,002%,/,=(5:,7+'2:1/2$'$1'9$63&/$0%25*+,1, Introduction
The new Gallardo LP 560-4 MY09 is equipped with a modern electronic immobilizer system called “Immobilizer 4 with download”.
This antitheft device blocks vehicle ignition, making its use impossible if a control unit or key are not original or have been tampered with. The Immobilizer 4 system involves the following vehicle components: •the two Master 01 ( A) & Slave 11 ( B) engine control units
• the Immobilizer 25 control unit (integrated in the Kombi 17)
• the ignition keys
A secret code is concealed inside each component. It is processed and recognised at each start-up by the Immobilizer
25 control unit placed inside the instrument cluster (Kombi 17). If the code read on all components involved coincides,
ignition is permitted. In the event the Immobilizer 25 control unit recognises an inconsistency amongst the secret
codes of the vehicle components, power supply to the engine will be immediately cut off after about three seconds
from ignition, and the word SAFE will appear on the instrument cluster display. It will be impossible to start the engine until the inconsistency previously found is resolved.
The VAS PC Lamborghini software must be used for managing replacement of the components involved in the Immobilizer 4 ( Fig.1).
The Immobilizer 25 control unit is an integral part of the Kombi, and therefore cannot be replaced
separately.
The VAS PC Lamborghini software allows the components installed on the vehicle to be synchronized with the virtual
YHKLFOHFRQ¿JXUDWLRQLQWKHSURGXFWLRQGDWDEDVH7RSHUIRUPWKHV\QFKURQL]DWLRQFRQQHFWWKHVRIWZDUHWRWKHYHKLFOH
using the OBD II outlet and the laptop to the Internet using a network outlet at the same time. In this way, the VAS PC software will be able to exchange information between the vehicle and the production database.
1R,PPRELOL]HUFRGHLQ2))/,1(PRGHLVSHUPLWWHG
