2013 VOLKSWAGEN TOUAREG Owners Manual

Changing the station buttons and storing a radio station

Fig. 139 RADIO main menu.
.

Selecting stations stored to station buttons

Fig. 140 RADIO main menu: Preset 4 selected.
.

Satellite radio main menu

Fig. 141 Satellite radio main menu.

Display: meaning
Antenna: Aerial fault. Please contact a Volkswagen dealership.

Changing station and selecting a category

Fig. 142 Station list for station selection.

SCAN
x Press the SIRIUS

Function key: Effect
£ Station list: All available stations and channels can be browsed in sequence with the arrow
buttons.
£ Presets: Only stations and channels that are stored to station buttons can be browsed with the
arrow buttons.
Presets: Select the station buttons to be displayed
Press one of the functions buttons Presets x...xto display the desired group of station buttons in
the main menu RADIO.
= HD radio: HD radio is activated
Delete Presets: When Delete is pressed, all stations and channels stored to station buttons are deleted.
SIRIUS ID: Displays the Sirius ID
Sort stations: the station list shows all satellite stations as selected:
Station number : in the all categories view arranged according to channel number.
Category/Station name : in the category view arranged according to station name.
Category/Station no. : in the category view arranged according to channel number.
Station name : in the all categories view arranged according to station name.
Category filter: restrict selection of stations to certain categories.
If the check box in the = Category filter on function key is deactivated, all categories are
displayed and all stations can be selected.

Media mode: Introduction

.NOTICE
x When inserting and removing CDs and DVDs, always hold them at right angles to the front
of the unit. Inserting or removing them at an angle to the DVD drive may lead to scratching.
x Inserting a second CD or DVD while a CD or DVD is inserted or is being ejected can destroy
the DVD drive. Always wait until the data media is completely ejected.
.NOTICE
Any foreign objects attached to a data medium and non-round data media can damage the DVD
drive.
x Only clean 12-cm standard CDs or DVDs should be used!
– Do not attach stickers or other items to the data medium. Stickers may peel off and damage the
drive.
– Do not insert 8-cm single CDs or non-round CDs (shaped CDs) or DVDs.
– Do not insert DVD-Plus, Dual Discs and Flip Discs, as these are thicker than standard CDs.
.CDs can also be played in a DVD drive if they meet the requirements .
.Uneven road surfaces and strong vibrations may cause CDs and DVDs being played in the
DVD drive to jump.
.If the temperature inside a DVD drive is too high, loading and playback of CDs and DVDs is
disabled.
Data media and file requirements
