2011 Lexus CT200h Owner's Manual (in English)

5
617
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
If the electronic key does not operate properly
Locking and unlocking the doors and key linked functions
Use the mechanical key (P. 54)
in order to perform the following
operations:
An alarm will sound if the
alarm is set. ( P. 138)
Locks all the doors
Closes the windows
* (turn
and hold)
Unlocks all the doors
Opens the windows
* (turn
and hold)
*: This setting must be customized
at any authorized Lexus dealer
or repairer, or another duly
qualified and equipped profes-
sional.
If communication between the electronic key and vehicle is inter-
rupted (P. 82) or the electronic key cannot be used because the bat-
tery is depleted, the smart entry & start system, the push-button start
system and wireless remote control cannot be used. In such cases, the
doors can be opened and the hybrid system can be started by following
the procedure below.

618
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Changing “POWER” switch modes and starting the hybrid system
Depress the brake pedal.
Touch the Lexus emblem side
of the electronic key to the
“POWER” switch.
If any of the doors is opened or
closed while the key is being
touched to the switch, an alarm
will sound to indicate that the
start function cannot detect the
electronic key.
To change “POWER” switch modes: Within 10 seconds of
the buzzer sounding, release the brake pedal and press the
“POWER” switch. Modes can be changed each time the
switch is pressed. (P. 197)
To start the hybrid system: Press the “POWER” switch
within 10 seconds of the buzzer sounding, keeping the
brake pedal depressed.
In the event that the hybrid system still cannot be operated, contact
any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional.
STEP1
STEP2
STEP3

5
619
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Stopping the hybrid system
Set the parking brake, shift the shift position to P and press the “POWER”
switch as you normally do when stopping the hybrid system.
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(P. 515)
Alarm
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,
the alarm may be triggered.

620
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If the 12-volt battery is discharged
The following procedures may be used to start the hybrid system if the
vehicle’s 12-volt battery is discharged.
You can also call any authorized Lexus dealer or repairer, or another
duly qualified and equipped professional.
If you have a set of jumper (or booster) cables and a second
vehicle with a 12-volt battery, you can jump start your vehicle
by following the steps below.
Open the hood and fuse
block cover.
Open the exclusive jump
starting terminal cover.
STEP1
STEP2

5
621
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Connect the jumper cables according to the following proce-
dure:
Connect a positive jumper cable clamp to the exclusive jump
starting terminal on your vehicle.
Connect the clamp on the other end of the positive cable to the
positive (+) battery terminal on the second vehicle.
Connect a negative cable clamp to the negative (-) battery ter-
minal on the second vehicle.
Connect the clamp at the other end of the negative cable to a
solid, stationary, unpainted metallic point away from the
STEP3

622
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Start the engine of the second vehicle. Increase the
engine speed slightly and maintain at that level for
approximately 5 minutes to recharge the battery of your
vehicle.
Open and close any of the doors of your vehicle with the
“POWER” switch off.
Maintain the engine speed of the second vehicle and start
the hybrid system of your vehicle by turning the
“POWER” switch to ON mode.
Make sure the “READY” indicator light comes on. If the
indicator light does not come on, contact any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
Once the hybrid system has started, remove the jumper
cables in the exact reverse order from which they were
connected.
To install the engine cover, conduct the removal proce-
dure in reverse. After installing, check that the fixed pins
are inserted securely.
Once the hybrid system starts, have the vehicle inspected at any
th i d L d l i th d l lifi dSTEP4
STEP5
STEP6
STEP7
STEP8
STEP9

5
623
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
To prevent 12-volt battery discharge
Turn off the headlights and the audio system while the hybrid system is
off.
Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic.
When the 12-volt battery is removed or discharged
The hybrid system may not start. (P. 499)
If the 12-volt battery discharges while the shift position is in P, it may not
be possible to shift the shift position to other positions. In this case, the
vehicle cannot be towed without lifting both front wheels because the
front wheels will be locked. (P. 551)
When the 12-volt battery is reconnected, start the hybrid system and
confirm that the shift position can be changed to each position using the
shift position indicator.
Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even
when the vehicle is not in use, due to natural discharge and the draining
effects of certain electrical appliances. If the vehicle is left for a long time,
the 12-volt battery may discharge, and the hybrid system may be unable to
start. (The 12-volt battery recharges automatically while the hybrid system
is operating.)

624
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
CAUTION
Avoiding 12-volt battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flam-
mable gas that may be emitted from the 12-volt battery:
Make sure each jumper cable is connected to the correct terminal and that
it is not unintentionally in contact with any other than the intended termi-
nal.
Do not allow the other end of the jumper cable connected to the “+” termi-
nal to come into contact with any other parts or metal surfaces in the area,
such as brackets or unpainted metal.
Do not allow the + and - clamps of the jumper cables to come into contact
with each other.
Do not smoke, use matches, cigarette lighters or allow open flame near the
12-volt battery.
