The system will no longer sound warnings about these objects. Ignoring signals from the Park
Distance Control system could result in serious damage to the vehicle.
x The sensors in the bumper can be damaged or become misaligned in low speed impacts
and parking maneuvers. Damaged or misaligned sensors cannot accurately detect or report
objects that might be within range of the PDC system
x To help make sure that the system works properly, always keep the sensors in the bumpers
clean, free of snow and ice; do not cover the sensors with stickers or other objects.
x When cleaning the sensors with power washers or steam cleaners, only spray the sensors
directly for a very short time, and always keep the washer nozzle at least 4 inches (10 cm) from
the sensors.
x Noise from rough roads, cobblestones, other vehicles and the surrounding area, for
example, can prevent the Park Distance Control system from accurately detecting and
reporting people and objects that may be within range of the system sensors.
.Volkswagen recommends practicing with the Park Distance Control system in a location or
parking space with no traffic in order to become familiar with the system and how it works.
Park Distance Control (PDC)

Fig. 260 On the front and rear bumper: Park Distance Control system sensors.

Fig. 261 In the upper front center console: Different versions of the button for switching Park Distance Control
on and off.
.

Switching Park Distance Control on and off manually
x Push the  or ∗ .button once when the ignition is switched on to switch Park Distance Control
on.
x Push the  or ∗ .button again when the ignition is switched on to switch Park Distance Control
off.
The indicator light in the button comes on and stays on as long as the feature is active. The indicator
light in the button comes on and stays on as long as the feature is active.
Switching Park Distance Control on and off automatically
x Automatic activation: Shift into reverse.
x OR: Drive forward slowly (less than about 6 - 9 mph /10 - 15 km/h) and approach to within about
38 inches (95 cm) of an obstacle.
x OR: If the vehicle rolls backwards.
x Automatic deactivation: Drive faster than about 6-9 mph (10 - 15 km/h).
A chime sounds to tell you that the system is on. If the chime does not sound, PDC is not working.
Have the system inspected by an authorized Volkswagen dealer or an authorized Volkswagen Service
Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an
obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System .
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is
engaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an
authorized Volkswagen Service Facility.
.WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
.If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light
in the button starts blinking, this means there is a malfunction in the Park Distance Control system.
Switch off the Park Distance Control system with the button and have it immediately checked by an
authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

Optical Parking System (OPS)

Fig. 262 OPS screen display: Small-screen display.

Fig. 263 OPS screen display: Full-screen display.
.

Function Proper response
Manual deactivation of OPS
small-screen display: Tap the O function key ⇒ fig. 262.
Switch to full-screen view: Vehicle rolls backwards slowly.
OR: Press the lit-up button .  or ∗
OR: Tap the OPS function key .
Switch on the display
automatically:
By putting the vehicle in Reverse.
OR: Vehicle rolls backwards.
Switch on the display manually: Press the  or ∗.button.
Manually deactivate the display: Press the  or ∗.button again.
Automatically deactivate the
display:
Drive forward faster than about 6 - 9 mph (10 - 15 km/h).

Scanned areas
In front of the vehicle, the area in which obstacles are detected extends about 48 inches (120 cm)
straight ahead and up to 24 inches (60 cm) to either side. Behind the vehicle, the area scanned area
extends about 5 ft. 4 inches (160 cm) to the rear and about 2 ft. (60 cm) to either side (C) and
⇒ fig. 263 (C).
When the system is activated automatically, the acoustic signal sounds only if an object is detected in
the area about 20 inches (50 cm) to the front or rear of the vehicle.
Screen display
The display shows the scanned area in several segments. The closer the vehicle gets to the obstacle,
the closer the segment advances to the displayed vehicle ⇒ fig. 262 (B) and ⇒ fig. 263 (B).
When the next-to-last segment is displayed, you have reached the collision zone. Stop the vehicle!

Distance between vehicle and obstacle Audible signal Screen: Segment color if
obstacle detected
Front: about 12 – 48 inches (31 – 120 cm)Beep tone if
manually activatedYellow Rear: about 12 – 64 inches (31 – 160 cm)
Front: about 12 – 20 inches (31 – 50 cm) Beep tone if
automatically
activated
Yellow Rear: about 12 – 20 inches ( 31 – 50 cm)
About 0 – 12 inches (0 – 30 cm) front or
rear Continuous tone Red

The distance at which the continuous tone sounds is somewhat greater for vehicles with a factory-
installed trailer hitch.
Infotainment System settings for OPS
A number of settings can be selected in the Infotainment System.
x Switch on the ignition.
x Press the CAR Infotainment button.
x Tap the Assist systems function key on the screen.
x Select Parking Distance Warning System from the list.

Function key: Actions
Front volume/tone level : Different volume and pitches can be separately selected for front by
tapping the - or + function keys or by moving the slider.
Rear volume/tone level : Different volume and pitches can be separately selected for rear by tapping
the - or + function keys or by moving the slider.
Reduced audio volume : Different volume and pitches can be separately selected for front and rear
by tapping the - or + function keys or by moving the slider.
Automatic activation of mini-OPS : If the check box in the function key is checked = ,the small
screen OPS display is automatically switched on when you slowly approach an obstacle. To switch
off this feature, tap Automatic activation of mini-OPS . After deactivation, there will not be any
warning when you approach an obstacle.
Reset settings : Resets all settings to the factory settings.

When towing a trailer
On vehicles with a factory-installed trailer hitch and an electrically connected trailer, a corresponding
graphic is displayed on the screen. Distance values behind the vehicles will not be displayed.
Muting Park Distance Control
The acoustical PDC warnings can be muted by tapping the  function key in the Infotainment System.
You must tap the function key again to reactivate the acoustic warnings.
Muting is cancelled by switching Park Distance Control back on after it was switched off. The warning
messages cannot be switched off.
.WARNING
Never rely completely on the OPS for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The OPS sensors have blind spots where they cannot detect persons or objects.
x Never pay so much attention to the OPS and the graphics shown on the screen that you
fail to notice what is going on around you.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
.NOTICE
Automatic activation of OPS when approaching an obstacle works only when your speed falls
below a threshold of about 6 - 9 mph (10 - 15 km/h). If you then close the display, you must
either switch the ignition off and back on or exceed the speed threshold and then reduce
speed to under the threshold a second time in order for it to activate automatically again.
.Volkswagen recommends practice parking with Park Distance Control on a parking lot or other
place where there is little traffic to get used to how the system works.

Rear Assist with dynamic orientation lines

.WARNING
Rear Assist technology cannot overcome the laws of physics and the limits of the system.
CAReless or unintentional use of Rear Assist may result in accidents and severe injuries.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
x Always keep an eye on the parking direction and the vehicle surroundings. The front of
the vehicle swings out more than the rear of the vehicle.
x Never pay so much attention to the graphics shown on the screen that you fail to notice
what is going on around you.
x Always watch for people, especially small children, animals and objects, because the
camera may not always be able to detect them.
x The system may not be able to clearly show everything behind the vehicle.
x Use Rear Assist only when the rear hatch is completely closed.
.NOTICE
x The camera shows only two-dimensional images on the screen. Due to the lack of depth of
field, it may be difficult or impossible to identify protruding objects or recesses in the road, for
example.
x Things like thin rods, fences, posts and trees may not be detected by the camera and could
damage the vehicle.
Operation

Fig. 264 In the rear hatch: Location of the Rear Assist camera.

Fig. 265 Display of the Rear Assist: Mode 1 activated.
.

Function buttons on the screen ⇒ fig. 265
(1) Display the menu () or hide the menu (
