*HUDER[DGMXVWPHQW
Step 1 1. Check that both the selection terminal and the engagement terminal ( $%)LJ) are enabled (not anchored
onto the ends of the cables). The terminals are enabled when the spring is compressed and slightly turned so
that the ring nut locks into place.
2. Insert the tool ( &)LJ) that holds the levers in place in the hole on the gear lever device and on the levers on
the gearbox. Check that the gearshift lever is only able to engage.
3. Disable the gear selection lever terminal ( $)LJ) and check that the terminal and cable are anchored together.
The gear selection has now been adjusted.
Step 2
7ZR SHRSOH PXVW FDUU\ RXW WKH JHDU OHYHU DGMXVWPHQW RQH LQ WKH YHKLFOH DQG RQH QHDU WKH terminals.
1. Remove the tool that holds the levers in place ( &)LJ) from the gear lever device and assemble the selector
using the two screws.
2. Position the lever exactly at the middle of the selector ( Fig.2).
3. Disable the engagement lever terminal ( $)LJ) and check that the terminal and cable are anchored together.
Gear engagement has now been adjusted.
4. Remove the tool that holds the levers in place ( &)LJ) on the gearbox.
5. Check that the system works correctly by changing gears. Gear selection
terminal
Tool for
KROGLQJOHYHUV in placeGear
engagement
terminal
Tool for
KROGLQJOHYHUV in place
