2013 VOLKSWAGEN TOUAREG audio

BT: Bluetooth audio transmission
.WARNING
The volume may suddenly get louder when you switch media source or connect a new audio
source.
x Always lower the base volume before switching media source or connecting a new audio
source.
.NOTICE
Excessively loud or distorted playback can damage the vehicle speakers.
Track or chapter selection in audio and video menu

Media mode (audio):

Files, folders and playlists on a data medium are sorted by name in alphanumerical order.
The illustration shows a typical audio data CD that contains tracks b, folders a and sub folders
⇒ fig. 147.
The tracks are played back as follows:
1. Tracks (1) and (2) in the CD's root directory
2. Track (3) and (4) in the first directory F1 in the root directory of the CD.
3. Track (5) in the first subdirectory F1.1 of the directory F1
4. Track (6) in the first subdirectory F1.1.1 of the subdirectory F1.1
5. Track (7) in the second subdirectory F1.2 of the directory F1
6. Track (8) and (9) in the second directory F2
Play lists ´ are treated like directories in the playback sequence.
.WARNING
Driving on today’s roads demands the full attention of the driver at all times. Driver
distraction causes accidents, collisions and serious personal injury!
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System,
when using your cell phone, or when operating the cell phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your cell phone,
and the cell phone controls only if road, traffic, and weather conditions permit and you will
not be distracted from your driving.
x If you cannot use the Infotainment System, your cell phone, or the cell phone controls
safely while driving, wait until later or find a safe spot where you can pull off the road and
park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other
warning sounds outside the vehicle.
.Compressed video files (Podcasts, AVI) on a data medium are treated like audio files when
played back.
.Play lists are not automatically played, they must be specifically selected via the menu for track
selection.
Playback of video files in the Audio menu
.

Track display in Audio menu

Fig. 148 MEDIA main menu: Audio menu.

Browsing audio and media sources

Fig. 149 Track list of a playing audio CD.

Fig. 150 Track list of a playing audio data CD.

x Press the F function key to open the current folder's parent folder (for example : .F1).
The audio source and the folder currently opened are displayed in the title bar (in .: SD CARd and
folder F1.1).
Pressing the F function key several times switches from one folder to another until you reach the top
selection level of the data media.
If only the name of a data medium is displayed in the title bar, this means the root directory of the data
media is opened ⇒ fig. 153.
Changing playback mode

Fig. 151 Extras pop-up window for audio mode.

Media center (HDD): importing files

Fig. 152 Select audio files to be imported.

Checking hard disk capacity of Media center
x In the Audio menu, press the Extrasfunction key ⇒ fig. 151.
x In the pop-up window, press the HDD capacity function key.
The HDD capacity menu shows how much hard drive memory space is used and how much is still
available for storage.
x Press the
