2011 Lexus CT200h Owner's Manual (in English)

5
561
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Warning lightWarning light/Details
(Flashes)
Pre-crash safety system warning light (if equipped)
Indicates a malfunction in the pre-crash safety system
The warning light will operate as follows, even when
the system is not malfunctioning:
• The light will flash quickly when the system is oper-
ating. (P. 292)
• The light will turn on when the pre-crash braking is
disabled. (P. 293)
• The light will turn on when the system cannot tempo-
rarily be used. (P. 576)
Slip indicator light
Indicates a malfunction in:
• Vehicle stability control;
• Traction control;
• Hill-start assist control
Brake system warning light (yellow indicator)
Indicates a malfunction in:
• The regenerative brake system; or
• The electronically controlled brake system
Automatic headlight leveling system warning light (if
equipped)
Indicates a malfunction in the automatic headlight lev-
eling system

562
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning light goes off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
Indicates that a door is not fully
closed
Check that all the
doors are closed.
Low fuel level warning light
Indicates remaining fuel is
approximately 6.8 L (1.8 gal.,
1.5 Imp.gal.) or less
Refuel the vehicle.
Seat belt reminder light
(warning buzzer)
*2
Warns the driver and/or front
passenger to fasten their seat
belts.
Fasten the seat belt.
If the front passen-
ger’s seat is occu-
pied, the front
passenger’s seat
belt also needs to be
fastened to make
the warning light
(warning buzzer)
off.
Master warning light
The warning light comes on
and flashes to indicate that the
master warning system has
detected a malfunction.
P. 5 6 5

5
563
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
*1:Open door warning buzzer:
P. 569
*2:Driver’s and front passenger’s seat belt buzzer:
The driver’s and front passenger’s seat belt buzzer sounds to alert the
driver and front passenger that his or her seat belt is not fastened. The
buzzer sounds for 30 seconds after the vehicle reaches a speed of 20 km/
h (12 mph). Then, if the seat belt is still unfastened, the buzzer will
sound in a different tone for 90 more seconds.
Front passenger detection sensor, seat belt reminder and warning buzzer
If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash and the warning
buzzer to sound even if a passenger is not sitting in the seat.
If a cushion is placed on the seat, the sensor may not detect a passenger,
and the warning light may not operate properly.
Electric power steering system warning light (warning buzzer)
When the 12-volt battery charge becomes insufficient of the voltage tempo-
rarily drops, the electric power steering system warning light may come on
and the warning buzzer may sound.

564
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If the malfunction indicator lamp comes on while driving
The malfunction indicator lamp will come on if the fuel tank becomes com-
pletely empty. If the fuel tank is empty, refuel the vehicle immediately. The
malfunction indicator lamp will go off after several trips.
If the malfunction indicator lamp does not go off, contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional as soon as possible.
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
The vehicle speed linked seat belt reminder buzzer can be disabled.
(Customizable features P. 655)
However, Lexus recommends that the seat belt reminder buzzer be opera-
tional to alert the driver and front passenger when seat belts are not fastened.
CAUTION
If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped profes-
sional. The vehicle will become extremely unstable during braking, and the
ABS system may fail, which could cause an accident resulting in death or
serious injury.
When the electric power steering system warning light comes on
The steering wheel may become extremely heavy.
If the steering wheel becomes heavier than usual when operating, hold
firmly and operate using more force than usual.

5
565
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
If a warning message is displayed
If a warning is shown on the multi-information display, stay calm and
perform the following actions:
Master warning light
The master warning light also
comes on or flashes in order
to indicate that a message is
currently being displayed on
the multi-information dis-
play.
Multi-information display
If any of the warning light comes on again after the following
actions have been performed, contact any authorized Lexus
dealer or repairer, or another duly qualified and equipped profes-
il

566
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Stop the vehicle immediately.
A buzzer sounds and a warning message is shown on the multi-
information display. The following warning indicates the possibil-
ity of damage to the vehicle that may lead to an accident. Immedi-
ately stop the vehicle in a safe place and contact any authorized
Lexus dealer or repairer, or another duly qualified and equipped
professional.
Warning messageDetails
Indicates a malfunction in the hybrid system

5
567
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Have the vehicle inspected immediately.
A buzzer sounds and a warning message is shown on the multi-
information display. Failure to investigate the cause of the follow-
ing warnings may lead to the system operating abnormally and
possibly cause an accident. Have the vehicle inspected by any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Warning messageDetails
Indicates a malfunction in the P position control
system
In this situation, there is a possibility that the
parking lock mechanism will not work.
When parking, park the vehicle on a flat surface
and apply the parking brake securely. Also, it
may not be possible to turn the “POWER”
switch off. If this happens, applying the parking
brake will enable the switch to be turned off.
(Flashes)
(If equipped)
Indicates a malfunction in the LED headlight sys-
tem

568
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
Warning messageDetails
(Flashes)
(If equipped)
Indicates a malfunction in the pre-crash safety
system
(If equipped)
Indicates a malfunction in the Lexus parking
assist-sensor
The malfunctioning assist-sensor is flashing.
Indicates a malfunction in the radar cruise control
system (if equipped) or the cruise control system
Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
