x Press one of the following options in the Destination details menu.
Start route guidance: Starts route guidance .
Add as stopover: Allows you to add the destination to the tour plan .
Enter/show destination on map: Shows the destination on the map .
You can also search for directory entries using a search function.
x Press the Searchfunction key and search for the directory entry by entering the entry name in an
input window .

Displays and options for directory entries

Fig. 183 Directory.

Fig. 184 Directory with a pop-up window for a directory entry.
.

Function key: Effect
Create new telephone numbers: Opens an input window where you can enter a telephone number
manually.
Create business navigation destination: Opens a menu where you can select a navigation destination for
the “Business P”favorites category or convert a stored mailing address into a navigation
destination .
Create business mailing address: Opens a menu to enter a mailing address manually in input windows.
Create business mailing address: Opens a menu where you can select a navigation destination for the
“Private T” favorites category or convert a stored mailing address into a navigation destination .
Create private mailing address: Opens a menu to enter a mailing address manually in input windows.
Read contact: The voice command stored under Last name and First name is read out .
= Private contact: The directory entry is only displayed when the corresponding user profile is loaded.
If the check box = is cleared, the directory entry is transferred to the general user profile and is
always displayed .

If the prefix Create ... is not displayed in a function key, corresponding information is already stored.
This information is displayed below the function key (such as in .: Business navigation destination).
Press the function key to display or modify the stored information ⇒ fig. 186.
Converting mailing addresses into navigation destinations
Information that is stored as Business mailing address or Private mailing address can be converted into
navigation destinations, such as the telephone directory entries of a connected cell phone.
x Press the Create private navigation destination or Create business navigation destination
.button.
x Press the Create navigation destination function key.
The mailing address is converted into a navigation destination in the Infotainment System and
displayed in the Address entry menu where it can be edited further .
x Touch the OKfunction key.
The mailing address is now stored as a navigation destination. The navigation destination is displayed
and can be edited again.
x Press the Efunction key to close the menu.

Function key: Effect
Delete profiles : Press the profile to be deleted in the list of stored user profiles and accept the
confirmation dialog with Delete .
Change profile name8: Renames currently loaded profile in an input window .
Read name tags9: Reads out recorded name tags .
Delete name tags15: Deletes recorded name tags .
Import directory a):: Starts an immediate import of directory entries from a connected cell phone to
the directory.
Import contactsImports navigation data (VCARds) from an inserted data medium into the directory .
Export contacts : copies selected directory entries on an inserted data medium .

Storing or editing the home address

Fig. 191 Menu: Destination entry.

Fig. 192 Menu: New home address.

8 Only active when a cell phone or a SIM card is currently connected to the Infotainment System
⇒ page 287.
9 Only active if name tags have been recorded for directory entries ⇒ page 183.

Dynamic route: Switching dynamic route guidance on or off
With this option, traffic reports can be taken into account in the route calculation .
x In the Route options menu, press the Dynamic route function key.
x In the pop-up window, press the On or Off function key to enable or disable dynamic route
guidance.
Excluding or including types of route in the calculation
Press the < .  Highways , ! Ferries , Toll roads
and " Tunnels function keys to activate or deactivate them. This makes it possible to define whether
these types of route should be allowed for the route calculation or not.
If no reasonable route exists without the road type to be avoided, this road type will be nevertheless
considered in the route calculation. For instance, if an island cannot be reached without using a ferry.
For the calculation of very long routes, it is not possible to avoid highways .
Starting and stopping route guidance

Fig. 208 3D map display during route guidance.

Fig. 209 Navigation main menu during route guidance.
.

During route guidance, you can manually exclude the route section immediately ahead of your current
location. The route exclusion is revoked when route guidance is stopped.
x In the Navigation main menu, press the Route function key ⇒ fig. 209.
x In the pop-up window, press the Avoid area function key.
The Avoid area menu opens. The length of the stretch to be excluded from the current vehicle
position.
x Press the ` function key to specify up to which route section the route ahead should be blocked.
x Press the a function key to shorten the route exclusion.
x Press the OK function key to confirm the exclusion entry.
In the Navigation main menu ⇒ fig. 209, the icon for an active route exclusion
