2011 Lexus CT200h Owner's Manual (in English)

233
2-3. Operating the lights and windshield wipers
2
When driving
CT200h_EE (OM76041E)
Turning on the high beam headlights
With the headlights on, push
the lever away from you to
turn on the high beams.
Pull the lever toward you to the
center position to turn the high
beams off.
Pull the lever toward you and
release it to flash the high
beams once.
You can flash the high beams
with the headlights on or off.
Manual headlight leveling dial (if equipped)
The level of the headlights can be adjusted according to the num-
ber of passengers and the loading condition of the vehicle.
Raises the level of the head-
lights
Lowers the level of the head-
lights

234
2-3. Operating the lights and windshield wipers
CT200h_EE (OM76041E)Guide to dial settings
Occupancy and luggage load conditionsDial positionOccupantsLuggage load
DriverNone0
Driver and front
passengerNone0
All seats occupiedNone1.5
All seats occupiedFull luggage loading2.5
DriverFull luggage loading4

235
2-3. Operating the lights and windshield wipers
2
When driving
CT200h_EE (OM76041E)
Daytime running light system (if equipped)
To make your vehicle more visible to other drivers, the front position lights
turn on automatically (at an increased intensity) whenever the hybrid system
is started. Daytime running lights are not designed for use at night.
Headlight control sensor
Automatic light off system
When the light switch is in the or position: The headlights
turn off automatically if the “POWER” switch is turned to ACCES-
SORY mode or OFF.
When the light switch is in the position: The headlights and all
lights turn off automatically if the “POWER” switch is turned to
ACCESSORY mode or OFF and the driver’s door is opened.
To turn the lights on again, turn the “POWER” switch to ON mode, or turn
the light switch off once and then back to the
or position.
Automatic headlight leveling system (if equipped)
The level of the headlights is automatically adjusted according to the num-
ber of passengers and the loading condition of the vehicle to ensure that the
headlights do not interfere with other road users.
Light reminder buzzer (if equipped)
A buzzer sounds when the “POWER” switch is turned off or turned to
ACCESSORY mode and the driver’s door is opened while the lights are
turned on.
The sensor may not function properly if
an object is placed on the sensor, or any-
thing that blocks the sensor is affixed to
the windshield.
Doing so interferes with the sensor
detecting the level of ambient light and
may cause the automatic headlight sys-
tem to malfunction

236
2-3. Operating the lights and windshield wipers
CT200h_EE (OM76041E)
Customization
Settings (e.g. light sensor sensitivity) can be changed.
(Customizable features P. 655)
NOTICE
To prevent 12-volt battery discharge
Do not leave the lights on longer than necessary when the hybrid system is
off.

237
2-3. Operating the lights and windshield wipers
2
When driving
CT200h_EE (OM76041E)
Fog light switch
The fog lights secure excellent visibility in difficult driving condi-
tions, such as in rain and fog.
Rear fog light switch
Turns the rear fog
light off
Turns the rear fog
light on

238
2-3. Operating the lights and windshield wipers
CT200h_EE (OM76041E)
Fog lights can be used when
Vehicles with a rear fog light only
The front position lights are turned on.
Vehicles with a front and rear fog light
Front fog lights: The front position lights are turned on.
Rear fog lights: The front fog lights are turned on.
NOTICE
To prevent 12-volt battery discharge
Do not leave the lights on longer than necessary when the hybrid system is
off.
Front and rear fog light switch (if equipped)
Turns the front and
rear fog lights off
Turns the front fog
lights on
Turns both front and
rear fog lights on
Releasing the switch ring
returns it to .
Operating the switch ring
again turns only the rear fog
lights off.

239
2-3. Operating the lights and windshield wipers
2
When driving
CT200h_EE (OM76041E)
Windshield wipers and washer
Intermittent windshield wipers with interval adjuster (if
equipped)
The wiper operation is selected by moving the lever as follows.
When intermittent windshield wiper operation is selected, wiper
intervals can be also adjusted.
Intermittent windshield
wiper operation
Low speed windshield
wiper operation
High speed windshield
wiper operation
Temporary operation

Increases the intermittent
windshield wiper fre-
quency
Decreases the intermittent
windshield wiper fre-
quency

240
2-3. Operating the lights and windshield wipers
CT200h_EE (OM76041E)
Washer/wiper dual opera-
tion
The wipers will automati-
cally operate a couple of
times after the washer
squirts.
