2013 VOLKSWAGEN TOUAREG Owners Manual

Folding the backrest of the rear bench forward and back into place

Fig. 98 Lower part of the rear seat bench: Lever to unlock the rear seat backrest by hand.

Fig. 99 Right side wall of the luggage compartment: Buttons for power release of the rear seat backrest.

.WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal
injury.
x Always make sure there are no people or animals in the area around the rear seat backrest
when folding it forward.
x Never fold the rear backrest up or down while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get
caught or damaged.
x Keep hands, fingers, feet and other body parts out of the way when folding the rear seat
backrest up and down.
x Each rear seat backrest must be securely latched in the upright position so that the safety
belts on the rear seats can provide protection. This is particularly the case for the middle seat
on the rear bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together
with the rear seat backrest during sudden braking, driving maneuvers or a collision.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded
down or not correctly latched.
.NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head
restraint or backrest cushion will not butt up against the front seats.
x The weight on the rear seat backrests when folded down must never exceed 110 lbs. (50
kg).
.NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is
adjusted in the fore and aft direction.
If the vehicle battery charge is weak, power release of the rear seat backrests may not be
possible.

Luggage compartment cover

Fig. 100 In the luggage compartment: Closed luggage compartment cover.

Fig. 101 In the luggage compartment: Removing the luggage compartment cover.

Removing the luggage compartment cover
x If there is a gap cover (2), unhook it from the fastening eyes on the rear seat backrests ⇒ fig. 101
(1).
x Push down release button (2) and push in the end parts of the luggage compartment cover (3).
x Lift the luggage compartment cover up and out.
Reinstalling the luggage compartment cover
x First fit the luggage compartment cover ⇒ fig. 100 (1) into the left-hand slot.
x Then fit the other end into the right-hand slot.
x Push down release button ⇒ fig. 101 (2) and push in the end parts of the luggage compartment
cover (3).
x Push the luggage compartment cover down into the right-hand slot so that it locks into place.
x Make sure that the luggage compartment cover is properly locked into place.
x If there is a gap cover ⇒ fig. 100 (2), hook it back into the fastening eyes on the rear seat backrests
⇒ fig. 101 (1).
.WARNING
In a sudden braking or other maneuver, or in a collision, unsecured or improperly secured
objects or animals on the luggage compartment cover could cause serious personal injury.
x Never leave hard, heavy or sharp objects in bags or loose on the luggage compartment
cover.
x Never let animals ride on the luggage compartment cover.
.WARNING
The view towards the rear is greatly limited when the luggage compartment cover is in the
convenience position.
x Before driving, ensure that the luggage compartment cover is not in the convenience
position.
.NOTICE
To help prevent damage to the luggage compartment cover, the luggage compartment may
only be loaded to a height at which the luggage compartment cover will not press on the
CARgo when the rear hatch is closed.
x The defroster heating wires or antenna in the rear window can be damaged by objects that
rub against them.
Do not cover the ventilation slots in the side consoles. Otherwise, stale air cannot escape from
the vehicle.

Luggage compartment pass-through

Fig. 102 In the rear backrest: Luggage compartment pass-through opening.

Tie-downs

Fig. 103 In the luggage compartment: Tie-downs.

.WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment Hooks on elastic straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the
vehicle and do not let them snap back and hit you.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let
them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the
luggage compartment and then to the tie-downs near the loading edge of the luggage
compartment. This way, if one of the hooks on the elastic straps snaps back, it will move
away from you, decreasing the risk of personal injury.
.The maximum weight force for the tie-downs is about 785 lbs (356 kg).
.For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. 104 In the luggage compartment: Shopping bag hook.

Luggage compartment floor

Fig. 105 In the luggage compartment: Lifting luggage compartment floor panel and securing it with retaining
strap.
