Hood
Release the lock from the inside of the vehicle to open the hood.
Pull the hood release lever.
The hood will pop up
slightly.
Pull up the auxiliary catch
lever and lift the hood.
Hold the hood open by
inserting the supporting rod
into the slot.
STEP1
STEP2
STEP3

482
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
CAUTION
Pre-driving check
Check that the hood is fully closed and locked.
If the hood is not locked properly, it may open while the vehicle is in motion
and cause an accident, which may result in death or serious injury.
After installing the support rod into the slot
Make sure the rod supports the hood securely from falling down on to your
head or body.
NOTICE
When closing the hood
Be sure to return the support rod to its clip before closing the hood. Closing
the hood without returning the support rod properly could cause the hood to
bend.

483
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)
Positioning a floor jack
When raising your vehicle with a floor jack, position the jack cor-
rectly. Improper placement may damage your vehicle or cause injury.
Front
Rear

484
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
CAUTION
When raising your vehicle
Make sure to observe the following precautions to reduce the possibility of
death or serious injury:
When using a floor jack, follow the instructions of the manual provided
with the jack.
Do not use the jack that was supplied with your vehicle.
Do not put any part of your body underneath the vehicle when it is sup-
ported only by the floor jack.
Always use floor jack and/or automotive jack stands on a solid, flat, level
surface.
Do not start the hybrid system while the vehicle is supported by the floor
jack.
Stop the vehicle on level, firm ground, firmly set the parking brake and
shift the shift position to P.
Make sure to set the floor jack properly at the jack point.
Raising the vehicle with an improperly positioned floor jack will damage
the vehicle and may cause the vehicle to fall off the floor jack.
Do not raise the vehicle while someone is in the vehicle.
When raising the vehicle, do not place any object on top of or underneath
the floor jack.
Lift up the vehicle using a floor jack
such as the one shown in the illustra-
tion.

485
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)
Engine compartment
12-volt battery
P. 4 9 6
Engine coolant reservoir
(P. 491)
Engine oil level dipstick
(P. 487)
Engine oil filler cap (P.
487)
Power control unit coolantFuse box (P. 520)
Radiator (P. 494)
Condenser (P. 494)
Electric cooling fans
Washer fluid tank (P.
495)

486
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)
Engine compartment cover
Removing the engine compartment cover
Installing the clips
Push up center portion
Insert
Press
NOTICE
After installing an engine compartment cover
Make sure that the cover is securely installed in its original position.

487
4-3. Do-it-yourself maintenance
4
Maintenance and care
CT200h_EE (OM76041E)
Engine oil
With the engine at operating temperature and turned off, check the
oil level on the dipstick.
Checking the engine oil
Park the vehicle on level ground. After warming up the
engine and turning off the hybrid system, wait more than 5
minutes for the oil to drain back into the bottom of the
engine.
Holding a rag under the end,
pull the dipstick out.
Wipe the dipstick clean.
Reinsert the dipstick fully.
Holding a rag under the end, pull the dipstick out and check
the oil level.
Wipe the dipstick and reinsert it fully.
Low
Full
STEP1
STEP2
STEP3
STEP4
STEP5
STEP6

488
4-3. Do-it-yourself maintenance
CT200h_EE (OM76041E)Adding engine oil
If the oil level is below or near
the low level mark, add engine
oil of the same type as that
already in the engine.
Make sure to check the oil type and prepare the items needed
before adding oil.
Remove the oil filler cap by turning it counterclockwise.
Add engine oil slowly, checking the dipstick.
Install the oil filler cap by turning it clockwise.
Engine oil selectionP. 6 4 2
Oil quantity
(Low  Full)1.5 L (1.6 qt., 1.3 lmp. qt.)
ItemsClean funnel
STEP1
STEP2
STEP3
