2013 VOLKSWAGEN TOUAREG audio

Driver side overview

Fig. 5 Driver side overview.
Key to fig. 5:
(1) Air vents z
(2) Lever for:
– High beams
– Headlight flasher
– Turn signal lights

(3) Multi-function steering wheel controls :
– Volume setting for radio, navigation system notifications, or telephone calls (if applicable)
.& – '
– Mute switching for radio or activation of voice control (if applicable) 
– Display Phone main menu or accept telephone calls -
– Audio, Navigation .Ì –

▪ Display since start
▪ Display since refuel
▪ Display long-term
▪ Digital speed (digital speed display).
▪ Alt. speed display (alternative speed display On/Off)
Navigation
Audio
▪ Source list
– DAB
– FM
– AM
– Radio memory
– HDD
– SD
– DVD
– USB
– Bluetooth
– TV tuner
– TV station memory
– External AV source
Telephone
▪ Directory
▪ Dialed numbers
▪ Missed calls
▪ Received calls
Using the instrument cluster menus

Fig. 14 Right side of the multi-function steering wheel: Controls for the menus in the instrument cluster.

Safety information on Infotainment System
.WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
x Setting the sound volume too high may damage your hearing. This applies even if you are
exposed to high volumes for short periods only.
.WARNING
The volume level may suddenly get louder change when you switch media source or connect
a new audio source.
x Always lower the base volume before switching media source or connecting a new audio
source.
.WARNING
Driving recommendations and traffic symbols displayed by the navigation system may differ
from the current traffic situation.
x Traffic signs and traffic regulations have priority over the recommendations and displays
provided by the navigation system.
x Always adjust your speed and driving style to road, traffic, weather, and visibility
conditions.
.WARNING
External devices that are loose in the vehicle or not properly secured could be thrown around
the interior and cause injuries during a sudden driving or braking maneuver, or in a crash.
x Never put or attach an external device on a door, on the windshield or above or near to the
areas marked “AIRBAG” on the steering wheel, the instrument panel and the seat backrests,
or between these areas and the vehicle occupants. External devices could cause serious
injury in an accident, especially when the airbags inflate.

.WARNING
The volume may suddenly get louder when you switch media source or connect a new audio
source.
x Always lower the volume before switching media source or connecting a new audio
source.
.NOTICE
Excessively loud or distorted playback can damage the vehicle speakers.
If the base volume on the Infotainment System has been considerably increased to play a certain
audio source, lower the volume again before switching to another audio source.
Function keys on screen

Fig. 124 Setup main menu (SETUP).

Fig. 125 Navigation settings.
.

Changes made in settings menus are automatically applied once the menu is closed.

Function key: Effect
Dynaudio Confidence: Dynaudio Confidence settings
Treble - Bass: Changing sound character. Change settings by moving the slider ?.
Balance - Fader: Changing the sound focus
Volume: Volume settings
= Speed-dependent volume adjustment: If the speed-dependent volume is activated, the audio volume is
automatically raised as the vehicle speed increases.
When speed-dependent volume is switched on in vehicles with Dynaudio Confidence®,the volume
of individual frequencies is automatically raised or reduced depending on the road noise caused by
the rising vehicle speed. This “reduces” the road noise in the vehicle.

Changing the sound focus (balance and fader) using the vehicle diagram
x Press the Balance – Fader function key.
The crosshair in the vehicle diagram shows the current sound focus in the vehicle interior.
x Place your finger on the crosshair and, without lifting it off, drag it across the screen. Lift your finger
off the screen once the sound focus is in the required position
x OR: Press the point in the interior view where you want the sound focus to be.
x OR: Move the sound focus step by step by pressing the arrow buttons on the left of the screen.
Press the function key between the arrow buttons to return the sound focus to the center of the interior
view.
Changing volume settings and adjustments
It is possible to preset some volume settings and adjustments.
x In the Setup Tone main menu, press the Volume function key.
x Press one of the function keys in the Volume settings menu to open the corresponding settings
menu.
Telephone 1):Set output volume for telephone calls in the vehicle.
Voice guidance: Set output volume for navigation announcements during route guidance
Reduced audio volume: Set by how much the volume of other audio sources should be reduced during an
announcement (navigation, voice operation) or a telephone call1. While you adjust the volume
reduction, the volume of the currently active audio source is reduced at the level of the setting as you
change it.
While you adjust volume settings, the corresponding audio source is played at the level of the setting
as you change it.
Dynaudio Confidence®
Additional settings are available if the vehicle is equipped with the RNS 850 and Dynaudio.
x In the Sound settings main menu, press the Dynaudio Confidencemain menu.
Press one of the function keys in the Dynaudio settings menu to open the corresponding settings
menu.
Sound focus: Optimize sound effects, frequency ranges and sound focus for different sitting positions in
the vehicle.
Surround: Set level of surround effect.

Data media Conditions for playback
Audio files Video files
i Audio CDs (up to 80 min).
i Standard video DVD and DVD-
compatible DVD audio.
i CD-ROM-, CD-R-, CD-RW audio
data CD up to max. 700 MB
(Megabyte) in the data system ISO
9660 Level 1 and 2, Joliet or UDF
1.02, 1.5, 2.01, 2.5
i DVD+/-R/RW up to 4.7 GB and
dual layer DVDs up to 8.5 GB in the
Joliet file system (single-session
only); UDF.
Þ SDHC memory CARds up
to 32 GB. Þ SD- and MMC memory
CARds in the data system FAT12,
FAT16, FAT32 or VFAT up to
max. 2 GB (Gigabyte) and SDHC
memory CARds up to max. 32 GB.
– Digital audio specification
!.
– Bit rates from 160 kbit/s
(recommended) up to
320 kbit/s and 48 kHz
sampling frequency.
– Format: MPEG layers 1, 2,
and 3 (.MP3).
– Format: .Windows Media
Audio 8 and 9 (.wma, .asf).
– Format: MPEG layers 2
and 4 (.m4a, .m4b, .mp4,
.aac).
– Bit rates up to 2000 kbit/s.
– Maximum resolution
720 x 576 pixel.
– Format: MPEG layers 1 and -
2 (.mpg, .mpeg).
– Format: ISO-MPEG4; DivX 3,
4 and 5 Xvid (.avi).
– Format: ISO-MPEG4 H.264
(.mp4, .m4v, .mov).
– Format: Windows Media
Video 9 (.wmv, .asf).
– Playlists supported in formats M3U, PLS and WPL (not
supported by the media center (HDD)).
– Limit of 4 partitions.
– On DVD limit of 1000 files per medium and directory.
– On memory CARds limit of 4000 files and limit of 1000 files
per directory.
– Limit of 3000 files in the media center (HDD).

Requirements for using external data media via the MEDIA-IN multimedia jack .
Restrictions and notes
Windows Media Audio 9 Voice, Lossless and Professional as well as DRM-protected files are not
supported. Other data media with copy protection and multi-session CDs and DVDs can sometimes
not be played back or only with limitations.
Dirt, high temperatures and mechanical damage can render a data medium unusable. Please observe
data medium manufacturer information.
Quality differences between data media of different manufacturers can cause problems during
playback.
The data medium configuration or the devices or programs used for recording can cause individual
tracks or data medium to be unreadable. Information can be found on the Internet on the best ways to
create audio files, video files and data media (compression rate, ID3 tag etc.).
Due to the larger quantity of data, it takes longer to read a data medium containing compressed audio
files (such as MP3, WMA) than a “normal” audio CD. Complex directory structures can also the delay
the reading process. If possible, only use data media with readable audio and video files.
Play lists only define a certain playback sequence. Play lists do not save any files. Play lists cannot
be played if the files on the data medium are not saved in the location to which the play list is referring
(relative data path). Play lists cannot be copied to the media center (HDD).
.NOTICE
Do not use memory CARd adapters.
.No liability can be accepted for damaged or lost files on the data media.

.NOTICE
Only insert or remove CDs or DVDs if the LEDs on the DVD slot are flashing green.
.NOTICE
Before closing the side compartment in the luggage compartment, check whether the CD or
DVD has been drawn in or removed completely. The DVD changer or the data medium might
otherwise be damaged.
.Playlists in the format cannot be played in the external DVD changer.
Open MEDIA main menu

Fig. 144 MEDIA main menu: Audio menu.

Fig. 145 MEDIA main menu: Video DVD menu.

When the system is switched over to play a standard video DVD, the MEDIA main menu is opened
automatically as a Video DVD menu
Other video sources (such as AVI films) are played back like audio files only via the Audio menu .
Starting media mode
x Press the MEDIA Infotainment button ⇒ fig. 123.
Playback of the last media source played is continued if the data medium is still available in the
Infotainment System.
Depending on the selected media source, the MEDIA main menu is opened as an Audio menu or
Video menu ⇒ fig. 145.
If no media source is available, the MEDIA main menu cannot be opened.
Changing the media source

Fig. 146 MEDIA main menu with display of currently playing and available media sources.
